Components and connectors
The following figure shows the port-side view of the DB620S FC SAN Switch.
Figure 2. DB620S FC SAN Switch port-side view
The following figure shows the non-port side view of the DB620S FC SAN Switch.
Figure 3. DB620S FC SAN Switch non-port-side view

System specifications

The following table lists the ThinkSystem DB620S system specifications.
Table 1. System specifications
Component
Specification
Form factor
Standalone or 1U rack mount
Ports
Media types
Lenovo ThinkSystem DB620S 32Gb FC SAN Switch
48x SFP+ ports:
Model HC1: 24 ports activated and 24x 32 Gb FC SWL SFP+ transceivers
included; up to two optional 12-port activation license packs or bundles (12-
port license pack and 12x 32 Gb FC SWL SFP+ transceivers).
Model HC2: 48 ports activated and 48x 32 Gb FC SWL SFP+ transceivers
included.
4x QSFP+ ports (require an optional activation license).
128 Gb (4x 32 Gb) FC QSFP+ transceivers: short wavelength (SWL).
128 Gb (4x 32 Gb) FC QSFP+ v2 transceivers: SWL.
4x 16 Gb FC QSFP+ transceivers: SWL.
32 Gb FC SFP+ transceivers: SWL, long wavelength (LWL).
16 Gb FC SFP+ transceivers: SWL, LWL, extended long wavelength (ELWL).
10 Gb FC SFP+ transceivers: SWL, LWL.
3
