Page 2: Floorplan
Step 60" x 80" Well Pantry Pull Out Wardrobe Table Slideout Side-By-Side Plank Standard Vinyl Refrig/Freezer Note: Dimensions shown are for Floorcovering Floorcovering sleeping space only and dashed lines denote overhead storage areas. FLOORPLAN Copyright © 2006 Winnebago Industries Inc.
Page 3: Table Of Contents
CABINETS ..........................................54 DOORS & DRAWERS ......................................55 SHOWER ..........................................56 COMPONENT PARTS FOR SHOWER .................................. 57 132340-01-01A ........................................57 BEDROOM GROUP ............................. 58 QUEEN CABINETS ........................................ 58 QUEEN DOORS & DRAWERS ....................................60 Copyright © 2006 Winnebago Industries Inc.
Page 4 CABINETS ..........................................108 DOORS & DRAWERS ......................................109 TABLE ........................................... 110 DRIVERS COMPARTMENT GROUP ......................112 INSTRUMENT PANEL ......................................112 DASH ............................................. 112 MOTOR COVER ........................................114 FRONT INTERIOR ......................................... 116 CABINETS ..........................................119 Copyright © 2006 Winnebago Industries Inc.
Page 5 EXTERIOR SLIDEOUT GROUP ......................... 165 FRONT LEFT ........................................165 COMPONENT PARTS FOR FRONT LEFT ................................169 100536-42-000 ........................................169 132540-01-000 ........................................169 RIGHT REAR ........................................170 COMPONENT PARTS FOR RIGHT REAR ................................174 128599-05-000 ........................................174 Copyright © 2006 Winnebago Industries Inc.
Page 6 COMPONENT PARTS FOR DRAINAGE SYSTEM ............................. 266 062415-01-000 ........................................266 134789-01-01A ........................................266 WATER SYSTEM ........................................267 COMPONENT PARTS FOR WATER SYSTEM ..............................274 051391-05-000 ........................................274 098607-01-000 ........................................275 131340-01-01A ........................................275 135027-01-01A ........................................276 Copyright © 2006 Winnebago Industries Inc.
Page 7 129929-10-01A ........................................290 134004-02-01A ........................................291 134004-03-01A ........................................292 WINDSHIELD & WIPER GROUP ....................... 293 WINDSHIELD ........................................293 WIPER ..........................................294 COMPONENT PARTS FOR WIPER ..................................295 095964-01-000 ........................................295 096505-09-000 ........................................295 117769-01-000 ........................................295 Copyright © 2006 Winnebago Industries Inc.
Page 8: Accessories Group
ACCESSORIES GROUP OPERATORS MANUAL KEY PART NUMBER U/M DESCRIPTION 129079-01-01A EA CASE - VINYL/BLACK-EXPANDABLE ACCORDION SIDES-7"WX9"HX14"L 132000-06-001 EA MANUAL/OWNER - ADVENTURER - 2001 134865-01-000 DW TOP LEVEL-G, 2001 Copyright © 2006 Winnebago Industries Inc.
Page 9: Appliance Group
EA HAIR DRYER - 3 SPEED W/NIGHT LIGHT - WALL MOUNT 133139-01-000 EA VACUUM CLEANER - RECHARGEABLE DUST-BUSTER - BLACK & DECKER 133140-01-000 EA FLASHLIGHT - RECHARGEABLE - BLACK & DECKER *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 10 EA INSERT/REFRIGERATOR DOOR - 21.6" X 38.6" - BLACK ACRYLIC FROM: 07-31-00 THRU: 99-99-99 054450-01-000 EA LEVEL - REFRIGERATOR 090329-01-000 FT SEAL/T - REFRIGERATOR CABINET 116751-05-01A EA TRAY - REFRIGERATOR - BLACK *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 11 EA INSERT/REFRIGERATOR DOOR - 16.8" X 55.1" - BLACK ACRYLIC FROM: 08-21-00 THRU: 99-99-99 054450-01-000 EA LEVEL - REFRIGERATOR 090329-01-000 FT SEAL/T - REFRIGERATOR CABINET 118871-06-01A EA TRAY - REFRIGERATOR SIDE / SIDE - BLACK *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 12 EA WASHER - DRYER - VENTED - UL/CSA - WHITE 111913-01-01A EA BRACKET - WASHER - TIE DOWN 113795-01-02B EA BRACKET - WASHER - E-COATED 113795-02-02B EA BRACKET - WASHER - E-COATED 134270-01-01A EA BAG - SHOE (WASHER / DRYER) INSTALLATION Copyright © 2006 Winnebago Industries Inc.
Page 13: Component Parts For Appliance
APPLIANCE GROUP (CONTINUED) COMPONENT PARTS FOR APPLIANCE 115504-01-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 115504-01-700 EA PLUG & CABLE, 10 WATT PANEL 600-016 118367-02-01A Copyright © 2006 Winnebago Industries Inc.
Page 14 293 20 94-02/8 118367-02-704 EA CONTROL - RIGHT 293 24 07-01/4 118367-02-705 EA CONTROL - LEFT 293 24 07-02/2 CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT 118367-02-706 EA SHELF - DOOR 293 25 77-02/2 118367-02-707 EA SHELF - DOOR 293 25 83-03/8 118367-01-707 EA DECORATION-DOOR, REFRIG.
Page 16 293 04 87-00/0 118367-02-718 EA STRIP - FRONT - LOWER 293 26 64-03/6 118367-02-719 EA SWITCH 293 26 80-02/4 118367-02-720 EA COIL - FREEZER 293 20 74-01/2 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 17 118367-01-761 EA RACK-LOWER 200 73 37-16/1 118367-01-762 EA RETAINER-RACKS 293 06 93-04/5 118367-02-738 EA RACK 200 73 37-19/5 118367-02-739 EA SHELF - GRATED 293 20 49-01/4 118367-02-740 EA SHELF - GRATED 293 20 79-01/1 Copyright © 2006 Winnebago Industries Inc.
Page 19: 119267-04-01A
KEY PART NUMBER U/M DESCRIPTION VENDOR NO 118367-02-01A EA REFRIGERATOR - SIDE BY SIDE - W/ICE MAKER - 12 VOLT 2-WAY CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT 118367-01-764 EA CONDUCTOR-ELECTRODE 200 76 68-04/5 CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT...
Page 20: 120075-13-01A
121568-01-700 EA RAIL - DOOR UPPER 618618 120075-07-700 EA DOOR BIN - CLEAR 619006 120075-07-701 EA DIVIDER/DOOR BIN CLEAR 619008 121568-03-704 EA TRAVEL LATCH - GRAY 619647 121568-03-705 EA STORAGE LATCH - GRAY 619648 Copyright © 2006 Winnebago Industries Inc.
Page 22 120075-07-700 EA DOOR BIN - CLEAR 619006 120075-07-704 EA DOOR BIN - LARGE/CLEAR 619005 120075-07-701 EA DIVIDER/DOOR BIN CLEAR 619008 121568-03-704 EA TRAVEL LATCH - GRAY 619647 121568-03-705 EA STORAGE LATCH - GRAY 619648 Copyright © 2006 Winnebago Industries Inc.
Page 23 EA COVER - HINGE HOLES 619301 120075-01-729 EA TRIM-BOTTOM PIECE 618136 120075-01-730 EA RETAINER-SHELF 618181 121568-03-717 EA HOLE PLUG - WHITE 619561 120075-01-732 EA PLATE-STRIKE 618167 120075-09-700 EA CABINET - FOAMED 619660 120075-01-721 EA LOUVER-DRIP TRAY 618176 Copyright © 2006 Winnebago Industries Inc.
Page 24 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 084880-01-760 EA CLIP (THERMISTER) 61689122 120075-01-735 EA THERMISTER W/LAMP & WIRE/ASM 618548 084880-03-705 EA BRACKET-LIGHT-INTERIOR 61629722 084880-03-706 EA BULB-LAMP 61628922 120075-01-734 EA COVER-LENS 618190 084880-03-707 EA COVER-LAMP, LENS 61627922 Copyright © 2006 Winnebago Industries Inc.
Page 25 APPLIANCE GROUP (CONTINUED) COMPONENT PARTS FOR APPLIANCE (CONTINUED) 120075-13-01A (CONTINUED) KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 088248-01-710 EA HEATER DC (HORIZONTAL) 61562822 120075-01-736 EA COOLING UNIT, SERVICE PACK 618542 088248-01-709 EA HEATER-AC (HORIZONTAL) 61562722 Copyright © 2006 Winnebago Industries Inc.
Page 26 EA TUBE-UNION 61694622 084880-01-718 EA VALVE-GAS, (ASCO) 61551822 120075-01-738 EA COVER-POWER BOARD 618185 120075-07-710 EA POWER - BOARD - 2-WAY 619360 104137-06-734 EA VALVE-SHUT OFF/MAN-NEW STYLE 618696 120075-01-744 EA KIT - GAS VALVE/BURNER TUBE 620609 Copyright © 2006 Winnebago Industries Inc.
Page 27 EA NUT/COMPRESSION - FITTING 61678722 120075-03-703 EA ARM-SHUT OFF 61656922 120075-03-704 EA BIN-ICE CUBE 618154 094039-07-706 EA ICE MAKER W/O PLATES 61656522 120075-01-717 EA SHELF-FREEZER, WIRE 618172 120075-09-702 EA RELAY - 12 VOLT 620239 Copyright © 2006 Winnebago Industries Inc.
Page 28: 121569-05-01A
620960 120075-01-705 EA HINGE-TOP LH/BOTTOM RH(DOOR) 618510 121568-01-700 EA RAIL - DOOR UPPER 618618 120075-07-700 EA DOOR BIN - CLEAR 619006 120075-07-701 EA DIVIDER/DOOR BIN CLEAR 619008 121568-03-705 EA STORAGE LATCH - GRAY 619648 Copyright © 2006 Winnebago Industries Inc.
Page 29 620960 121568-01-704 EA RAIL - DOOR LOWER 618578 120075-01-705 EA HINGE-TOP LH/BOTTOM RH(DOOR) 618510 121568-01-701 EA BIN - DOOR WHITE 618619 120075-07-701 EA DIVIDER/DOOR BIN CLEAR 619008 121568-03-705 EA STORAGE LATCH - GRAY 619648 Copyright © 2006 Winnebago Industries Inc.
