Page 1 Embedded Computer 6th Generation Intel® Xeon® E3 or Intel® Core™ i7/ i3 Processors EAC PRO-IK90 User Manual Version 2.0 Document part number: 917111171007...
Page 2: Preface
In the serial numbers the third and fourth two digits give the year of manufacture, and the fifth digit means the month (e. g., with A for October, B for November and C for December). For example, the serial number 1W17Axxxxxxxx means October of year 2017. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 3: Customer Service
In addition, free technical support is available from our engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 4 The Protective Conductor Terminal (Earth Ground) symbol indicates the potential risk of serious electrical shock due to improper grounding. Le symbole de Mise à Terre indique le risqué potential de choc électrique grave à la terre incorrecte. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 5: Safety Information
Toujours utiliser un bracelet de mise à la terre comme précaution. Placer toutes les composantes électroniques sur une surface conçue pour dissiper les charge, ou dans un sac anti-statique lorsqu’elles ne sont pas dans le chassis. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 6: Safety Precautions
Si vous doutez de leur provenance, contactez le manufacturier. WARNING!/ AVERTISSEMENT! Always ground yourself against electrostatic damage to the device. Toujours vérifier votre mise à la terre afin que l’équipement ne se décharge pas sur vous. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 7: Important Information
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at him own expense. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 8 IEC61000-4-3: 2006+A1: 2007+A2: 2010 o IEC61000-4-4: 2012 o IEC61000-4-5: 2014 o IEC61000-4-6: 2013 o IEC61000-4-8: 2010 o IEC61000-4-11: 2004  EN55022: 2010/AC:2011  EN61000-3-2:2014  EN61000-3-3:2013 Low Voltage Directive (2014/35/EU)  EN 60950-1:2006/A11:2009/A1:2010/A12:2011/ A2:2013 EAC PRO-IK90 EMBEDDED COMPUTER viii...
Page 9: About This User Manual
The documentation set for the Winmate® Embedded Computer EAC PRO-IK90 provides information for specific user needs, and includes:  EAC PRO-IK90 Quick Start Guide - describes how to get the box computer up and running.  EAC PRO-IK90 User Manual – contains detailed description on how to use the display, its components and features.
Page 10: Table Of Contents
2.2.3 Inserting a CFast Card ..................34 2.2.4 Expansion Module (Preliminary) ..............35 2.2.5 External Antenna Installation ................. 36 2.2.6 Inserting a Memory Card and Mini PCIe Card ..........36 2.3 Connecting the Power....................38 2.3.1 Connecting to AC Power ................. 38 EAC PRO-IK90 EMBEDDED COMPUTER...
Page 11 4.7 Microsoft .NET Framework Driver ................89 4.8 WatchDog Driver ....................... 89 CHAPTER 5: TECHNICAL SUPPORT ..................91 5.1 Software Developer Support ..................91 5.2 Problem Report Form ....................92 APPENDIX A: ORDERING INFORMATION ................94 EAC PRO-IK90 EMBEDDED COMPUTER...
Page 12: Specifications
USER MANUAL CHAPTER 1 INTRODUCTION INTRODUCTION This chapter provides the EAC PRO-IK90 Embedded Computer product overview, describes its features and hardware specifications. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 13: Chapter 1: Introduction
IK90 with 6th Generation Intel® Xeon E3 or Core™ i7/i3 processors and C236 chipset offers high performance computing power and outstanding video processing. Abundant I/O ports and PCI/ PCIe expansion make EAC PRO-IK90 suitable for Factory Automation, Machine Vision, Surveillance, Machine Automation and other high-performance applications.
Page 14: Hardware Specifications
1 x LPT port pin header Internal I/O 1 x Mini PCIE socket (PCIE) for Wi-Fi module Mini PCIE 1 x Mini PCIE socket (PCIE) for Expansion I/O module or 3G module USIM 1 x USIM slot EAC PRO-IK90 EMBEDDED COMPUTER...
Page 15 0~40°C (32~104°F ) (with HDD) Environment Storage Temp. -20~60° C (-4~140° F) (excl. HDD/ SSD/ CFast) EMC & Safety CE, FCC Certificate Shock &Vibration IEC60068-2-278, IEC60068-2-64 Operating Windows® 10 IoT Enterprise (64bit) System Windows® Embedded 8.1 Industry Pro (64bit) (Optional) EAC PRO-IK90 EMBEDDED COMPUTER...
