Aussie
LP Gas Grill
Assembly and Use Manual
FOR OUTDOOR HOUSEHOLD USE ONLY. NOT FOR COMMERCIAL USE.
For Customer Service, call 1-800-251-7558 or visit our web site at www.meco.net
• Failure to follow these instructions could result in fire or explosion which could cause death,
serious personal injury, or property damage.
• Read and follow instructions carefully before assembly or use.
• Do not use this product for any other purpose than which it is intended.
• These instructions must be kept with the user. SAVE THESE INSTRUCTIONS.
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
®
by Meco
MODEL 7110.7.641 Liquid Propane Gas Grill
®
TM
Joey
1. Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7110.7.641 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aussie 7110.7.641

  • Page 1 MODEL 7110.7.641 Liquid Propane Gas Grill FOR OUTDOOR HOUSEHOLD USE ONLY. NOT FOR COMMERCIAL USE. For Customer Service, call 1-800-251-7558 or visit our web site at www.meco.net • Failure to follow these instructions could result in fire or explosion which could cause death, serious personal injury, or property damage.
  • Page 2: Table Of Contents

    MECO CORPORATION STRIVES TO BE A QUALITY SUPPLIER OF CONSUMER PRODUCTS. IF WE OMITTED ANY PARTS NEEDED FOR ASSEMBLY, OR YOU NEED TROUBLESHOOTING INFORMATION, PLEASE CONTACT US USING OUR TOLL FREE NUMBER. THANK YOU FOR PURCHASING A MECO CORPORATION PRODUCT.
  • Page 3: Parts Illustrations

    If you need replacement parts, refer to the Parts Illustrations and the Parts List to find the exact parts you need. If you have any questions which require help, contact Customer Service and be sure to mention the model number of your grill. (3) Cylinder Retainer Clip (1) Owner’s Manual...
  • Page 4 (33) Hood Handle (31) Handle Spacer (32) Handle Spacer (Tapered) (Fitted) (35) Flame Diffuser (34) Cooking Grid (36) Main Burner 42) Main Burner Electrode (38) Warming Rack (37) Fabric Panel (39) LP Cylinder (40) Control Panel Heat Shield w/Manifold and Regulator (41) Control Knob...
  • Page 5: Step 1) Cart Assembly

    To reduce the risk of a cut injury: · Wear protective gloves when handling parts that have sharp edges. · Some assembly may require help from another person. Observe where noted. TOOLS: STEP 1) Cart Assembly: Attach the Legs to the Bottom Shelf with M5 x 40 Bolts threaded into the Bottom Shelf holes.
  • Page 6: Step 2) Assemble Axle, Wheels & Wheel Covers

    STEP 2) Assemble Axle, Wheels & Wheel Covers: Push Axle through center hole in Wheel and through lower hole in each leg. (FIG. 2A) Insert Axle pin through small hole in end of Axle until it snaps over it. (FIG. 2B) Align Wheel Cover pins with 3-holes in Wheel and push flush against Wheel.
  • Page 7: Step 3) Assemble Hood/Bowl To Cart

    Step 3) Assemble Hood/Bowl to Cart: (14) HOOD/BOWL ASSEMBLY NOTE: REQUIRES 2-PERSONS · With Cart upright, align Bowl Bracket legs with Cart legs. (FIG. 3A) · Lower Hood/Bowl so ends of Cart legs insert into Bowl Bracket legs. · Press downward until leg screw holes align. NOTE: If cart legs do not align and fit into Bowl Bracket legs easily, loosen the Control Panel bolts slightly.
  • Page 8: Step 5) Assemble Sidebraces

    Step 5) Assemble Sidebraces: · Attach Right and Left Sidebraces (19 & 20) to legs with ST4.0 x 10 Screws. (FIG. 5A) Secure Bottom Heat Shield to Left Sidebrace with M4x10 Bolts and M4 Wingnuts. (FIG. 5B) Allow Heat Shield Edge to overlap Sidebrace edge. (22) BOLT, (21) SCREW, ST4.0 x 10 M4x 10MM...
  • Page 9: Step 6) Assemble Side Tables

    Step 6) Assemble Side Tables: Align bracket holes of Left and Right Side Tables with holes in Bowl Leg Brackets. Attach Side Tables with M6 x 15 Bolts underneath. (FIG. 6A 7 6B) (27) BOLT, M6X15 8 PC FIG. 6B (27) BOLT, M6X15 Step 7) Attach Hood Handle: Open Hood.
  • Page 10: Step 8) Attach Front Panel