Page 30 618136 120075-01-730 EA RETAINER-SHELF 618181 121568-03-717 EA HOLE PLUG - WHITE 619561 120075-01-732 EA PLATE-STRIKE 618167 120075-07-709 EA CABINET - FOAMED 619347 120075-01-721 EA LOUVER-DRIP TRAY 618176 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 31 VENDOR NO. 084880-01-760 EA CLIP (THERMISTER) 61689122 120075-01-735 EA THERMISTER W/LAMP & WIRE/ASM 618548 084880-03-705 EA BRACKET-LIGHT-INTERIOR 61629722 084880-03-706 EA BULB-LAMP 61628922 084880-03-707 EA COVER-LAMP, LENS 61627922 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 32 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 120075-01-736 EA COOLING UNIT, SERVICE PACK 618542 088248-01-709 EA HEATER-AC (HORIZONTAL) 61562722 120075-01-744 EA KIT - GAS VALVE/BURNER TUBE 620609 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 33: 126019-01-01A
121568-03-719 EA POWER - BOARD - 2-WAY 619353 121568-03-720 EA VALVE/SHUT OF-MANUAL ELECT. 618696 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS 126019-01-01A KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 126019-01-01A EA COFFEEMAKER - OPTIMA - W/BRACKETS - BLACK & DECKER BLK&DKR #ODC150...
Page 34: 133004-02-01A
L1008-00 133004-01-705 EA SWITCH/SPNO MOM ON-OFF PUSH L0950-00 133004-01-703 EA LED - RED - PANEL MOUNT L1009-00 133004-01-701 EA SWITCH/DPDT ON-ON/MAINTAINED L1025-00 133004-02-701 EA SCREENED - CHASSIS CC0547-00 133004-02-700 EA BOARD - PC L5113-03 Copyright © 2006 Winnebago Industries Inc.
Page 35: 135065-01-01A
COMPONENT PARTS FOR APPLIANCE (CONTINUED) 135065-01-01A KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 135065-01-01A EA RANGE - 3 BURNER W/O OVEN - SEALED BURNERS - BLACK TOP CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT 102020-01-709 EA BUMPER-GRATE 8007-P020-60 128728-01-700 EA GRATE - BURNER 74003948...
Page 36 EA REGULATOR - PRESSURE 74004235 135065-01-703 EA VALVE/BURNER - REAR 74004643 135065-01-704 EA VALVE/BURNER - FRONT 74004644 135065-01-705 EA BURNER/SEALED ASSEMBLY 74003967 128728-01-716 EA BURNER - IGNITOR 74003946 128728-01-717 EA WIRES - IGNITOR 74003947 Copyright © 2006 Winnebago Industries Inc.
Page 38 EA PILOT - OVEN 74004586 126023-02-702 EA PIPE - MANIFOLD 74004360 126023-02-703 EA REGULATOR - PRESSURE 74004235 CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT 102020-01-724 EA BUMPER-MAIN TOP 8003P008-60 126023-01-734 EA THERMOSTAT OVEN 11/CLY MODEL 74004361 128728-01-705 EA TOP - MAIN - BLACK...
Page 39 74001190 102020-01-701 EA HANDLE,DOOR 7701P092-60 CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT...
Page 40 74003998 126023-01-731 EA BOTTOM - OVEN 2205F016-19 126023-01-718 EA FLUE BOX ASSEMBLY 4006W075-80 4 THRU 5 CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT 126023-01-713 EA TRIM - SIDE (RIGHT) 74002827 126023-01-714 EA TRIM - SIDE (LEFT) 74002828 7 THRU 9...
Page 41: Audio Video Group
EA CONTROL - VOLUME - SPEAKER 128074-02-000 EA FILTER - NOISE - 12 VOLT DC W/PLUGS 136053-01-000 EA FILTER - NOISE - AUDIO FROM: 00-00-00 THRU: 06-29-00 *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 42: Component Parts For Radio System
102080-15-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 102080-15-700 EA REMOTE 1-476-488-11 127517-05-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 127517-05-000 EA RADIO - AM/FM STEREO/CD PLAYER - SONY CDX-C4005X 127517-05-700 EA REMOTE-WIRED RMX4S Copyright © 2006 Winnebago Industries Inc.
Page 43: Rear View Monitor
EA SPEAKER - 4" - 2 WATT - 8 OHM 114870-01-000 EA PLUG - AUDIO W/LEADS - 48.5" 133989-01-12B EA BRACKET - CAMERA - MONITOR/REAR - BRIGHT WHITE *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 44: Component Parts For Rear View Monitor
AUDIO VIDEO GROUP (CONTINUED) COMPONENT PARTS FOR REAR VIEW MONITOR 093040-10-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 093040-10-000 EA MONITOR - 7" REAR VIEW - W/BRACKET - SONY 093040-10-700 EA LENS-MONITOR, REAR VIEW F/7" 3-708-537-01 Copyright © 2006 Winnebago Industries Inc.
Page 45: Telephone System
FROM: 05-29-00 THRU: 05-06-01 126697-07-000 EA VCR - VHS/CABLE READY - W/REMOTE - GE VG4045 - W/O DELUXE SOUND FROM: 05-07-01 THRU: 99-99-99 134006-01-03B EA PLATE - COAXIAL CABLE/OFF WHITE *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 46: Component Parts For Tv & Vcr
EA BASE PLATE 3100523 076319-01-703 EA BEARING - NYLON - 5"OD 3200656 076319-01-714 EA HOUSING - ROTATING GEAR 2200049 076319-01-716 EA TUBING, ELEVATING RP-2900 076319-01-704 EA BEARING-NYLON, 1.25"OD 3200657 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENT Copyright © 2006 Winnebago Industries Inc.
Page 47 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 086231-10-000 EA TV - 13" COLOR - AUDIOVOX AVT-1498/DC AUDIOVOX AVT-1498 086231-08-700 EA REMOTE-UNIVERSAL 892325 086231-08-701 EA CONVERTER/POWER SUP 110/12 V 891436 086231-10-700 EA ADAPTER WIRE - (CIGARETTE) 894000 Copyright © 2006 Winnebago Industries Inc.
Page 49 EA VCR/VHS - CABLE READY - REMOTE GE VG4052 126697 05 700 EA REMOTE 238861 126697-06-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 126697-06-000 EA VCR/VHS - CABLE READY - REMOTE GE VG4052 126697-06-700 EA REMOTE 248791 Copyright © 2006 Winnebago Industries Inc.
Page 50 EA TV - 25" - STEREO W/5 JACKS - RCA F25648 130121-05-700 EA REMOTE 242524 133377-01-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 133377-01-000 EA TV - 25" - STEREO W/5 JACKS - RCA F25648 133377-01-700 EA REMOTE 240961 Copyright © 2006 Winnebago Industries Inc.
Page 52 120233-01-704 EA DIAL - DIRECTIONAL 3200364 120233-01-721 EA CRANK HANDLE ASSEMBLY 2762825 137135-01-701 EA CONNECTOR - F - MALE TO MALE FS-8100 137135-01-700 EA ROOF WEDGE W/GASKET RW-5000 137135-01-718 EA REFLECTOR/WHITE - 46CM 2745282 Copyright © 2006 Winnebago Industries Inc.
Page 53: Exterior Entertainment
EA BOX - ENTERTAINMENT CENTER/EXTERIOR - BRIGHT WHITE 127409-02-L15 EA PLATE - RADIO MOUNTING 104898-01-02A EA PLATE - PLASTIC BOTTOM - BRIGHT WHITE 105230-01-J01 EA SHELF - EXTERIOR ENTERTAINMENT CENTER - W/BRKT/HINGE/SUPT NOT USED Copyright © 2006 Winnebago Industries Inc.
Page 54: Bath Group
M09366-01-M42 EA DOOR/PANEL - SLIDING - W/PULL 103868-15-01A EA TRACK - SLIDING DOOR - 76" - OFF WHITE 130806-01-M42 EA HEADER - DOOR 132533-01-01A EA HOLDER - TOILET PAPER - EURO STYLE - BRASS Copyright © 2006 Winnebago Industries Inc.
Page 55: Doors & Drawers
EA LOCK - PRIVACY/LOCKING - POLISHED BRASS - S SHAPED FROM: 05-29-01 THRU: 99-99-99 100357-01-000 EA ROD - F/TOWEL BAR - BRASS P34509-01-L81 EA RAIL END - RH/LH - TOWEL RACK - PORTSMOUTH OAK Copyright © 2006 Winnebago Industries Inc.
Page 56: Shower
EA SEAT - SHOWER - FOLDING FROM: 00-00-00 THRU: 06-03-01 135607-03-01A EA SEAT - SHOWER/FOLDING FROM: 06-04-01 THRU: 99-99-99 132340-01-01A EA DOOR - FOLDING/SHOWER - 39.2"W X 67.5"T - GOLD/WHITE *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 57: Component Parts For Shower
EA STRIKE ASSEMBLY - 66" 132340-01-700 EA TRACK - (TOP/BOTTOM) - 46.6" 132340-01-707 EA JAMB/WALL - W/MAG STRIKE 66" 5 THRU 10 CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT 108351-01-703 EA BRACKET & ROLLER ASM. SINGLE GRB1 108351-01-704 EA BRACKET & ROLLER ASM. DOUBLE...
Page 58: Bedroom Group
FROM: 00-00-00 THRU: 10-22-00 115466-26-02B EA STRAP - TIEDOWN/TV - E-COATED FROM: 10-23-00 THRU: 99-99-99 135074-13-M42 EA SHELF - W/PLASTIC EDGE MOLDING 132141-C8-M42 EA DOOR - RAIL/VENEER - 25.5" X 15.3" - W/O HARDWARE Copyright © 2006 Winnebago Industries Inc.
Page 59 EA DOOR - MIRRORED/WARDROBE - LEFT HAND - 66" X 20.5" 136680-14-M42 EA DOOR - MIRRORED/WARDROBE-RH-W/HANGARS/GUIDES/LATCH-66"X22.5" 099717-04-000 EA STRAP - W/21.2" FEMALE STRAP AND 27.1" MALE STRAP 113797-09-01A EA STRIP - BLACK PLASTIC W/SELF ADHESIVE - .6" X .12" X 55.7" Copyright © 2006 Winnebago Industries Inc.
Page 60: Queen Doors & Drawers
EA CORNER HANGER (DOUBLE ROLLER W/BRACKET) (SOLD AS 1 EACH) 107391-01-000 EA GUIDE - BOTTOM - BY-PASS (4 USED PER DOOR) 111575-01-01A EA CHANNEL - GLAZING - SWING DOOR 132038-01-01A EA LATCH - DOOR/WARDROBE - TERRATONE Copyright © 2006 Winnebago Industries Inc.