Page 16: Function Block Diagram
USER MANUAL CHAPTER 1 INTRODUCTION 1.4 Function Block Diagram EAC PRO-IK90 EMBEDDED COMPUTER...
Page 17: Package Contents
CHAPTER 1 INTRODUCTION 1.5 Package Contents Carefully remove the box and unpack EAC PRO-IK90 Embedded Computer. Please check if all the items listed below are inside your package. If any of these items are missing or damaged contact us immediately.
Page 18 USER MANUAL CHAPTER 1 INTRODUCTION Optional accessories: WLAN External WWAN External Antenna Antenna 39700000000E 39700000000F EAC PRO-IK90 EMBEDDED COMPUTER...
Page 19: Appearance And Dimensions
USER MANUAL CHAPTER 1 INTRODUCTION 1.6 Appearance and Dimensions This section includes mechanical drawing and dimensions of the EAC PRO-IK90 Embedded Computer. All dimensions shown in mm (millimeters). Top View Bottom View Front View Rear View Left Side View Right Side View...
Page 20: Front Side I/O Connectors
EAC PRO-IK90 Embedded Computer Front Side 1.6.2 Power Button EAC PRO-IK90 Embedded Computer has a Power On/ Off button on the front side. 1.6.3 Reset Button EAC PRO-IK90 Embedded Computer has a Reset Button located on the front side. Press reset button to reboot the computer forcibly.
Page 21: Led Indicators
USER MANUAL CHAPTER 1 INTRODUCTION 1.6.5 LED Indicators The EAC PRO-IK90 provides four SSD/HDD LED indicators and one WWAN/ WLAN LED indicator for status monitoring. LED Indicator Color Description Slot is empty; module is not yet discovered by the system.
Page 22: Hardware Installation
USER MANUAL CHAPTER 2 HARDWARE INSTALLATION HARDWARE INSTALLATION This chapter provides information on how to use external I/O and the installation of EAC PRO-IK90 Embedded Computer hardware. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 23: Chapter 2: Hardware Installation
This chapter provides information on how to use external I/O and the installation of EAC PRO-IK90 Embedded Computer hardware. 2.1 Jumpers and Connectors This section describes all connectors located on the EAC PRO-IK90 Embedded Computer. 2.1.1 External Connectors This section describes all the external connectors located on the EAC PRO-IK90 Embedded Computer.
Page 24 DATA+ 2.1.1.3 Ethernet Connector (LAN) EAC PRO-IK90 Embedded Computer has three Ethernet connectors located on the front. Ethernet ports provide a standard RJ45 10/100/1000 Mbps jack connector with LED indicators on the front side to show its Active/ Link status and Speed status.
Page 25 USER MANUAL CHAPTER 2 HARDWARE INSTALLATION 2.1.1.4 Audio Connector EAC PRO-IK90 Embedded Computer has two stereo audio ports with phone jack connectors, one is Line-out, and the other one is Mic-in. Color Signal Name GREEN Line-out PINK Mic-in 2.1.1.5 USB3.0 Connector EAC PRO-IK90 Embedded Computer provides six USB3.0 connectors.
Page 26 USER MANUAL CHAPTER 2 HARDWARE INSTALLATION 2.1.1.7 Isolated Digital Input/ Output Connector The EAC PRO-IK90 Embedded Computer controller features an onboard isolated digital I/O circuit with a twenty pin connector on Backplane Board. Digital Input/ Output Connector (CN4) Pin №...
Page 27 Isolated Digital input signals ISO_COM ISO_GND Output Isolated COM Voltage of DO/DI Isolated Inputs Each of isolated digital input channels accepts internal COM voltage setting by JP7. ISO_COM COM Supply Voltage ISO12V Internal isolation DC12V ISO5V Internal isolation DC5V EAC PRO-IK90 EMBEDDED COMPUTER...
Page 28 COM voltage setting by JP7. Signal Reference Direction Description Name DO[0:7] ISO_GND Output Isolated digital output signals ISO_COM ISO_GND Output Isolated COM Voltage of DO/DI ISO_GND Isolated ground Max. channel sink current: ISO12V – 20mA ISO5V – 24mA EAC PRO-IK90 EMBEDDED COMPUTER...
