Installation and Operations Manual — LXL Gate Operator
INSTALLATION MANUAL
B&B ARMR
A Division of B&B Roadway and Security Solutions
Hydraulic Slide Gate
Model No.:_______________________
Serial No.: _______________________
B&B ARMR
Corporate Office & Tech Support:
5900 S. Lake Forest Drive, Suite 230
McKinney, TX 75070
Phone: (800) 367-0387
Fax: (972) 385-9887
E-mail:
info@bb-armr.com
techsupport@bb-armr.com
www.bb-armr.com
MADE IN THE USA
LXL Series
Operators
0054-9001UL Revision A2
1

Advertisement

Table of Contents
loading

Summary of Contents for B&B ARMR LXL-15vp-SS

  • Page 1 Installation and Operations Manual — LXL Gate Operator LXL Series Hydraulic Slide Gate Operators INSTALLATION MANUAL Model No.:_______________________ Serial No.: _______________________ B&B ARMR Corporate Office & Tech Support: 5900 S. Lake Forest Drive, Suite 230 McKinney, TX 75070 Phone: (800) 367-0387 Fax: (972) 385-9887 E-mail: info@bb-armr.com...
  • Page 2: Introduction

    Installation and Operations Manual — LXL Gate Operator Your safety is extremely important to us. If you have any questions or are in doubt about any aspect of the equipment, please contact us. Introduction Welcome! Congratulations on your purchase of a B&B ARMR gate operator. In addition to providing detailed operating instructions, this manual describes how to install, maintain, and troubleshoot your operator.
  • Page 3: Important Safety Information

    Installation and Operations Manual — LXL Gate Operator Important Safety Information TO REDUCE THE RISK OF SERIOUS INJURY OR DEATH, READ AND FOLLOW ALL INSTRUCTIONS PROVIDED IN THIS MANUAL. 1. Hydraulic slide gate operators are intended for vehicular use only. Pedestrians should use a separate walkthrough entrance designed for on-foot traffic.
  • Page 4: How To Contact Us

    Installation and Operations Manual — LXL Gate Operator How to Contact Us If you have any questions or experience any problems with your vehicle barrier—or if we can help you with any other facility security issues—please contact us directly at: Corporate/Tech Support: B&B ARMR 5900 S.
  • Page 5: Table Of Contents

    Installation and Operations Manual — LXL Gate Operator Table of Contents Introduction ..........................2 Safety ............................2 How to Contact Us ........................4 System Installation Record ....................... 4 UL 325 And Gate Operators ....................7 What Is UL? ..............................7 Development Of UL-325 ..........................
  • Page 6 Installation and Operations Manual — LXL Gate Operator 4.13 Turning ON / OFF The Timer To Close ....................21 4.14 Setting The Timer To Close ........................21 4.15 Setting The Inherent Safety ........................22 4.16 Setting the Gate Locking Device ......................22 4.16.1 Self Latching Lock Parameter......................
  • Page 7: Ul 325 And Gate Operators

    Installation and Operations Manual — LXL Gate Operator 1. UL 325 And Gate Operators 1.1 What Is UL? Underwriters Laboratories, Inc., a non-profit organization established in 1894, is self- described as “the leading third-party certification organization in the United States and the largest in North America.”...
  • Page 8: Gate Operator Classifications

    Installation and Operations Manual — LXL Gate Operator AGAINST ROTECTION NTRAPMENT VEHICULAR USAGE GATE OPERATOR CATEGORY CLASS Horizontal Slide SWING GATE VERTICAL LIFT VERTICAL BARRIER (ARM) VERTICAL PIVOT PRIMARY SECONDARY PRIMARY TYPE SECONDARY TYPE TYPE TYPE Class I & II B1,B2 or D A or C A,B1,B2,C or D...
  • Page 9 Installation and Operations Manual — LXL Gate Operator Figure 1 Non-Contact Sensor Detail Figure 2 Contact Sensor Detail B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 10: Effect On Installation

    Installation and Operations Manual — LXL Gate Operator 2. Effect On Installation These provisions will have several effects on gate and fence dealers: • Gate and fence dealers should look for an indication of the Class of each operator, which will be specified by the gate operator manufacturer.
  • Page 11: Statements In Manufacturer's Instructions Concerning Installation

    Installation and Operations Manual — LXL Gate Operator • at the leading edge, the trailing edge, and also post-mounted both inside and outside of, a vehicular horizontal slide gate; • at the bottom edge of a vehicular vertical slide gate; and •...
  • Page 12: Lxl Operator Models And Features