Page 61: Chassis Group
EA GUARD/ROCK - STEEL - W/BEND - 18"W X 14.9"H - E-COATED 132485-23-02B EA PLATE/SEAL - E-COATED 133612-02-02B EA ZEE/SEAL PLANE - BOTTOM - E-COATED FROM: 00-00-00 THRU: 08-06-00 133612-05-02B EA ZEE/SEAL PLANE - BOTTOM - E-COATED FROM: 08-07-00 THRU: 99-99-99 Copyright © 2006 Winnebago Industries Inc.
Page 62 FROM: 03-13-01 THRU: 99-99-99 132607-01-02B EA BOX ASM-ENTRANCE,STEP,E-COAT FROM: 00-00-00 THRU: 08-01-00 132607-06-02B EA BOX ASM-ENTRANCE,STEP,E-COAT FROM: 08-02-00 THRU: 99-99-99 138799-01-02B EA SHIM - BODY - E-COATED *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 63: Component Parts For Frame
CHASSIS GROUP (CONTINUED) COMPONENT PARTS FOR FRAME 132643-01-01A KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 132643-01-700 EA HITCH/RECEIVER WELDED ASM. 72430-47 132643-01-701 EA TIRE CARRIER COMPLETE 56610-47 132643-01-702 EA RETAINER KIT/SPARE TIRE 55290-47 Copyright © 2006 Winnebago Industries Inc.
Page 64: Front End
EA STEP - DRIVER DOOR - BLACK - G35U & G37G WORKHORSE 104409-01-000 EA PLATE - MOUNTING/SIDEWALL FROM: 00-00-00 THRU: 03-28-01 139383-01-02B EA PLATE/MOUNT - SIDEWALL - E-COATED FROM: 03-29-01 THRU: 99-99-99 076364-57-000 EA ANGLE - FORMED Copyright © 2006 Winnebago Industries Inc.
Page 65: Drivetrain
EA STRAP - BEARING - 1480 JOINT - G37G WORKHORSE 138616-01-02B EA BRACKET - BEARING MOUNT - 43 - WORKHORSE - E-COATED - G37G 138616-02-02B EA BRACKET - BEARING MOUNT - 155 - WORKHORSE - E-COATED - G37G Copyright © 2006 Winnebago Industries Inc.
Page 66: Exhaust
EA SHIELD - HEAT/EXHAUST - 19.7" X 29.1" - E-COATED 112012-03-000 EA PIPE - EXHAUST - 3" DIAMETER - G37G 094918-06-000 EA CLAMP - EXHAUST - 3" - HEAVY DUTY - G37G NOT USED NOT USED Copyright © 2006 Winnebago Industries Inc.
Page 67 EA CLAMP - EXHAUST - 3" - GUILLOTINE STYLE 122392-03-02B EA HANGER - TAILPIPE - REAR - E-COATED 094918-01-000 EA CLAMP - EXHAUST - 3" - GUILLOTINE STYLE 122529-02-000 EA PIPE - EXHAUST NOT USED NOT USED NOT USED NOT USED Copyright © 2006 Winnebago Industries Inc.
Page 69 EA HANGER - TAILPIPE - DOUBLE - E-COATED - G32V 094918-06-000 EA CLAMP - EXHAUST - 3" - HEAVY DUTY - G32V 101544-06-000 EA SHIELD - HEAT/EXHAUST - 33.9" X 29.1" - E-COATED 137652-01-000 EA PIPE - EXHAUST - W/FLANGES - G37G Copyright © 2006 Winnebago Industries Inc.
Page 70: Fuel
EA BRACKET - FUEL FILL - E-COATED FROM: 00-00-00 THRU: 07-23-00 136483-01-02B EA BRACKET - FUEL FILL - E-COATED FROM: 07-24-00 THRU: 99-99-99 EA CHASSIS SUPPLIED 125187-02-000 FT HOSE - FUEL - LOW PERMEABILITY - 12.7" ID - FORD Copyright © 2006 Winnebago Industries Inc.
Page 71 EA BUSHING - BRASS - 3/8"MPT X 1/8"FPT 114254-01-000 EA ADAPTER - 1/4 BARB X 1/8 MPT 098779-01-000 EA COUPLER - FUEL LINE - 1.2" LONG X 14MM THREAD 139138-01-02B EA PLATE - FUEL FILL - E/COATED Copyright © 2006 Winnebago Industries Inc.
Page 72: Hydraulic Leveling
EA SHIELD - HEAT - E-COATED - G35U, G37G FROM: 00-00-00 THRU: 06-01-01 132999-02-02B EA SHIELD - HEAT - E-COATED - G35U, G37G FROM: 06-02-01 THRU: 99-99-99 *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 73: Component Parts For Hydraulic Leveling
U/M DESCRIPTION VENDOR NO. 100532-12-706 EA SWITCH - WARNING/MAGNETIC RAP1008 / RAP90496 100532-12-707 EA SPRING KIT R3847 100532-45-700 EA CYLINDER W/O FOOT - 6K X 13" RAP90490 131306-02-700 EA FOOT - 6K JACK RAP2004 Copyright © 2006 Winnebago Industries Inc.
Page 74 EA JACK/CROSSMEMBER - 9K - REAR LEVELING - MANUAL 100532-12-706 EA SWITCH - WARNING/MAGNETIC RAP1008 / RAP90496 100532-12-707 EA SPRING KIT R3847 100532-53-700 EA CYLINDER ASM. - 9K RAP90491/AP15891 131306-02-701 EA FOOT - 9K JACK RAP8464 Copyright © 2006 Winnebago Industries Inc.
Page 75 UNDERSTAND OPERATOR'S MANUAL BEFORE USING. BLOCK FRAME AND TIRES UNDERSTAND OPERATOR'S MANUAL BEFORE USING. BLOCK FRAME AND TIRES SECURELY BEFORE REMOVING TIRES OR CRAWLING UNDER VEHICLE. SECURELY BEFORE REMOVING TIRES OR CRAWLING UNDER VEHICLE. 131306-11-000 Copyright © 2006 Winnebago Industries Inc.
Page 76 EA SPRING KIT R3847 100532-53-700 EA CYLINDER ASM. - 9K RAP90491 131306-02-701 EA FOOT - 9K JACK RAP8464 131306-11-703 EA PUMP/TANK/MANIFOLD ASM. AP19561 131306-02-700 EA FOOT - 6K JACK RAP2004 131306-12-702 EA VALVE-PRESS SOLENOID (SMALL) RAP90729 Copyright © 2006 Winnebago Industries Inc.
Page 77 UNDERSTAND OPERATOR'S MANUAL BEFORE USING. BLOCK FRAME AND TIRES UNDERSTAND OPERATOR'S MANUAL BEFORE USING. BLOCK FRAME AND TIRES SECURELY BEFORE REMOVING TIRES OR CRAWLING UNDER VEHICLE. SECURELY BEFORE REMOVING TIRES OR CRAWLING UNDER VEHICLE. 131306-12-000 Copyright © 2006 Winnebago Industries Inc.
Page 78 EA SPRING KIT R3847 100532-53-700 EA CYLINDER ASM. - 9K RAP90491/AP15891 131306-02-700 EA FOOT - 6K JACK RAP2004 131306-02-701 EA FOOT - 9K JACK RAP8464 131306-12-701 EA PUMP/TANK/MANIFOLD-2 ROOM AP19501 131306-12-702 EA VALVE-PRESS SOLENOID (SMALL), RAP90729 Copyright © 2006 Winnebago Industries Inc.
Page 79 UNDERSTAND OPERATOR'S MANUAL BEFORE USING. BLOCK FRAME AND TIRES UNDERSTAND OPERATOR'S MANUAL BEFORE USING. BLOCK FRAME AND TIRES SECURELY BEFORE REMOVING TIRES OR CRAWLING UNDER VEHICLE. SECURELY BEFORE REMOVING TIRES OR CRAWLING UNDER VEHICLE. 131306-20-000 Copyright © 2006 Winnebago Industries Inc.
Page 80 100532-31-701 EA CHECK VALVE & KIT RAP10021 131306-11-701 EA CONTROL BOX - 310 SYSTEM RAP90019/AP10086 CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT 100532-12-706 EA SWITCH - WARNING/MAGNETIC RAP1008 / RAP90496 100532-45-700 EA CYLINDER W/O FOOT - 6K X 13" RAP90490/AP16112 100532-53-700 EA CYLINDER ASM.
Page 81: Suspension
CHASSIS GROUP (CONTINUED) SUSPENSION KEY PART NUMBER U/M DESCRIPTION 122756-04-000 EA SHOCK & STABILIZER KIT - WORKHORSE/WIDE BODY CHASSIS *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 82: Component Parts For Suspension
EA BOLT PACKAGE KIT T818B-WW 122756-02-707 EA DAMPNER - STEERING T818SD 122756-02-708 EA BOOT - DAMPNER T818SDB 122756-02-709 EA BUSHING PKG-STEERING DAMPNER T818SDBSH 122756-02-710 EA BOLT PKG - STEERING DAMPNER T818BSD 122756-03-702 EA SHOCK 557003 Copyright © 2006 Winnebago Industries Inc.
Page 83: Wheel, Tire, Covers &/Or Liners
EA LINER - WHEEL - SET OF 4 - 19.5" P30 WORKHORSE CHASSIS - G32V WORKHORSE 134609-02-000 EA LINER - WHEEL - SET OF 4 - 19.5" - G35U & G37G WORKHORSE *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 84: Component Parts For Wheel, Tire, Covers &/Or Liners
EA LINER-WHEEL, FRT.(SS NUT CVR 091209-13-706 EA LINER-WHEEL, RR.(SS NUT CVR) 091209-13-708 EA CAP-CENTER, STAINLESS 091209-13-709 EA TOOL/JAMB NUT-ULTG/ULTIëS M9100 091209-16-000 EA NUT-JAM,22MMX30MM HEX KAPER II A20 134609-02-700 EA COVER - LUG NUT 1 3/4" Copyright © 2006 Winnebago Industries Inc.
Page 85: Brake
CHASSIS GROUP (CONTINUED) BRAKE KEY PART NUMBER U/M DESCRIPTION 113007-01-000 EA PIN - SPRING - .375 X 3" BRAKELINE KEY PART NUMBER U/M DESCRIPTION 075466-01-000 EA UNION - INVERTED FLAIR - 1/4" - STRETCHED CHASSIS Copyright © 2006 Winnebago Industries Inc.
Page 86: Curtain & Cushion Group
CURTAINS. YOU WILL NOTE THE WIDTH MEASUREMENT IS TAKEN ON THE TOP OF THE CURTAIN WITH THE CURTAIN FULLY EXTENDED. THE LENGTH MEASUREMENT IS TAKEN FROM TOP TO BOTTOM. LEFT AND RIGHT WINDOW LEGS ARE DETERMINED WHEN FACING THE WINDOW. Copyright © 2006 Winnebago Industries Inc.