Page 29 DC Jack The optional DC power supply connector of the EAC PRO-IK90 Embedded Computer is on the front panel. The optional DC power input for the EAC PRO-IK90 allows a voltage input from 9-36 V DC. Pin № Signal Name Pin №...
Page 30: Motherboard Connectors
USER MANUAL CHAPTER 2 HARDWARE INSTALLATION 2.1.2 Motherboard Connectors 2.1.2.1 Motherboard Connectors IK90 Top Layer (CPU Side, Top View) IK90 Motherboard Bottom Layer (IO Side, Top View) EAC PRO-IK90 EMBEDDED COMPUTER...
Page 31 CLOSED and pin 3 is OPEN. If you remove the jumper cap, the jumper is OPEN. PIN1-2 CLOSED PIN3 OPEN 2.1.2.2.1 Motherboard Jumper List The table below lists all the jumpers located on the motherboard. Label Function CLR_CMOS Clear CMOS CLR_RTC Clear RTC EAC PRO-IK90 EMBEDDED COMPUTER...
Page 32 1-2 closed. Pin № Function 1-2 (Default) Normal Clear RTC CAUTION Shut down your computer and unplug the power cord from the power supply before setting Clear CMOS. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 33: I/O Board
USER MANUAL CHAPTER 2 HARDWARE INSTALLATION 2.1.3 I/O Board IO Board Top Side (IO Side, Top View) IO Board Bottom Side (BTB side, Top View) EAC PRO-IK90 EMBEDDED COMPUTER...
Page 34: Backplane Board Connectors
USER MANUAL CHAPTER 2 HARDWARE INSTALLATION 2.1.4 Backplane Board Connectors BP1 Board Top Side (Top View) *PCIE PEG x16 Slot (CN1) depends on SKU1 or SKU2. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 35 USER MANUAL CHAPTER 2 HARDWARE INSTALLATION BP1 Board Bottom Side (Top View) EAC PRO-IK90 EMBEDDED COMPUTER...
Page 36 When you install PCIe card it is required to change Jumper: PCIe x16, PCIe x8 (JP1) settings. Pin № CN1 (PCIE x16) CN2 (PCIE x8) 2.2.4.2.2 Jumper ISO_COM (JP7) Pin № Signal Name Internal isolation DC12V Internal isolation DC5V EAC PRO-IK90 EMBEDDED COMPUTER...
Page 37: Hardware Installation
USB, COM port and optional expansion module in the system. 2.2.1 SATA HDD Installation Follow the instruction below to install SATA HDD. 1. Loosen a thumbscrew on the front panel by hand. 2. Withdraw thumbscrew and open the SATA HDD cover. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 38 3. Replace the SATA HDD. Reverse procedures to restore the unit. HDD LED Indicators When you install SATA HDD disk, the corresponding LED light located on the front side of the EAC PRO-IK90 will light up green. SSD/ HDD LED Indicator Internal...
Page 39: Pci/ Pcie Card Installation
HARDWARE INSTALLATION 2.2.2 PCI/ PCIe Card Installation EAC PRO-IK90 Embedded Computer has four slots for PCI/ PCIe card. Follow instructions below to install PCI/PCIe card. 1. Loosen two thumbscrews on the front panel by hand and remove the top cover.
Page 40 If your PCI/PCIe power consumption is more than 30W, you need you use AC Adapter 12V/220W (Optional accessory, not included in the standard packing list). IMPORTANT: Before recovery, remove the PCI/ PCIe card and CFast card. Hotkey for recovery “Tab+F6”. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 41 Use Cable Ties to Fix the PCI/PCIe Card to Enhance Vibration and Shock Resistance 1. Loosen six screws on the right side cover. 2. Loosen a thumbscrew to open the top cover. 3. Insert PCI/PCIe card. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 42 5. Reassemble the right side and top covers. Jumper Settings When installing PCIe card , you need to change JP1 jumper settings located on the Backplane Board. Refer to Ch. 2, 2.1.1.3 PCIe of this User manual for more details on jumper settings. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 43: Inserting A Cfast Card
CHAPTER 2 HARDWARE INSTALLATION 2.2.3 Inserting a CFast Card The EAC PRO-IK90 Embedded Computer provides external CompactFlash socket to accommodate a CF card. 1. Loosen two screws on the front side and remove the external CF socket cover. 2. Align the internally mounted CF card with the guide of the internal CF socket and insert the card until it is firmly seated in the external CF socket.