    Installation and Operations Manual — LXL Gate Operator 3. LXL Operator Models And Features 3.1 General Description B&B ARMR’s model LXL hydraulic sliding gate operator is designed to reliably operate many styles of sliding gates, including overhead track, ground track, and cantilever style gates. Our LXL series of operators are designed to operate in all four UL-325 classes of operators.
  • Page 13: Models Available

    NOTE: To order any of the LXL models, substitute the required input voltage for the "v" and the required input phase for "p". Typical Available Models Travel Speed Gate Size Pull Force UL Class LXL-15vp-SS Standard Speed 1.0 ft/s 2,000 lbs 400 lbs I-IV LXL-15vp-HS High Speed 2.0 ft/s...
  • Page 14: Installing And Programming The Lxl Operator

    Installation and Operations Manual — LXL Gate Operator 4. Installing and Programming the LXL Operator Installation and programming of the LXL series gate operators can be accomplished in a few easy steps. The following illustrations will guide you through the process of mounting the operator and drive rail, connecting power and programming the LXL controller functions.
  • Page 15: Mount Drive Rail

    Installation and Operations Manual — LXL Gate Operator 4.3 Mount Drive Rail 1. Place gate operator on the pad and measure 3” from the face of a vertical gate member to center of the wheels. 2. With the drive wheels disengaged, slide the drive rail between the wheels, to the closed position.
  • Page 16: Install Limit Switch Trip Plates

    Installation and Operations Manual — LXL Gate Operator 4.4 Install Limit Switch Trip Plates 1. Slide the gate to the full open position. 2. On the top of the drive rail, place a trip plate so that the last 2” is in front of the proximity switch.
  • Page 17: Connect Primary Power

    Installation and Operations Manual — LXL Gate Operator 4.5 Connect Primary Power Connecting the Primary Power should be performed by a license electrician. The primary power must have a circuit breaker in-line from power source in accordance to NEC. A\C UNITS ONLY FOR D/C UNITS, GO TO STEP 4.7-4.8 1.
  • Page 18: Connect Primary / Battery Power D/C Units Only

    Installation and Operations Manual — LXL Gate Operator 4.7 Connect Primary / Battery Power D/C Units Only 1. Connect the primary power to switch S1B and the batteries to switch S1A in the converter enclosure. 2. Earth ground the enclosure. THIS IS NOT AN OPTION! 3.
  • Page 19: Set Operator Handing (Inside Looking Out)

    Installation and Operations Manual — LXL Gate Operator 4.10 Set Operator Handing (Inside Looking Out) 1. With power off, move the gate to the close position with the limit plate in front of the close limit switch. 2. While holding down STOP and CLOSE buttons on supplied 3 button station, turn operator power on.
  • Page 20: Setting The Date And Time (Optional, Not Required)

    Installation and Operations Manual — LXL Gate Operator Setting The Date And Time (optional, not required) 1. Turn power on. Date and time will be flashing. Press the ESC key. 2. This is the main menu. Use the UP >Stop and DOWN arrow keys to select ‘Set Set Param Clock’, and press the OK button.
  • Page 21: Turning On / Off The Timer To Close

    Installation and Operations Manual — LXL Gate Operator 4.12 Turning ON / OFF The Timer To Close With the unit powered down and the gate OPEN in the closed position, locate the supplied 3 button control station and do the following (in order): 1.
  • Page 22: Setting The Inherent Safety

    Installation and Operations Manual — LXL Gate Operator 4.14 Setting The Inherent Safety 1. Press the ESC button to return to the main menu. 2. Engage the drive wheels on the drive LXL V1.20 rail. Open and Close the operator MX RN 20:00s using the 3 button control station.
  • Page 23: Maglock Parameter

    Installation and Operations Manual — LXL Gate Operator 4.15.2 Maglock Parameter 1. From the main menu, select ‘Set Param’. 2. Press the UP grey arrow key and MAGLOCK? scroll through the options to MAGLOCK? 3. Press OK. Switch-Off 4. The S on Switch will start flashing 5.
  • Page 24: Mainopen Parameter

    Installation and Operations Manual — LXL Gate Operator 4.16.1 MAINOPEN Parameter From the main menu, select ‘Set Param’. 2. Press the UP grey arrow key and MAINOPEN scroll through the options to MAINOPEN 3. Press OK. Switch-Off 4. The S on Switch will start flashing 5.
  • Page 25: The Lxl Interface Board