Page 87: Cushion Layout
EA COVER - SEAT - 23" X 42" X 5" (M42) P05603-15-M43 EA COVER - SEAT - 23" X 42" X 5" (M43) P05603-30-M58 EA COVER - SEAT - 23" X 42" X 5" (M45) Copyright © 2006 Winnebago Industries Inc.
Page 88 EA ARMREST - LEFT HAND (M43, M45) - LEATHER P30718-02-M40 EA COVER - ARMREST/LEFT HAND (M40) P30718-02-M42 EA COVER - ARMREST/LEFT HAND (M42) P30718-02-L11 EA COVER - ARMREST/LEFT HAND (M43) P30718-02-M45 EA COVER - ARMREST/LEFT HAND (M45) Copyright © 2006 Winnebago Industries Inc.
Page 89 EA COVER/SEAT - SOFA/BED P35138-01-M45 EA COVER - SEAT - SOFA/BED P35138-09-M40 EA COVER/SEAT - SOFA/BED - LEATHER (M40) P35138-09-M42 EA COVER/SEAT - SOFA/BED - LEATHER (M42) P35138-09-M43 EA COVER/SEAT - SOFA/BED - LEATHER (M43, M45) Copyright © 2006 Winnebago Industries Inc.
Page 90 135823-08-M45 EA ARMREST - LEFT HAND 135823-10-M40 EA ARMREST - LEFT HAND (M40) - LEATHER 135823-10-M42 EA ARMREST - LEFT HAND (M42) - LEATHER 135823-10-M43 EA ARMREST - LEFT HAND (M43, M45) - LEATHER Copyright © 2006 Winnebago Industries Inc.
Page 91 EA COVER/SEAT - SOFA/SLEEPER - RECLINER/POWERED (M45) P35822-07-M40 EA COVER/SEAT - SOFA/SLEEPER - RECLINER/POWERED (M40) - LEATHER P35822-07-M42 EA COVER/SEAT - SOFA/SLEEPER - RECLINER/POWERED (M42) - LEATHER P35822-07-M52 EA COVER/SEAT - SOFA/SLEEPER - RECLINER/POWERED (M43, M45) - LEATHER Copyright © 2006 Winnebago Industries Inc.
Page 92 EA BUCKET SEAT - PASSENGER 135473-04-M40 EA BUCKET SEAT - PASSENGER - LEATHER 135473-04-M42 EA BUCKET SEAT - PASSENGER - LEATHER 135473-04-M43 EA BUCKET SEAT - PASSENGER - LEATHER 135473-04-M45 EA BUCKET SEAT - PASSENGER - LEATHER Copyright © 2006 Winnebago Industries Inc.
Page 93: Component Parts For Cushion Layout
CURTAIN & CUSHION GROUP (CONTINUED) COMPONENT PARTS FOR CUSHION LAYOUT 136534-02-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 136534-02-700 EA MOTOR 9PL-MO-W/T-1 136534-02-701 EA CABLE - MOTOR DRIVE - SOFA 9PL-FCA20.25 Copyright © 2006 Winnebago Industries Inc.
Page 94: Bucket Seats
EA COVER - BACK M05962-D9-M45 EA COVER - BACK M05962-B7-M40 EA COVER - BACK - LEATHER M05962-B7-M42 EA COVER - BACK - LEATHER M05962-B7-M43 EA COVER - BACK - LEATHER M05962-B7-M45 EA COVER - BACK - LEATHER Copyright © 2006 Winnebago Industries Inc.
Page 95 EA BRACKET - SEAT RELEASE - SINGLE REMOTE - E-COATED 080730-09-000 EA SHIELD - RECLINER HANDLE 080730-08-000 EA HANDLE - RECLINER 080730-11-000 EA SHIELD - RUBBER BOOT 127159-02-02B EA BRACKET - SEAT RELEASE - DUAL REMOTE - E-COATED Copyright © 2006 Winnebago Industries Inc.
Page 96 EA SEAT - POWER 6 WAY 107921-18-000 EA PLATE - TOP - POWER - 6-WAY FROM: 00-00-00 THRU: 09-30-00 133408-08-000 EA TOP PLATE - W/BAR FROM: 10-01-00 THRU: 99-99-99 *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 97: Component Parts For Bucket Seats
EA MOTOR PKG. ADJ. VERTICAL 22063238 & H-196 081373-03-704 EA DRIVE CABLE 22143984 081373-03-705 EA SPRING 22048978 081373-03-706 EA SHOE GUIDE (WHITE) 22048993 081373-03-707 EA SHOE GUIDE (BLACK) 22048994 081373-03-703 EA SWITCH-CHROME-PLASTIC F/POWER SEAT 6-WAY Copyright © 2006 Winnebago Industries Inc.
Page 98: Lounge Chair
EA COVER - RECLINER W/FOOTREST P35675-02-M42 EA COVER - RECLINER W/FOOTREST - LEATHER 134128-02-02B EA PLATE - W/HOLES - E-COATED 134194-01-01A EA KNOB - HOLD DOWN - RECLINER - BLACK 134057-01-11B EA BRACKET - RECLINER - FLAT BLACK Copyright © 2006 Winnebago Industries Inc.
Page 99: Window Treatment
EA BLIND - DAY/NIGHTER - 59" X 26.5" 111910-55-M42 EA BLIND - DAY/NIGHTER - 59" X 26.5" 111910-55-M43 EA BLIND - DAY/NIGHTER - 59" X 26.5" 111910-55-M45 EA BLIND - DAY/NIGHTER - 59" X 26.5" Copyright © 2006 Winnebago Industries Inc.
Page 100 111910-59-M52 EA BLIND - DAY/NIGHTER - 31" X 28.5" (M43) 111910-59-M45 EA BLIND - DAY/NIGHTER - 31" X 28.5" (M45) 084755-57-E07 EA SHADE - PULL - 27.25" 109041-58-03A EA BLIND - MINI - 30.5" Copyright © 2006 Winnebago Industries Inc.
Page 101 EA LEG - RIGHT - 25" (M45) 127017-46-M40 EA LEG - LEFT - 25" (M40) 127017-46-M09 EA LEG - LEFT - 25" (M42) 127017-46-M43 EA LEG - LEFT - 25" (M43) 127017-46-M58 EA LEG - LEFT - 25" (M45) Copyright © 2006 Winnebago Industries Inc.
Page 102: Hardware
097592-01-000 EA SPOOL - CORD - ELEVATED BLIND HOLDUP - SMALL - CLEAR 083125-07-000 EA BRACE - ANGLE/COUCH - 2.5" - OFF WHITE 083125-08-000 EA BRACE - WINDOW MOUNT - .75" - OFF WHITE Copyright © 2006 Winnebago Industries Inc.
Page 103 FT CORD - BLIND - PLEATED - GRAY 097593-06-000 FT CORD - BLIND - PLEATED - PEWTER 097593-07-000 FT CORD - BLIND - PLEATED - PALE JADE 097593-10-000 FT CORD - BLIND - PLEATED - VANILLA Copyright © 2006 Winnebago Industries Inc.
Page 104: Accessories
EA ADJUSTER - SEATBELT - D-LOOP - ADJUSTER 127598-02-000 EA NUT - HEX FLANGE - M10 X 1.5 - CLASS 10 095076-02-000 EA WASHER - FL - 7/16"ID X 2"OD X .06 *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 105: Component Parts For Accessories
VENDOR NO. 091990-01-701 EA EXTENDER 9" FOR A8408 3 PT I-1331-02 091990-01-703 EA RECEIVER/FEMALE END-SEATBELT I-1159-02 091990-05-700 EA SLEEVE/BUCKLE COVER-PLASTIC 209S-2 091990-05-701 EA CAP/COVER - BOLT HOLE COVER 209SC-02 091990-05-702 EA SLEEVE/RETRACTABLE COVER 309C-02 Copyright © 2006 Winnebago Industries Inc.
Page 106: Fabrics
BODY 126883-F4-000 126883-50-000 126883-18-000 126883-C3-000 LOUNGE OVERLAY OVERLAY OVERLAY OVERLAY PILLOW 126883-F3-000 126883-99-000 126883-41-000 126883-C2-000 BUTTON BUTTON BUTTON BUTTON 126883-F4-000 126883-50-000 126883-18-000 126883-C3-000 CEILING MATERIAL 113979-12-01A 113979-12-01A 113979-12-01A 113979-12-01A SPEAKER 072333-A2-000 072333-A2-000 072333-A2-000 072333-A2-000 Copyright © 2006 Winnebago Industries Inc.
Page 107 SINGLE FLANGED SINGLE FLANGED SHAMS 105745-W7-000 105745-P9-000 105745-L8-000 105745-U4-000 105745-V2-000 105745-R2-000 105745-L4-000 105745-U3-000 079680-30-000 079680-30-000 079680-30-000 079680-30-000 079680-32-000 079680-32-000 079680-32-000 079680-32-000 079680-33-000 079680-33-000 079680-33-000 079680-33-000 VINYL 103907-01-07A 103907-01-07A 103907-01-07A 103907-01-07A 103907-02-07A 103907-02-07A 103907-02-07A 103907-02-07A Copyright © 2006 Winnebago Industries Inc.
Page 108: Dinette Group
EA CABINET - OVERHEAD/DINETTE - W/O DOORS/HARDWARE - W/DELUXE SOUND 134918-01-M42 EA CABINET - OVERHEAD/COFFEE - W/O DOORS/HARDWARE 122021-01-02A EA ANGLE - W/HOLES - 8.6" LONG - OFF WHITE 132871-02-02B EA BRACKET/L-ANGLE W/HOLES - 1.9" X 2.8" - E-COATED Copyright © 2006 Winnebago Industries Inc.
Page 109: Doors & Drawers
DINETTE GROUP (CONTINUED) DOORS & DRAWERS KEY PART NUMBER U/M DESCRIPTION 132141-20-M42 EA DOOR - RAIL/VENEER - 10.8" X 27.9" - W/O HARDWARE M09316-B1-M42 EA DRAWER - OGEE EDGE - 16.6"W X 37.3"D - W/O SLIDES/HARDWARE Copyright © 2006 Winnebago Industries Inc.
Page 110: Table
EA BRACKET - HINGE - MOUNTS TO LEG & TABLE TOP - 1.7" X 2.6" 092707-04-09A EA LEG - TABLE - W/O HARDWARE - 27" - PORTSMOUTH OAK 092593-01-05A EA CATCH - TABLE LEG - OFF/WHITE 049493-12-000 EA CATCH - TABLE LEG/FLOOR MOUNTED - OFF WHITE Copyright © 2006 Winnebago Industries Inc.