Page 44: Expansion Module (Preliminary)
CHAPTER 2 HARDWARE INSTALLATION 2.2.4 Expansion Module (Preliminary) EAC PRO-IK90 Embedded Computer supports two kinds of optional modules for different applications. Notice that Expansion Module is an optional feature and may not be present in your device. 1. Loosen two hand-turn screws and open the top cover.
Page 45: External Antenna Installation
CHAPTER 2 HARDWARE INSTALLATION 2.2.5 External Antenna Installation The EAC PRO-IK90 Embedded Computer is equipped with SMA Connector for additional external antenna (WLAN or WWAN). To install the Antenna please perform the following: 1. Remove the rubber cap on the SMA connector before installing the antenna.
Page 46 HARDWARE INSTALLATION 2. Insert a memory card to the DDR4-SODIMM (J2/ J4) located on the IK90 Motherboard. ANT1 ANT2 WLAN WIFI MAIN WIFI AUX WWAN WWAN MAIN WWAN AUX WLAN + WWAN WIFI MAIN WWAN MAIN EAC PRO-IK90 EMBEDDED COMPUTER...
Page 47: Connecting The Power
Connect the EAC PR-IK90 either to AC power or DC power. Do not perform both connections at the same time. 2.3.1 Connecting to AC Power Use AC Adapter (12V/ 220W) included in the package to connect EAC PRO-IK90 to 9-36V power source. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 48: Connecting To Dc Power
USER MANUAL CHAPTER 2 HARDWARE INSTALLATION 2.3.2 Connecting to DC Power Connect open wire cable (not supplied by Winmate) to 9-36V DC, maximum power source 220W. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 49: Power Consumption Reference
EAC PRO-IK90 /7 CPU i7-6700TE Power Off Idle mode Full Load Power consumption (W) 32.16 * With internal Graphics ,not include other device. IMPORTANT: Please evaluate the extra to join USB Device Power consumption/SATA HDD Power consumption(Max.). EAC PRO-IK90 EMBEDDED COMPUTER...
Page 50: Dido Installation
To install isolated Digital Input: 1. Check DI/DO voltage level, to set JP7 to select 5V or 12V. 2. Connect Push Button between DIx and ISO_GND. 3. Check the DI signal go to Low when Push Button pressed. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 51 HARDWARE INSTALLATION To install isolated Digital Output: 1. Check DI/DO voltage level, to set JP7 to select 5V or 12V. 2. Connect Load Circuit between DOx and ISO_COM. 3. Set DO signal to Low to active LED. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 52: Smart Fan
When sensor cheap reaches the temperature of 65 degree, smart fan turns off. You can check Smart Fan settings in BIOS.Go to Advanced > PC Health Status When FAN2 turn off, the value shows 0RPM. When FAN2 turn on, the value shows FAN RPM. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 53 UEFI BIOS SETUP BIOS Setup Utility is a program for configuration basic Input / Output system settings of the computer for optimum use. This chapter provides information on how to use BIOS setup, its functions and menu. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 54: Chapter 3: Uefi Bios Setup
Exit Change Opt. Enter Select or execute command Cursor ↑ Moves to the previous item Cursor ↓ Goes to the next item Cursor ← Moves to the previous item Cursor → Goes to the next item EAC PRO-IK90 EMBEDDED COMPUTER...
Page 55: Bios Functions
RC version, system language, time, and date. When you enter BIOS setup, the first menu that appears on the screen is the main menu.It contains the system information including BIOS version, processor RC version, system language, time, and date. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 56: Advanced Settings
CPU Configuration. You can use the <Arrow> keys enter all advanced BIOS setup options. The advanced BIOS setup menu is shown below. The submenus described on the following pages. CAUTION Handle advanced BIOS settings page with caution. Any changes can affect the operation of your computer. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 57 Opens submenu settings SATA Configuration Configures SATA Enter Opens submenu parameters Network Stack Configures Enter Opens submenu Configuration Network Stack parameters CSM Configuration Configures CSM Enter Opens submenu parameters USB Configuration Configures USB Enter Opens submenu parameters EAC PRO-IK90 EMBEDDED COMPUTER...