    Step 8) Attach Front Panel: Remove the M6 nut used to attach the upper and lower leg sections. Place the large eyelet over the bolt and replace the nut. (FIG. 8B) Using the ST4.0 Screw, secure the Fabric Panel to holes in the lower legs over the eyelets. (FIG. 8A) (21) SCREW, ST4.0 x 10 4 PC (37) FABRIC PANEL...
  • Page 11: Operating Your Lp Gas Grill

    Other types of caps or plugs may result in leakage of propane. · The LP gas cylinder, for use with this LP gas grill, must meet the following requirements: 1) 12” diameter x 18” tall, 20 lb.. maximum capacity...
  • Page 12: A) Connecting Lp Gas Cylinder

    National Electrical Codes, ANSI/NFPA 70, or the Canadian Electrical Code Remove CSA C22.1. Protective Cap · Keep any electrical supply cord away from any heated surfaces. Cylinder Retainer Clip BEFORE USING YOUR GAS GRILL INSTALLATION CODES...
  • Page 13: Selecting A Location

    · Do not perform a leak test on a grill while it is hot or in use. · Do not use the gas grill if you detect a gas leak that cannot be corrected by using the leak test procedures.
  • Page 14: Lighting The Grill Using The Ignitor

    To reduce the risk of serious bodily injury or death: · Open Hood before lighting the grill to prevent an explosion from any gas accumulation. · If lighting attempts fail, or the burners go out during operation, turn all control knobs “Off” to dissipate any accumulation of gas.
  • Page 15: Manual Lighting The Grill

    MANUAL LIGHTING THE GRILL To reduce the risk of serious bodily injury or death: · Open Hood before lighting the grill to prevent an explosion from any gas accumulation. · If lighting attempts fail, or the burners go out during operation, turn all control knobs “Off”...
  • Page 16: Warming Rack

    · Keep any electrical supply cord and regulator hose away from any heated surfaces. · Do not operate a gas grill if you are aware of or suspect a gas leak. · Make sure there are no gas leaks or obstructions to the flow of combustion and ventilation air before each use.
  • Page 17: Spider Alert

    To reduce the risk of a cut injury: · Be careful or wear protective gloves when cleaning grill parts that have sharp edges. CLEANING THE GRILL 1) Remove Drip Cup, Cooking Grid, and Flame Diffuser. 2) Drip Cup-Wash the Drip Cup with soap and water. 3) Grill Body and Cart-Do not mistake the accumulation of grease and smoke residue for peeling or flaking paint.
  • Page 18: B) Storage

    STORAGE To reduce the risk of serious bodily injury or death: · Store your LP gas grill in a cool dry place. Do not store an LP gas cylinder in a space greater than 125 degrees Fahrenheit. Do not store an LP gas cylinder in a building ,garage or any enclosed area.
  • Page 19: Troubleshooting

    Gas Leaks and Fire Emergencies Problem Possible Cause Gas leaking from Damaged hose. cracked/cut/burned hose. Gas leaking from LP Mechanical failure due to rust cylinder or mishandling. Gas leaking from LP Failure of valve from mishan- cylinder valve dling or mechanical malfunc- tion.
  • Page 20 Turn control knobs to “off” position and turn LP gas cylinder handle clockwise until it stops. Wait five minutes. Relight LP gas grill. If flame continues to be low, turn off gas at cylinder and grill. Disconnect the regulator from the LP gas cylinder.
  • Page 21: Important Notice-Lp Cylinder With Opd

    If your problem is not resolved from the information provided above, please call Customer Service at IMPORTANT NOTICE This Gas Grill must be used with a LP Gas Cylinder equipped with an OPD (Overfill Prevention Device). This is a secondary device to prevent the overfill of your LP Gas cylinder. The proper methods for the filling of your LP Gas cylinder are by weight or volume, as described in NFPA 58.
  • Page 22: Limited Warranty

    All other parts are warranted for a period of one (1) year from the date of purchase. Meco Corporation requires proof of purchase and we suggest you keep your receipt. Damages caused by commercial or institutional use, accidental or intentional damage, repairs made or attempted by unauthorized persons, or misuse are not covered by this warranty.
  • Page 23 ® Aussie P/N 03.6602.01 REV. 20071129...
