Quick Installation Guide
Quick Installation Guide
Package Contents:
MPCIE-3G package includes the following items:
1 x MPCIE-3G PCI Express Mini 3G adapter card
1 x Driver CD
1 x RF antenna cable (optional)
1 x GSM antenna cable (optional)
PCI Express Mini 3G Adapter Card, RoHs
MPCIE-3G
Version 1.0
Jul 01, 2014
©2013 Copyright by IEI Integration corp.
All rights reserved.
ard, RoHs
.
1
Advertisement
Related Manuals for IEI Technology MPCIE-3G
Summary of Contents for IEI Technology MPCIE-3G
- Page 1 Version 1.0 Jul 01, 2014 Package Contents: MPCIE-3G package includes the following items: 1 x MPCIE-3G PCI Express Mini 3G adapter card 1 x Driver CD 1 x RF antenna cable (optional) 1 x GSM antenna cable (optional) ©2013 Copyright by IEI Integration corp.
-
Page 2: Specifications
Specifications MPCIE-3G GSM/GPRS/EDGE Dual band GSM 900 / 1800 MHz Frequency Bands UMTS/HSPA+ Dual band UMTS 900/2100MHz Class 4 (+33dBm 2dB) for EGSM900 Class 1 (+30dBm 2dB) for GSM1800 Class E2 (+27dBm 3dB) for GSM900 8-PSK Output Power Class E2 (+26dBm+3 /-4dB) for GSM1800 8 -... - Page 3 HSPA DL 7.2Mbps, UL 5.7Mbps HSDPA Cat.8 / HSUPA Cat.6 data rates 3GPP Release 6, 7 Compressed mode (CM) supported according to 3GPP TS25.212 UMTS PS data rate 384 kbps DL / 384 kbps UL 3GPP Release 4 CS data rate 64 kbps DL / 64 kbps UL GSM/GPRS/EGPRS GPRS: Multislot Class 12...
- Page 4 Point-to-point MT and MO Cell broadcast Text and PDU mode Storage: SIM card plus SMS locations in mobile equipment Interface Antenna 50Ohms. Main GSM/UMTS antenna USB 2.0 High Speed (480Mbit/s) device interface, Full Speed (12Mbit/s) compliant ASC0: 8-wire modem interface with status and control lines, unbalanced, asynchronous Adjustable baud rates: 1,200bps to 921,600...
-
Page 5: Hardware Installation
Hardware Installation Step 1: Install the MPCIE-3G card into the PCIe Mini full-size slot of the system. Please refer to the system manual for the detail installation instruction. Step 2: Connect the RF antenna cable to the RF antenna connector on the MPCIE-3G. -
Page 6: Software Installation
Software Installation Step 1: Insert the MPCIE-3G driver CD into the system. Step 2: Open the Device Manager. Right click on Cinterion Wireless Modules Suspend under Other devices and select Update Driver Software. NOTE: There are seven further EHx ports located under “Other devices”... - Page 7 Step 3: The Hardware Update Wizard appears. Select “Yes, this time only” and click Next to continue. Step 4: Select “Install the software automatically” and click Next.
- Page 8 Step 5: The Hardware Installation warning windows appears. Click “Continue Anyway”. Step 6: The system starts installing drivers.
- Page 9 Step 7: When the Hardware Update Complete window appears, click Finish to close the wizard. Step 8: The Cinterion EHx USB Modem appears in the Device Manager under Modems.
- Page 10 Click the Advanced tab to specify the Extra Initialization Commands: AT+CGDCONT=1,”IP”,”[APN]” NOTE: [APN] stands for the APN information provided by the MNO of the SIM card installed on the MPCIE-3G. Ensure that the SIM card does not require a PIN.
-
Page 12: Create A Connection
Create a Connection Step 1: Open Control Panel. Select Network and Internet Connections Network Connections. Click “Create a new connection”. Step 2: The New Connection Wizard appears. Click Next to continue. - Page 13 Step 3: Select a network connection type. Click Next to continue. Step 4: Select “Set up my connection manually”. Click Next to continue.
- Page 14 Step 5: Select “Connect using a dial-up modem”. Click Next to continue. Step 6: Type a name for this connection. Click Next to continue.
- Page 15 Step 7: Enter the Internet Service Provider settings in the following two setup windows. The information should be provided by the MNO of the installed SIM card, including phone number, user name and password. Click Next to continue.
- Page 16 Step 8: The setup steps are completed. To create the connection and close the wizard, click Finish.