Page 111 EA TRIM - TABLE MOLDING - 23.8" 133856-14-L53 EA TRIM - TABLE MOLDING - 23.8" 133856-13-L53 EA TRIM - TABLE MOLDING - 41.2" 133856-23-M42 EA COUNTERTOP - F/WALL CABINET - LAMINATED - PORTSMOUTH OAK Copyright © 2006 Winnebago Industries Inc.
Page 112: Drivers Compartment Group
EA VINYL - LAMINATE - 1/4" X 25" X 100" - ALLANTE ANTELOPE 132126-02-02B EA PANEL - DASH TOP - E-COATED 129813-02-01A EA HINGE - DASH POD - ANTELOPE 132080-01-01A EA POD - INSTRUMENT PANEL - W/O HOLE - ANTELOPE Copyright © 2006 Winnebago Industries Inc.
Page 113 EA DASH - WORKHORSE CHASSIS - F/WORKSTATION - E-COAT - G35U & G37G WH W/WORKSTATION 138620-01-02B EA BRACKET - RADIO SUPPORT - E-COATED FROM: 00-00-00 THRU: 07-13-01 115870-01-000 FT SEAL - TRIM - EDGE Copyright © 2006 Winnebago Industries Inc.
Page 114: Motor Cover
EA RETAINER - MOTOR COVER/TOP - E-COATED FROM: 00-00-00 THRU: 07-08-01 115855-01-02B EA RETAINER-MOTOR COVER,TOP,E-C FROM: 07-09-01 THRU: 99-99-99 134455-01-000 EA INSULATION/ENGINE COVER/MAIN - FORD 134455-02-000 EA INSULATION/ENGINE COVER/FRONT - FORD 134497-01-000 SF FOIL/ALUMINUM - REINFORCED - FORD Copyright © 2006 Winnebago Industries Inc.
Page 115 EA RETAINER - LATCH - MOTOR COVER - RIGHT HAND - E-COATED 137096-01-01A EA COVER - MOTOR - W/O CARPET 115855-04-02B EA RETAINER - MOTOR COVER - E-COATD 115855-03-02B EA RETAINER - MOTOR COVER/TOP - E-COATED 130127-02-02B EA SUPPORT - MOTOR COVER - E-COATED Copyright © 2006 Winnebago Industries Inc.
Page 116: Front Interior
EA TRIM - WINDSHIELD - INNER/TOP/DRIVER - ANTELOPE 118452-04-01A EA TRIM - WINDSHIELD - CENTER - ANTELOPE 118453-03-01A EA TRIM - WINDSHIELD - INNER/TOP/PASSENGER - ANTELOPE 125508-01-01A EA TRIM - A-PILLAR - PASSENGER/INTERIOR - ANTELOPE Copyright © 2006 Winnebago Industries Inc.
Page 117 EA ANGLE - SLIDE - TRAY/RIGHT HAND - E-COATED 135228-02-02B EA ANGLE - SLIDE - TRAY/LEFT HAND - E-COATED 135314-01-01A EA SLIDE - DASH WORK STATION - RIGHT HAND 135314-02-01A EA SLIDE - DASH WORK STATION - LEFT HAND Copyright © 2006 Winnebago Industries Inc.
Page 118 EA PANEL - OVERHEAD/FRONT/PASSENGER 132694-02-L32 EA PANEL - OVERHEAD/FRONT/DRIVER 126440-11-L32 EA PANEL - OVERHEAD/FRONT/BOTTOM/PASSENGER - W/FRONT TV 126440-12-L32 EA PANEL - OVERHEAD/FRONT/BOTTOM/DRIVER - W/FRONT TV 123298-04-01A EA SUNVISOR - 10.5" X 21" - DRIVER/PASSENGER-ALLANTE ANTELOPE Copyright © 2006 Winnebago Industries Inc.
Page 119: Cabinets
EA PANEL/SHELF - E-COATED - W/CD CHANGER 130030-02-02B EA SUPPORT - TV - E-COATED 132973-03-M53 EA CABINET - OVERHEAD/FRONT - W/O DOORS/HARDWARE 132141-29-M30 EA DOOR - RAIL/VENEER - 10" X 25.1" - W/O HARDWARE Copyright © 2006 Winnebago Industries Inc.
Page 120: Electrical Group
EA BULB - 12V - #194 - .27 AMP - BAYONETTE 111102-01-000 EA BASE - MARKER LAMP 113589-01-000 EA CONNECTOR - PLUG - TRAILER 113589-02-000 EA CONNECTOR - SOCKET - TRAILER *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 121 EA SWITCH - ROCKER - SPST - ON/OFF - 2 TERMINAL 108356-02-01A EA COVER/ACTUATOR SWITCH - 2 ROWS DIMPLES- CONTURA II - BLACK 108355-01-000 EA HOUSING - SWITCH 135167-01-02B EA BRACKET - COVER - SWITCH - E-COATED *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 122 EA SPACER - SWITCH - 2.3" X 4.1" - PLASTIC - DARK BROWN 132180-01-01A EA SWITCH - PADDLE - SPST - ON/OFF - BLACK 098351-19-01A EA PLATE/SWITCH - 1 GANG 133713-05-08A EA SPACER - SWITCH - VINYL - PORTSMOUTH OAK Copyright © 2006 Winnebago Industries Inc.
Page 123 EA SWITCH - PADDLE - SPST - ON/OFF - BLACK 098351-17-01A EA PLATE/SWITCH - 2 GANG W/LABEL 133713-05-08A EA SPACER - SWITCH - VINYL - PORTSMOUTH OAK 116995-02-000 EA SWITCH/MAGNET - ELECTRIC STEP - BLACK/WHITE-CLOSED CIRCUIT *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 124: Front End Wiring
049185-04-000 EA HEADLAMP - PASSENGER - HIGH/LOW - HALOGEN 049186-04-000 EA HEADLAMP - DRIVER - HIGH/LOW - HALOGEN 110690-01-D18 EA PLATE - HEADLAMP - QUAD/RIGHT HAND 110690-02-D18 EA PLATE - HEADLAMP - QUAD/LEFT HAND Copyright © 2006 Winnebago Industries Inc.
Page 125 EA SWITCH-PUSH BUTTON, IN DOOR JAMB - METAL - CHROME 133535-01-000 EA MODULE - TIMER 20 SECOND - WARNING LIGHT - TS61120P EA FILTER - NOISE - 12 VOLT D.C. W/PLUGS - SEE AUDIO VIDEO GROUP Copyright © 2006 Winnebago Industries Inc.
Page 126 108355-01-000 EA HOUSING - SWITCH 108357-08-000 EA SWITCH - ROCKER - DPDT - ON/NONE/ON - 6 TERMINAL 108356-02-01A EA COVER/ACTUATOR SWITCH - 2 ROWS DIMPLES- CONTURA II - BLACK 108355-01-000 EA HOUSING - SWITCH Copyright © 2006 Winnebago Industries Inc.
Page 127 EA PLATE/SWITCH - E-COATED 115539-01-000 EA RELAY - RADIO/TV SPEAKER - SWITCH 077031-03-000 EA FILM - WHITE - .75" X 1" 103603-01-000 EA BULB - 12V - #74 - .12A WEDGE - GE 22-25 USED IN DASH Copyright © 2006 Winnebago Industries Inc.
Page 128: Component Parts For Lights & Switches
VENDOR NO. 115632-03-02A EA LIGHT - STOP/TURN/TAIL RED 115632-03-700 EA LENS - RED-(STOP/TAIL/BACK) 3092-704 121935-01-01A KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 121935-01-01A EA LIGHT - DOME - SHOWER 121935-01-700 EA LENS ONLY 809511 Copyright © 2006 Winnebago Industries Inc.
Page 129: Circuit Breakers & Fuses
127002-02-000 EA PANEL/MONITOR - ENERGY MANAGEMENT SYSTEM FROM: 00-00-00 THRU: 01-28-01 127002-05-000 EA PANEL/MONITOR - ENERGY MANAGEMENT SYSTEMS CTRL - W/PLUG FROM: 01-29-01 THRU: 99-99-99 127002-07-000 EA SENSOR - CURRENT FROM: 01-29-01 THRU: 99-99-99 Copyright © 2006 Winnebago Industries Inc.
Page 130: 110V Wiring
EA RECEPTACLE - ELECTRIC - DOUBLE - IVORY 133713-01-08A EA SPACER - RECEPTACLE - VINYL - PORTSMOUTH OAK 058708-02-000 EA RECEPTACLE - ELECTRIC - DOUBLE - IVORY 133713-01-08A EA SPACER - RECEPTACLE - VINYL - PORTSMOUTH OAK Copyright © 2006 Winnebago Industries Inc.
Page 131: Drivers Door Wiring
088246-01-000 EA SWITCH/REMOTE MIRROR - W/2PIN & 6 PIN CONNECTORS/PIGTAIL 108357-14-000 EA SWITCH - ROCKER - SPST - W/LIGHT - ON/OFF - 4 TERMINAL 108356-03-02A EA COVER/ACTUATOR SWITCH -3 GROOVES W/LIGHT-CONTRA III-BLACK NOT USED Copyright © 2006 Winnebago Industries Inc.
Page 132: Entertainment Wiring
EA PLATE/SWITCH - 1 GANG W/LABEL 058708-05-000 EA RECEPTACLE - ELECTRIC - SINGLE - BROWN KEY PART NUMBER U/M DESCRIPTION 058708-01-000 EA RECEPTACLE - ELECTRIC - DOUBLE - BROWN 058708-02-000 EA RECEPTACLE - ELECTRIC - DOUBLE - IVORY Copyright © 2006 Winnebago Industries Inc.
Page 133: Boxes & Cords
EA WIRE ASSEMBLY - SPEAKER/ADAPTER - 35.4" LONG 133877-01-000 EA WIRE ASSEMBLY - RADIO ADAPTOR FROM: 00-00-00 THRU: 07-12-00 134544-01-000 EA WIRE ASSEMBLY - SWITCH ADAPTER 135131-01-000 EA WIRE ASSEMBLY - THERMOSTAT 137626-01-000 EA WIRE - OVERDRIVE SWITCH Copyright © 2006 Winnebago Industries Inc.
Page 134: Connectors & Conduit
EA TERMINAL - MALE - 56 SERIES 098261-02-000 EA SOCKET - CONNECTOR - WEATHERPACK - 14-18 AWG 098262-01-000 EA SEAL - CONNECTOR - WEATHERPACK 098262-05-000 EA SEAL - CAVITY 098262-06-000 EA SEAL - CONNECTOR - M/P - 10 GAUGE Copyright © 2006 Winnebago Industries Inc.
