2.2 Rear View
2.2.1 GV-SNVR0411
No. Name
1
DC 52 V (Power Input)
Megabit PoE Port
2
WAN
3
4
USB 2.0 Port
5
Default Button
6
HDMI Output
6
Function
Connects to power supply.
Connects to cameras, delivering power and network
connection to the cameras.
Connects to the network.
Connects to a keyboard, mouse, USB flash drive or
GV-Joystick V2.
Restores the device to default settings. Press the button for
15 seconds to load default.
Connects to a HD TV.
12
5
3
2
4
1