Page 58 Schedule an None No operation scheduled Operation operation for the TPM Clear Schedule TMP Clear for security device. the security device Note: Your computer will reboot during restart in order to change state of the device. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 59 Select the TMP TPM1.2 TPM1.2 will restrict device. support to TPM1.2 devices TPM2.0 TPM2.0 will restrict support to TPM2.0 devices Auto Auto will support both with the default set to TPM2.0 if not found, TPM1.2 will be enumerated EAC PRO-IK90 EMBEDDED COMPUTER...
Page 60 Use this item to Enable/ Disable Enables/ Disables Screen enable or disable MEBx selection the MEBx Selection screen Screen. Hide Un-Configure Configure Hide Un- Enable/ Disable Hide Un-Configure ME Confirmation Configure ME ME without Confirmation Password parameters. confirmation EAC PRO-IK90 EMBEDDED COMPUTER...
Page 61 Use this function to Enable/ Disable Enables or disables enable or disable this function PET events progress to receive PET events or not Watchdog Enables or disables Enable/ Disable Enables or disables Watchdog Timer this function EAC PRO-IK90 EMBEDDED COMPUTER...
Page 62 1.2 disables Selection device PTT in SkuMgr Enables PTT in SkuMgr WARNING! PTT/ dTMP will be disabled and all data saved on it will be lost Firmware Update Use this item to Configuration control firmware update configuration EAC PRO-IK90 EMBEDDED COMPUTER...
Page 63 Output Low Set Output Low for a DO Port 0~7 Output High Set Output High for a DO Port 0~7 Watch Dog Timer Set parameters of Enabled/ Disabled Enables/ Disables Select Watch Dog Timer. Watch Dog Timer. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 64 A watchdog is a Disabled Disables Watch Dog device used to Timer protect a system 1~10 min Set Watch Dog from specific timer for 1~10 min software or hardware failures that may cause the system to stop responding. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 65 Hardware Monitor is a hardware monitoring program that reads PC systems main health sensors:  CPU temperature, voltage, power consumption and utilization.  Mainboard voltages, temperatures, fans speed.  GPU voltage, temperature, utilization.  HDD temperature. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 66 3.2.2.6 Serial Port Console Redirection BIOS Setting Description Setting Option Effect COM0~COM5 Use this item to Enabled/ Enables or disables enable or disable Disabled console redirection console redirection to the serial port to the serial port EAC PRO-IK90 EMBEDDED COMPUTER...
Page 67 Technology). When disabled only one thread per enabled core is enabled Intel Virtualization When enabled Enabled/ Use this item to Technology VMM can utilize Disabled enable or disable the additional Intel Virtualization hardware Technology capabilities provided by EAC PRO-IK90 EMBEDDED COMPUTER...
Page 68 RAID-0 through RAID-6, and each with different configurations of the hard drive. Serial ATA Allows users to enable or Enabled/ Set required configuration Port 0/1/2 disable the SATA Port Disabled EAC PRO-IK90 EMBEDDED COMPUTER...
Page 69 USER MANUAL CHAPTER 3 UEFI BIOS SETUP 3.2.2.9 Network Stack Configuration BIOS Setting Description Setting Option Effect Network Stack Allows users to Enabled/ Enables or disables enable or disable Disabled UEFI Network Stack UEFI Network Stack EAC PRO-IK90 EMBEDDED COMPUTER...
Page 70 3.2.2.10 CSM Configuration You can choose either UEFI or LEGACY mode. IMPORTANT: Please make the same settings for all the items below (Network, Storage, Video, Other PCI devices). Please also change Boot settings to the chosen mode. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 71 OpROM execution execution policy for devices of devices other other than than Network, Network, Storage, Storage, or Video or Video UEFI Launch execution of UEFI other devise OpROM Legacy Launch execution of Legacy other devise OpROM EAC PRO-IK90 EMBEDDED COMPUTER...
Page 72 USER MANUAL CHAPTER 3 UEFI BIOS SETUP 3.2.2.11 USB Configuration EAC PRO-IK90 EMBEDDED COMPUTER...
Page 73 Floppy Optical drives are emulated as Floppy Forced FDD Optical drives are emulated as Forced FDD Hard Disk Optical drives are emulated as Hard Disk CD-ROM Optical drives are emulated as CDROM EAC PRO-IK90 EMBEDDED COMPUTER...