Page 135 EA HOUSING - PIN - 2 CAVITY/HIGH AMP 137208-01-000 EA HOUSING - SOCKET - 2 CAVITY/HIGH AMP 137209-01-000 EA PIN - CONNECTOR - 10AWG/HIGH AMP 137210-01-000 EA SOCKET - CONNECTOR - 10 AWG/HIGH AMP Copyright © 2006 Winnebago Industries Inc.
Page 136: Boots, Solenoids, Relays & Miscellaneous
EA STUD - ISOLATED - 3/8" X 7/8" LONG 086273-01-000 EA RELAY - BATTERY DISCONNECT 115539-01-000 EA RELAY - RADIO/TV SPEAKER - SWITCH 131832-01-000 EA RELAY - 25 AMP/120 VOLT AC/6 TERM - CUTLER-HAMMER D8PR7TEA 131832-02-000 EA HOUSING - RELAY Copyright © 2006 Winnebago Industries Inc.
Page 137: Exterior Body Group
134344-01-04A EA DECAL - WINDSHIELD - LOWER/RIGHT HAND - KHAKI/DK CHARCOAL - W/SAHARA GREY 120702-03-23A EA DECAL - LOGO - WINNEBAGO - MEDIUM TITANIUM METALLIC - W/LAVENDAR FROST 120702-03-24A EA DECAL - LOGO - WINNEBAGO - DARK CHARCOAL METALLIC - W/SAHARA GREY EA DECAL - LOGO "W"...
Page 138 EA BEZEL - DOMED GRILLE LOGO CHASSIS SUPPLIED CHASSIS SUPPLIED PAINT 121510-01-01A EA DECAL - LOGO - WINNEBAGO - SWEEP - BRIGHT WHITE 133141-01-03A EA DECAL - CORNER/SWEEP - PASSENGER - LAVENDER FROST - W/LAVENDAR FROST 133141-01-04A EA DECAL - CORNER/SWEEP - PASSENGER - DARK CHARCOAL METALLIC -...
Page 139: Panels
EA RETAINER - SIDEWALL - BRIGHT WHITE - 133.8" 115863-24-01A EA TRIM - SIDEWALL/SLIDEOUT - TOP - 133.7" - BRIGHT WHITE 115863-23-01A EA TRIM - SIDEWALL/SLIDEOUT - RIGHT HAND - 75.6" - BRT WHT Copyright © 2006 Winnebago Industries Inc.
Page 140 EXTERIOR BODY GROUP (CONTINUED) PANELS (CONTINUED) KEY PART NUMBER U/M DESCRIPTION 133100-02-01A EA TRIM - SIDEWALL - BLACK 124511-19-17A EA TRIM - SIDEWALL/LOWER - 33.2" - BLACK 133100-01-01A EA TRIM - SIDEWALL - BLACK Copyright © 2006 Winnebago Industries Inc.
Page 141: Trims
EA MUD FLAP - 14" X 18" - W/O MOUNTING HOLES - BLACK 131365-01-000 EA WHEELWELL - PLASTIC 121117-01-02B EA ANGLE - W/O SLOTS - 3.7" X 2" - E-COATED - FORD, G32V WORKHORSE Copyright © 2006 Winnebago Industries Inc.
Page 142 EA TRIM - BACKWALL - VERTICAL/INNER - RH/LH - BRIGHT WHITE 132266-01-12B EA BRACKET - MOUNT - BRIGHT WHITE KEY PART NUMBER U/M DESCRIPTION 103335-05-02A EA TRIM - BACKWALL - LOWER - 96.3" - BRIGHT WHITE Copyright © 2006 Winnebago Industries Inc.
Page 143: Front End
FT INSERT - TRIM - .65" WIDE - BRIGHT WHITE 133770-02-02B EA BRACKET - HOOD SUPPORT - E-COATED 134562-01-02B EA SUPPORT - FRONT - E-COATED 134066-01-02B EA BRACKET - ZEE - W/HOLES - E-COATED Copyright © 2006 Winnebago Industries Inc.
Page 144 EA BOLT - HOOD ADJUSTMENT - 5/16"-18 X 1.5"-2"- W/BLACK PAD 137072-01-01A EA HINGE - HOOD - RIGHT HAND - BLACK FROM: 10-02-00 THRU: 99-99-99 137072-02-01A EA HINGE - HOOD - LEFT HAND - BLACK FROM: 10-02-00 THRU: 99-99-99 Copyright © 2006 Winnebago Industries Inc.
Page 145 FROM: 00-00-00 THRU: 04-13-01 134418-07-02B EA PIVOT - LATCH/HOOD - E-COATED - LEFT HAND FROM: 04-14-01 THRU: 99-99-99 113908-01-000 EA LATCH/PLUNGER - F/HOOD 102265-01-000 EA CLIP - ROD END - 5/32" - BLACK PLASTIC Copyright © 2006 Winnebago Industries Inc.
Page 146: Ladder
FROM: 07-10-00 THRU: 99-99-99 106015-13-01A EA MIRROR - EXTERIOR REMOTE/HEAT - DRIVER FROM: 00-00-00 THRU: 07-09-00 106015-19-01A EA MIRROR - EXTERIOR/REMOTE/HEAT - DRIVER FROM: 07-10-00 THRU: 99-99-99 *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 147: Component Parts For Mirrors
U/M DESCRIPTION VENDOR NO. 106015-16-700 EA GLASS-FLAT W/HEAT ELEMENT 709450 106015-18-700 EA GLASS/CONVEX-KIT W/CLIP 709650 106015-18-701 EA GLASS-ACTUATOR - CONVEX GLAS 7475410 106015-18-702 EA MOTOR - FLAT GLASS 747118 106015-18-703 EA CONVEX REBUILT KIT 7709651 Copyright © 2006 Winnebago Industries Inc.
Page 148: Structural Components
EA BRACKET - AWNING - F/A&E INSTALLATION - BRIGHT WHITE FROM: 00-00-00 THRU: 09-10-00 137054-01-02A EA BRACKET - AWNING - BRIGHT WHITE FROM: 09-11-00 THRU: 99-99-99 137171-01-01A EA BRACKET - AWNING - BRIGHT WHITE - ELECTRIC *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 149: Component Parts For Awnings
EA FOOT - PATIO 730366-001 113874-01-710 EA PLUG-STOP KIT 830456 113874-01-717 EA ARM - ADJUSTABLE BRT/WHT 830467.517/F 113874-01-709 EA NAIL-SPIKE, 8" 113006 113874-01-716 EA ARM - MAIN SUPPORT BRT/WHT 3104502.293/F 113874-01-703 EA ROD-CENTER PULL W/ACCESSORY 830152.102 Copyright © 2006 Winnebago Industries Inc.
Page 150: Exterior Doors & Compartments Group
EA JAMB - VENT DOOR/REFRIGERATOR - BRIGHT WHITE - W/TWO DOOR REFRIGERATOR 125481-01-02A EA DOOR - VENT/REFRIGERATOR - 28.5"W X 13.8"H - BRIGHT WHITE - W/FOUR DOOR REFRIGERATOR 125481-02-000 EA Z-BRACKET - VENT DOOR - W/FOUR DOOR REFRIGERATOR Copyright © 2006 Winnebago Industries Inc.
Page 151 EA CYLINDER - LOCKING 138289-06-000 EA CYLINDER - LOCKING 138289-07-000 EA CYLINDER - LOCKING 138289-08-000 EA CYLINDER - LOCKING 138289-09-000 EA CYLINDER - LOCKING 138289-10-000 EA CYLINDER - LOCKING *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 152 EA CASE/CYLINDER - TWIST LATCH - W/O CAM - 1" - 596669 110506-60-000 EA CAM - LATCHING - STRAIGHT 2.4" FROM: 00-00-00 THRU: 07-07-01 110506-78-000 EA CAM - LOCK FROM: 07-08-01 THRU: 99-99-99 009065-01-000 EA HINGE - ALUMINUM - 1 1/2" X 96" - UNPAINTED Copyright © 2006 Winnebago Industries Inc.
Page 153 134980-05-AA1 EA VALANCE/DOOR - W/O LATCH/HINGE - 32.7" X 24.3" 132873-25-000 EA ROD - LATCH - 10.2" 132873-26-000 EA ROD - LATCH - 12" 107796-32-000 EA SPRING/GAS - 9.5" COMPRESSED/15" EXTENDED - 90 LB Copyright © 2006 Winnebago Industries Inc.
Page 154: Component Parts For Door & Compartment Layout
EA LINKAGE ASM. W/BEARINGS-PINS 909534 094707-02-707 EA TREAD - NON-SKID - BLACK 909333 094707-02-706 EA GEAR BOX ASM. W/O MOTOR 9524 094707-02-708 EA TREAD - NON-SKID - YELLOW 909331 094707-03-701 EA PLUG - 4-WAY - PACKARD 909306 Copyright © 2006 Winnebago Industries Inc.
Page 155: Compartment Door Piece Parts
EA ROD - LATCH (BLANK) - LEFT HAND EA SEE DOOR & COMPARTMENT LAYOUT FOR ROD & LATCH 057460-02-000 EA BALL STUD - F/GAS SPRING .39" - 5/16"-18 133049-02-L76 EA TRIM - COVER/WATER HEATER Copyright © 2006 Winnebago Industries Inc.
Page 156 EA HINGE - ALUMINUM - 2" X 96" - BRIGHT WHITE 106850-02-000 FT SEAL-E - SPONGE RUBBER - .43" X .75" 130005-02-000 EA LOCK - W/O CYLINDER & KEYS - W/CAM - F/KEY ONE SYSTEM Copyright © 2006 Winnebago Industries Inc.
Page 157: Drivers
EA SPACER - STRIKE - DRIVER DOOR - E-COATED 132297-01-M24 EA BEVERAGE TRAY - PASSENGER/DRIVER - PORTSMOUTH OAK 117802-01-000 EA GROMMET - CONVOLUTED - 2" 128131-01-01A EA SPACER/SWITCH - DOME - BLACK *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 159 EA FRAME MOUNTING ASM., (JAMB) V130-30L 125581-07-702 EA GLASS-ROLL-UP/29.3" X 29.5" V220-65L 125581-07-701 EA GLASS-STATIONERY/4.95"X29.5" 106-042082 CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT 125581-04-707 EA CHANNEL - ROLL UP GLASS V156-60 125581-04-708 EA CHANNEL - STATIONARY GLASS V156-61 125581-04-709 EA REGULATOR - MANUAL...