    Installation and Operations Manual — LXL Gate Operator 6. The LXL Interface Board 24VAC/24VDC auxiliary power Processor/Controller Built-in 3 button station Position indication and power loss relays Secondary safety device connections Control inputs (open devices, safety loops, etc.) Input power for control board Contactor output B&B ARMR A Division of B&B Roadway and Security Solutions...
  • Page 26: Secondary Safety Devices

    Installation and Operations Manual — LXL Gate Operator 1 amp fuse (processor protection) Factory connections 7. Secondary Safety Devices Connecting safety devices to the secondary safety connectors will stop the gate on the detection of the safety and proceed in the event of clearing the safety. To reverse the gate on the event of a safety, you must connect the safety device to the loopsafe terminal on connector 3.
  • Page 27: Master Slave Connections

    Installation and Operations Manual — LXL Gate Operator 8. Master Slave Connections  10 conductors required for master / slave connection between operators (16-18 gauge wire), plus 4 for safety devices  Each operator must be programmed separately  Secondary safety devices must be connected to their respective operators for proper operation, and to ensure UL 325 compliance B&B ARMR A Division of B&B Roadway and Security Solutions...
  • Page 28: Other Device Connections

    Installation and Operations Manual — LXL Gate Operator 9. Other Device Connections B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 29: Appendix

    Installation and Operations Manual — LXL Gate Operator 10. Appendix ** Note: There are some changes in the drawing below. Standard speed setup is shown. For high speed and rack and pinion users please note that these item numbers are different: Number 31 will be XHYD-103-1572 for standard and high speed units Number 31 will be 0050-RS-1001010 for rack and pinion units Number 9 will be XHYD-M406-0103 for high speed units...
  • Page 30: General Parts Breakdown

    Installation and Operations Manual — LXL Gate Operator 2.1 General Parts Breakdown Typical Installation B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 31 Installation and Operations Manual — LXL Gate Operator B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 32: Battery Backup Schematic

    Installation and Operations Manual — LXL Gate Operator 2.2 Battery Backup Schematic B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 33 Installation and Operations Manual — LXL Gate Operator Battery backup Parts List B&B ARMR # ITEM QTY B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 34 Installation and Operations Manual — LXL Gate Operator B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 35 Installation and Operations Manual — LXL Gate Operator B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 36 Installation and Operations Manual — LXL Gate Operator B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 37 Installation and Operations Manual — LXL Gate Operator B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 38 Installation and Operations Manual — LXL Gate Operator B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 39 Installation and Operations Manual — LXL Gate Operator B&B ARMR A Division of B&B Roadway and Security Solutions 0054-9001UL Revision A2...
  • Page 40: Troubleshooting

    Installation and Operations Manual — LXL Gate Operator 11. Troubleshooting The table below provides a general guidance on identifying and correcting any problems with your LXL Series gate operator. If you encounter problems that you cannot fix, contact B&B ARMR and we will gladly work with you to correct them. 2.3 Alarm Definitions –...
  • Page 41 Installation and Operations Manual — LXL Gate Operator Symptom Actions 1. Check CONN 9 for power when command is given. 2. Check overload protector Gate operator does 3. Check PLC output. not respond when 4. Check that safeties are clear, and that IR Beams are aligned. commanded.
  • Page 42 Installation and Operations Manual — LXL Gate Operator Symptom Actions 3. Check the connection of the wire between the J1Pin 9 connector and I7 of the PLC. 4. Verify shunt is present on JP1 between pins 1 and 2. 5. Check F3. Electric Motor turns 1.
  • Page 43: Equipment Maintenance Log Form

    Installation and Operations Manual — LXL Gate Operator 2.5 Equipment Maintenance Log Form Product Type:____________________ Location:________________________ Checklist Date Performed By Anomalies Notes Complete Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Yes No Year...
  • Page 44: Warranty Information

    Installation and Operations Manual — LXL Gate Operator 12. Warranty Information B&B-ARMR CORPORATION warranties for a period of five (5) years, after delivery F.O.B. plant, unless otherwise specified by Supplier, from failure of operation in ordinary use and against defects due to faulty material or workmanship. Any defective equipment in the Barrier shall be returned to the factory, at Supplier’s option, for repair or replacement, and Supplier assumes no responsibility for service at any consumer site.