Page 74: Chipset Menu
USER MANUAL CHAPTER 3 UEFI BIOS SETUP 3.2.3 Chipset Menu EAC PRO-IK90 EMBEDDED COMPUTER...
Page 75 Allows users to enable or disable VT-d. BIOS Setting Description Setting Option Effect Graphics Configure Graphics Enter Opens submenu Configuration settings PEG Port Configure PEG Port Enter Opens submenu Configuration settings Memory Configure Memory Enter Opens submenu Configuration settings EAC PRO-IK90 EMBEDDED COMPUTER...
Page 76: Graphics Configuration
USER MANUAL CHAPTER 3 UEFI BIOS SETUP 3.2.3.1.1 Graphics Configuration EAC PRO-IK90 EMBEDDED COMPUTER...
Page 77 Internal Device Graphics Device Select DVMT 5.0 Select DVMT 5.0 Total Graphic Total Graphic DVMT Total Gfx Memory size used 128M, 256M, MAX Memory size used by the Internal by the Internal Graphic Device Graphic Device EAC PRO-IK90 EMBEDDED COMPUTER...
Page 78 USER MANUAL CHAPTER 3 UEFI BIOS SETUP 3.2.3.1.2 PEG Port Configuration 3.2.3.1.3 Memory Configuration EAC PRO-IK90 EMBEDDED COMPUTER...
Page 79 S0 State is pre- Specify which state S0 State applied after a power failure to go when power is State After G3 pre-applied after a S5 stae is pre- power failure S5 State applied after a power failure EAC PRO-IK90 EMBEDDED COMPUTER...
Page 80 BIOS Setting Description Setting Option Effect Selectively Enable Disable this Disable or Disable the function USB Port Disable corresponding USB Override port from reporting Select Per Pin Select Per Pin a Device Connection to the controller EAC PRO-IK90 EMBEDDED COMPUTER...
Page 81 Configure RTC Lock 128-byte bank of RTC Lock parameters RTC RAM Disable this Disable function Enable/ Disable the PCH BIOS Lock Enable/ Enable or disable BIOS Lock Enable (BLE bit) Disable this function feature EAC PRO-IK90 EMBEDDED COMPUTER...
Page 82: Boot Menu
BIOS use to look for a boot device from which to load the operating system. IMPORTANT: Make sure that Boot mode select setting is the same as settings of Configuration EAC PRO-IK90 EMBEDDED COMPUTER...
Page 83 CD/DVD, USB Key, UEFI AP Disable Disable Boot UEFI USB Key Drive Configure UEFI USB Enter Opens sub-menu BBS Priorities Key Drive BBS Priorities parameters UEFI Application Configure UEFI Enter Opens sub-menu Boot Priorities Application Boot Priorities parameters EAC PRO-IK90 EMBEDDED COMPUTER...
Page 84 USER MANUAL CHAPTER 3 UEFI BIOS SETUP 3.2.4.1 Hard Disk Drive BBS Priorities EAC PRO-IK90 EMBEDDED COMPUTER...
Page 85 USER MANUAL CHAPTER 3 UEFI BIOS SETUP 3.2.4.2 USB Key Driver Boot Priorities EAC PRO-IK90 EMBEDDED COMPUTER...
Page 86: Security Menu
BIOS Setting Description Setting Option Effect Administrator Set Administrator Enter Enter password Password password User Password Set User password Enter Enter password Secure Boot Menu Configure Secure Enter Opens sub-menu Boot menu parameters EAC PRO-IK90 EMBEDDED COMPUTER...
Page 87 Standard Disables users to Selector change Image Execution policy and manage Secure Boot Keys Custom Enables users to change Image Execution policy and manage Secure Boot Keys Key Management Configure Key Enter Opens sub-menu Management parameters EAC PRO-IK90 EMBEDDED COMPUTER...
Page 88: Key Management
USER MANUAL CHAPTER 3 UEFI BIOS SETUP 3.2.5.1.1 Key Management EAC PRO-IK90 EMBEDDED COMPUTER...