Page 161 EA CYLINDER - LOCK ASSEMBLY - ENTRANCE DOOR (J) 129685-09-000 EA CYLINDER - LOCK ASSEMBLY - ENTRANCE DOOR (J) 129685-10-000 EA CYLINDER - LOCK ASSEMBLY - ENTRANCE DOOR (J) *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 162: Component Parts For Entry
EXTERIOR DOORS & COMPARTMENTS GROUP (CONTINUED) COMPONENT PARTS FOR ENTRY 129676-01-000 - 129676-10-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO . 129685-01-701 EA KEY - BLANK KS 150 144472-07-2001 Copyright © 2006 Winnebago Industries Inc.
Page 163: Screen
078777-08-000 FT CHANNEL - SLIDER 120863-06-000 EA BUMPER - RUBBER - 3/4" X 3/8" 132081-01-01A EA STRIKE - SLIDER - SCREEN DOOR - BRIGHT WHITE 132082-01-01A EA SLIDER - SCREEN DOOR - BRIGHT WHITE Copyright © 2006 Winnebago Industries Inc.
Page 164: Latch - Entry
EA COVER - STRIKE - ENTRY DOOR - 6.5" X 2.5" - WHITE PLASTIC FROM: 00-00-00 THRU: 12-18-00 077461-07-000 EA COVER/BRACKET - STRIKE - OFF WHITE FROM: 12-19-00 THRU: 05-13-01 139102-01-01A EA COVER - BRACKET - STRIKE - BRIGHT WHITE FROM: 05-14-01 THRU: 99-99-99 Copyright © 2006 Winnebago Industries Inc.
Page 165: Exterior Slideout Group
EA BRACKET - SLIDEOUT/COMPARTMENT - E-COATED FROM: 00-00-00 THRU: 04-22-01 128386-02-02B EA BRACKET - SLIDEOUT COMPARTMENT - E-COATED FROM: 04-23-01 THRU: 99-99-99 126516-01-01A FT TRIM - VINYL/EXTRUDED - 8í *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 166 EA TRIM/KEY CORNER - SLIDEOUT - 3.1"X3.1" - BRT WHT FROM: 00-00-00 THRU: 04-29-01 116444-04-12B EA TRIM/KEY CORNER - SLIDEOUT - 3.1"X3.1" - BRT WHT FROM: 04-30-01 THRU: 99-99-99 134929-01-M42 EA ROOF - W/O LIGHTS/VENTS - W/WIRING - F/SLIDEOUT Copyright © 2006 Winnebago Industries Inc.
Page 167 FT SHOE/GLIDE - SLIDEOUT ROOM - 1/16" X 3" - POLYEHTYLENE 115325-01-02A EA RAIL - FLOOR/SLIDEOUT ROOM - BLACK 133954-01-01A EA TRIM/SEAL - W/MITERED ENDS - 154.3" - BRIGHT WHITE 115076-03-000 FT SEAL - SLIDEOUT Copyright © 2006 Winnebago Industries Inc.
Page 168 FROM: 05-14-01 THRU: 99-99-99 116101-02-F31 EA STRAP - WINCH - 34" CENTER BRACKET/STRAP END 116082-03-02B EA BRACKET - WINCH 115767-02-000 EA WINCH - SLIDEOUT W/10í STRAP 136839-02-01A EA TRIM-J - CARPET EDGE/SLIDEOUT - 76.8" - BLACK Copyright © 2006 Winnebago Industries Inc.
Page 169: Component Parts For Front Left
EA RAM - SLIDEOUT ROOM RAP90689/AP19616 132540-01-701 EA CYLINDER - SYNCRONIZING RAP90690/AP17966 132540-01-702 EA HOSE-HYD-3/16" X 12' AP18016 132540-01-704 EA TUBE ASM - FRONT OF SLIDE AP19394 132540-01-705 EA TUBE ASM - REAR OF SLIDE AP19395 Copyright © 2006 Winnebago Industries Inc.
Page 170: Right Rear
EA RAIL - FLOOR/SLIDEOUT ROOM - BLACK 115325-11-01A EA RAIL - FLOOR/SLIDEOUT ROOM - BLACK 115661-01-000 FT SHOE/GLIDE - SLIDEOUT ROOM - 1/16" X 3" - POLYEHTYLENE *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 171 EA PROTECTOR - CORNER - SLIDEOUT - WHITE 116444-02-12B EA TRIM/KEY CORNER - SLIDEOUT - 3.1"X3.1" - BRT WHT FROM: 00-00-00 THRU: 04-29-01 116444-04-12B EA TRIM/KEY CORNER - SLIDEOUT - 3.1"X3.1" - BRT WHT FROM: 04-30-01 THRU: 99-99-99 Copyright © 2006 Winnebago Industries Inc.
Page 172 RIGHT HAND FROM: 04-11-01 THRU: 99-99-99 133954-25-01A EA TRIM/SEAL - W/MITERED ENDS - 70.4" - BRIGHT WHITE - LEFT HAND FROM: 04-11-01 THRU: 99-99-99 105312-01-07A FT INSERT - FEATURE STRIP - VINYL - BRIGHT WHITE Copyright © 2006 Winnebago Industries Inc.
Page 173 FROM: 00-00-00 THRU: 05-13-01 132663-02-08A EA MOLDING-VINYL WRAP/PRE DRILLED-.6"X3"X48.6" - OAK FROM: 05-14-01 THRU: 99-99-99 124624-10-02A EA ANGLE - TRIM - BLACK - 7.9" FROM: 00-00-00 THRU: 04-15-01 124624-03-02A EA ANGLE-TRIM,BLACK FROM: 04-16-01 THRU: 99-99-99 Copyright © 2006 Winnebago Industries Inc.
Page 174: Component Parts For Right Rear
U/M DESCRIPTION VENDOR NO. 128599-05-700 EA RAM/CYLINDER - SLIDEOUT RAP90688 128599-05-701 EA HOSE - 1/8" X 84" AP14252 128599-05-702 EA HOSE - 1/8" X 72" AP12071 128599-05-703 EA COVER - SLOTTED W/FOAM PAD AP16465 Copyright © 2006 Winnebago Industries Inc.
Page 175: Galley Group
EA SHELF - W/EDGE MOLDING 132600-19-M42 EA TOE KICK - GALLEY CABINET 130815-02-01A EA COVER/SINK - SMALL - JAMAICAN SAND - 1/4" VENDURA 130815-01-01A EA COVER/SINK - LARGE - JAMAICAN SAND - 1/4" VENDURA Copyright © 2006 Winnebago Industries Inc.
Page 176 EA SLIDE - PANTRY - W/O LOCK - RIGHT/LEFT HAND 122360-03-000 EA SLIDE - PANTRY - W/LOCK - RIGHT HAND (FACING PANEL) 123673-01-01A EA KNOB - PANTRY SLIDE 131096-06-L81 EA WALL POCKET - MONITOR PANEL Copyright © 2006 Winnebago Industries Inc.
Page 177: Doors And Drawers
132141-B5-M42 EA DOOR - RAIL/VENEER - 17.9" X 14.3" - W/O HARDWARE 133890-04-L81 EA DRAWER - OGEE EDGE - 20.2"W X 15.7"D - W/O SLIDES/HARDWARE P32052-68-05W EA DRAWER FACE ONLY - 4.3" X 11.4" Copyright © 2006 Winnebago Industries Inc.
Page 178: Generator Group
EA CLAMP - MUFFLER - 1.5" DIAMETER 104644-01-000 EA ANGLE - FORMED - GENERATOR 081364-03-000 EA MUFFLER - GENERATOR - ONAN 007125-04-000 EA CLAMP - MUFFLER - 1.12" DIAMETER 112365-03-000 EA BREAKER - 30 AMP GENERATOR Copyright © 2006 Winnebago Industries Inc.
Page 179 EA GENERATOR - 5.5 - 30/20 - GAS - MARQUIS GOLD - 30 AMP SYSTEM 105958-03-000 EA PIPE - GENERATOR EXHAUST - 1.5" OD X 4.4" X 15.7" 007125-03-000 EA CLAMP - MUFFLER - 1.5" DIAMETER Copyright © 2006 Winnebago Industries Inc.
Page 181 EA TEE - BEADED - 5/8" X 5/8" X 5/8" 007108-01-000 FT HOSE - HEATER - 5/8" ID - HI-TEMP 103930-50-000 EA RESTRICTOR-WATER 103930-37-000 EA MANUAL/OWNERS - HEATER-A/C *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 183 103930-17-702 EA OíRING #10 045-0127 103930-29-701 EA OíRING F/LOW PRESSURE SWITCH 045-0483 103930-47-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO 103930-47-000 EA HOSE - EXPANSION VALVE - RECEIVER DRIER 113245-01-710 EA OíRING, #12 045-0128 Copyright © 2006 Winnebago Industries Inc.
Page 184 EA CONTROL PANEL - NON RECESSED 083-0223 103930-49-704 EA SWITCH - BLOWER 032-0332 103930-49-705 EA POTENTIOMETER 032-0182 103930-49-706 EA SWITCH - VACUUM 032-0185 103930-49-707 EA DECAL CONTROL PANEL-N/RECESS 058-0144 103930-49-708 EA KNOB - BLOWER - NONRECESSED 062-0620 Copyright © 2006 Winnebago Industries Inc.
Page 185: Furnace
EA FURNACE - 40000 BTU - SF QUIET - SUBURBAN SF-42 2323J - G35B, G35U, G37G FROM: 10-01-01 THRU: 99-99-99 098668-23-000 EA DOOR - ACCESS - FURNACE - BRIGHT WHITE *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 187 098668-01-707 EA TUBE ASSEMBLY, EXHAUST W/CAP 260231 098668-08-700 EA MODULE BD/FAN CONT - FENWAL 232613 098668-08-701 EA MODULE BD/FAN CONT-UNITED TE 232614 069634-01-720 EA ORIFICE-MAIN BURNER 180222 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 188 EA WHEEL-COMBUSTION AIR 350183 098668-22-703 EA GASKET 070811 098668-08-700 EA MODULE BD/FAN CONT - FENWAL 232613 098668-08-701 EA MODULE BD/FAN CONT-UNITED TE 232614 098668-22-704 EA GASKET - MOTOR 70812 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 190 EA BUSHING - STRAIN RELIEF 231809 098668-01-716 EA GASKET-FIREWALL,CHAMBER SIDE 070808 139980-01-716 EA CHAMBER ASSEMBLY - FINAL 021149BK 098668-21-701 EA SWITCH - LIMIT 232504 098668-01-713 EA TUBE ASSEMBLY, INTAKE 051248 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 192 EA BUSHING - STRAIN RELIEF 231809 098668-01-716 EA GASKET-FIREWALL,CHAMBER SIDE 070808 139980-04-703 EA CHAMBER ASSEMBLY FINAL 021150BK 098668-22-706 EA SWITCH/LIMIT - 195 TRIP TEMP 232505 098668-01-713 EA TUBE ASSEMBLY, INTAKE 051248 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 193: Rear Heater
EA HOSE - 90 DEGREE - 5/8"ID X 4" X 36" 094600-05-01A EA REGISTER W/O DAMPER-3.6" X 11.3" FACE/2.1" X 9.9" - BEIGE 129205-01-000 EA HEATER - REAR *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 194: Component Parts For Rear Heater
VENDOR NO. 129205-01-000 EA HEATER - REAR 129205-01-700 EA SEAL - CORE TUBE HV218421 129205-01-701 EA CORE - HEATER HV218426 129205-01-702 EA BLOWER ASSEMBLY HV218419 129205-01-703 EA WIRE HARNESS HV21842O 129205-01-704 EA RESISTOR HV218125 Copyright © 2006 Winnebago Industries Inc.