Page 89: Using Recovery Wizard To Restore Computer
Yes to continue. 5. Wait the recovery process to complete. During the recovery process, a command prompt will show up to indicate the percent of recovery process complete. The system will restart automatically after recovery completed. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 90: How To Enable Watchdog
UEFI BIOS SETUP 3.4 How to Enable Watchdog To enable Watchdog, you need to download Winmate Watchdog utility. Find more information on Watchdog in “Watchdog Guide” that you can download from Winmate Download Center or File Share. Refer to the User Manual for more details.
Page 91 The system automaticity restarts when this countdown time reaches zero. Watchdog Countdown Time Default: 10 min To set a cycle time to automatically reset watchdog timer. Periodically Feed Time Default: 9 min Enable or disable watchdog. Enable / Disable Default: Enable EAC PRO-IK90 EMBEDDED COMPUTER...
Page 92: Driver Installation
USER MANUAL CHAPTER 4 DRIVER INSTALLATION DRIVER INSTALLATION This chapter provides instructions on how to install drivers on the EAC PRO-IK90 Embedded Computer. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 93: Chapter 4: Driver Installation
USER MANUAL CHAPTER 4 DRIVER INSTALLATION CHAPTER 4: DRIVER INSTALLATION This chapter provides instructions on how to install drivers on the EAC PRO-IK90 Embedded Computer. 4.1 Chipset Driver Follow instructions below to install Chipset driver. 1. Open the Driver CD (included in the package) and select Chipset driver.
Page 94 USER MANUAL CHAPTER 4 DRIVER INSTALLATION 3. Select Accept to agree with the terms of license agreement. 4. Check the ReadMe file information, select Install to continue. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 95 USER MANUAL CHAPTER 4 DRIVER INSTALLATION 5. Wait for the driver to be installed. 6. When installation completed, select Restart Now to restart your computer. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 96: Graphic Driver
7. Again select the ME to continue installation. Select Next. 8. Please check the license agreement, and then select Next. 9. Select Next to start the installation. 10. Wait for the driver to be installed. 11. When installation completed, select Finish complete installation. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 97: Audio Driver
4. Confirm the installation, select Install to start the installation. 5. Select Next to continue. 6. Select Next to start the installation. 7. Wait for installation to complete. 8. Warning message will pop up, select Install. EAC PRO-IK90 EMBEDDED COMPUTER...
Page 98: Microsoft .Net Framework Driver
3. Read the license agreement, and then select “I agree”. 4. Wait for installation to complete. 5. When installation is completed, select Finish to close the window. 4.8 WatchDog Driver For more details about Winmate Watchdog, please download Watchdog Guide from Winmate Downloads Center: http://dc.winmate.com.tw/_downloadCenter/2017/Embedded%20Computing/Watchdo g%20Guide_IB_IH_IV_IK.pdf Follow instructions below to install Watchdog driver.
Page 99: Technical Support
USER MANUAL CHAPTER 5 TECHNICAL SUPPORT TECHNICAL SUPPORT This chapter includes pathway for technical support and Software Development Kit (SDK). EAC PRO-IK90 EMBEDDED COMPUTER...
Page 100: Chapter 5: Technical Support
Winmate Download Center http://www.winmate.com/ > Support > Download Center > Embedded Computing > EAC PRO-IK90 Winmate File Share http://www.winmate.com/ > Support > Download Center >Public Documents > Embedded Computing > EAC PRO-IK90 Or follow the link below: https://winmate.box.com/v/Winmate-EAC-PRO EAC PRO-IK90 EMBEDDED COMPUTER...
Page 101: Problem Report Form
________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ _______________________________________________________________________ EAC PRO-IK90 EMBEDDED COMPUTER...
Page 102: Ordering Information
USER MANUAL APPENDIX A ORDERING INFORMATION ORDERING INFORMATION This section includes EAC PRO-IK90 Embedded Computer ordering information. Appendix EAC PRO-IK90 EMBEDDED COMPUTER...
Page 103: Appendix A: Ordering Information
USER MANUAL APPENDIX A ORDERING INFORMATION APPENDIX A: ORDERING INFORMATION EAC PRO-IK90 Embedded Computer available in the following configurations: Item Specifications  EAC PRO-IK90/E Intel® Xen E3-1268L V5  EAC PRO-IK90/7 Processor Intel® Core™ i7-6700TE  EAC PRO-IK90/3 Intel® Core™ i3-6100TE...