Page 196 FROM: 00-00-00 THRU: 07-16-00 105620-15-000 EA THERMOSTAT - FURNACE/HEAT PUMP-A/C - W/HEAT PUMP FROM: 07-17-00 THRU: 99-99-99 120134-01-02A EA REGISTER - W/DAMPER - 4" PIPE/7" O.D. FACE - WHITE *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 198 105620-10-707 EA CONDENSER COIL 1452-1541 105620-10-705 EA PTCR (START DEVICE) - W/CAP. 8333A9021 126859-01-703 EA CAPACITOR - RUN 1499-5671 CONTACT WINNEBAGO PART SALES FOR THIS PART 105620-01-738 EA BOARD-TERMINAL, HIGH VOLTAGE 6795-315 105620-01-733 EA ISOLATOR-HIGH VOLTAGE 6795-117 093763-01-704 EA CAPACITOR-FAN...
Page 200 EA KIT-CIRCUIT BD (6535-SERIES) 6535-3209 105620-12-721 EA CIRCUIT BD(6535 A SERIES) 6535-3201 093763-01-704 EA CAPACITOR-FAN 1499-5461 105620-10-720 EA FUSE/BUSS(8AMP/250V) 2 PKG 6535-3081 105620-10-705 EA PTCR (START DEVICE) - W/CAP. 8333A9021 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 201: Interior Finish Group
FT MOLDING-T - W/EDGE LIP - 3/4" FACE - BEIGE ILLUSION 022992-11-000 FT MOLDING - REVERSE COVE - T-SHAPED - IVORY 022992-14-000 FT MOLDING - REVERSE COVE - T-SHAPED - BRIGHT WHITE 022992-15-000 FT MOLDING - REVERSE COVE - T-SHAPED - VW GRAY Copyright © 2006 Winnebago Industries Inc.
Page 202 FT MOLDING - CROWN - 3.5" - CHERRY 113794-02-02A FT MOLDING - CROWN - 1.8" - CHERRY 113794-01-03A FT MOLDING - CROWN - 3.5" - MAPLE 113794-02-03A FT MOLDING - CROWN - 1.8" - MAPLE Copyright © 2006 Winnebago Industries Inc.
Page 203 FT MOLDING - PICTURE - HARD WHITE MAPLE 131923-03-01A FT MOLDING - CROWN - DIVIDER - ASH 131923-03-02A FT MOLDING - CROWN - DIVIDER - CHERRY 131923-03-03A FT MOLDING - CROWN - DIVIDER - HARD WHITE MAPLE Copyright © 2006 Winnebago Industries Inc.
Page 204 104676-02-08A FT MOLDING-T - W/EDGE LIP - 11/16" FACE - PORTSMOUTH OAK 104676-02-09A FT MMOLDING-T - W/EDGE LIP - 11/16" FACE - CONCERT CHERRY 091985-01-08A FT INSERT - TRIM - SOFT WHITE - 1" Copyright © 2006 Winnebago Industries Inc.
Page 205 EA TRIM - CHAIR RAIL - 2.5" X 8' EACH - WOOD - WASHED MAPLE 100182-10-M95 EA TRIM - CHAIR RAIL - 2.5" X 8' EACH - WOOD 109410-16-JQ0 EA MOLDING - TRIM - WASHED MAPLE 109410-01-M53 EA MOLDING - TRIM - 8' - PORTSMOUTH OAK Copyright © 2006 Winnebago Industries Inc.
Page 206 EA TRIM/TABLE - 29.7" - PORTSMOUTH OAK P34052-01-M84 EA TRIM/TABLE - 29.7" - WASHED MAPLE P34052-02-M52 EA TRIM/TABLE - 24" - SALEM CHERRY P34052-02-M76 EA TRIM/TABLE - 24" - PORTSMOUTH OAK P34052-02-M84 EA TRIM/TABLE - 24" - WASHED MAPLE Copyright © 2006 Winnebago Industries Inc.
Page 207: Paneling & Laminates
FROM: 02-05-01 THRU: 99-99-99 132610-05-01A FT WALLPAPER - BORDER - 4 3/4" - SELF-ADHESIVE (M43) 132610-05-06A FT WALLPAPER - BORDER - 7" - SELF-ADHESIVE (M45) 132610-06-01A FT WALLPAPER - BORDER - 5 1/4" - SELF-ADHESIVE (M42) Copyright © 2006 Winnebago Industries Inc.
Page 208: Accessories
EA PICTURE - DECORATIVE - 13" X 15" - LATTICE BOUQUET II (M40, M42, M43) - REFRIGERATOR WALL 131493-02-05A EA PICTURE - DECORATIVE - 13" X 15" - VIOLIN (M45) - REFRIGERATOR WALL *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 209: Component Parts For Accessories
INTERIOR FINISH GROUP (CONTINUED) COMPONENT PARTS FOR ACCESSORIES 094499-02-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO 094499-02-000 EA EXTINGUISHER/FIRE - DRY - 1A10BC - CANADIAN 094499-01-700 EA BRACKET MTG. W/PLAS. STRAP 294039 Copyright © 2006 Winnebago Industries Inc.
Page 210: Floor Coverings
SY CARPET - TAPIOCA - INCREMENTS OF 4 SQ YDS (M43) 096060-H2-000 SY CARPET - SADDLE - INCREMENTS OF 4 SY YDS (M45) 124253-01-02A EA VINYL - FLOOR PLANK - 3" X 12" - MAPLE Copyright © 2006 Winnebago Industries Inc.
Page 211: Hardware
EA SLIDE - DRAWER - 20" - LEFT CABINET 128810-21-01A EA SLIDE - DRAWER - 22" - LEFT CABINET 128810-25-01A EA SLIDE - DRAWER - 24" - LEFT CABINET 128811-01-01A EA BACKSOCKET - ADJUSTABLE - LEFT 128811-02-01A EA BACKSOCKET - ADJUSTABLE RIGHT Copyright © 2006 Winnebago Industries Inc.
Page 212 EA SLIDE - DRAWER - 9" 133892-03-01A EA SLIDE - DRAWER - LEFT DRAWER - 16" 133892-01-01A EA SLIDE - DRAWER - LEFT CABINET - 16" 133907-02-01A EA BACKSOCKET - LEFT HAND 133907-01-01A EA BACKSOCKET - RIGHT HAND Copyright © 2006 Winnebago Industries Inc.
Page 213 EA CABLE - STAINLESS STEEL - 15.5" 076767-14-000 EA CABLE - STAINLESS STEEL - 14.9" 076767-15-000 EA CABLE - STAINLESS STEEL - 9.8" 114739-01-01A EA PAD - NON SKID - PSA - 4"W - 1 EACH=PAIR Copyright © 2006 Winnebago Industries Inc.
Page 214 EA BRACKET - GAS SPRING W/BALL STUD - E-COATED 126263-10-02B EA BRACKET - GAS SPRING W/BALL STUD - E-COATED 126263-13-02B EA BRACKET - GAS SPRING W/BALL STUD - E-COATED 126263-08-02B EA BRACKET - GAS SPRING W/BALL STUD - E-COATED Copyright © 2006 Winnebago Industries Inc.
Page 215 EA LATCH - DOOR - GRABBER W/KEEPER - PLASTIC - BLK-5 LB PULL 117095-02-01A EA LATCH - DOOR - GRABBER W/KEEPER - PLASTIC - BLK-10 LB PULL 133607-01-01A EA PULL - LATCH - BLACK PLASTIC Copyright © 2006 Winnebago Industries Inc.
Page 216 EA CORNER - TRACK - TAMBOUR DOOR 106699-01-01A EA BRACKET F/TV INSTALLATION - OVERHEAD CABINET 106699-03-02B EA BRACKET F/TV INSTALLATION - OVERHEAD CABINET - E-COATED 106699-04-02B EA BRACKET F/TV INSTALLATION - OVERHEAD CABINET - E-COATED Copyright © 2006 Winnebago Industries Inc.
Page 217 EA LATCH - W/O STRIKE - BLACK - NEW STYLE 103256-01-000 EA LATCH COMPLETE (SLIDE) 098196-01-000 EA LATCH - 1/4 TURN - T-BAR 129703-01-01A EA CATCH ASSEMBLY (SPRING) 009013-01-000 EA CATCH - BULLDOG - MALE/FEMALE Copyright © 2006 Winnebago Industries Inc.
Page 218 EA ROD - SHOWER CURTAIN - 3/4"OD X 34.2" - SOFT WHITE 102075-17-02A EA ROD - SHOWER CURTAIN - 1" OD X 39.3" - SOFT WHITE 102075-18-02A EA ROD - SHOWER CURTAIN - 1" OD X 38.9" - SOFT WHITE Copyright © 2006 Winnebago Industries Inc.
Page 219 EA HINGE - 1" X 72" - ALUMINUM - W/HOLES 084625-06-000 EA HINGE - ALUMINUM - W/HOLES - 17.2" - OFF/WHITE 110496-01-01A EA HINGE - BRASS 114278-02-000 EA HINGE - CONTINUOUS - 3" WIDE Copyright © 2006 Winnebago Industries Inc.
Page 220: Labels Group
KEY PART NUMBER U/M DESCRIPTION 006187-01-000 EA LABEL - SEWAGE KEY PART NUMBER U/M DESCRIPTION 006188-01-000 EA LABEL - WASTE WATER KEY PART NUMBER U/M DESCRIPTION 023769-01-000 EA LABEL - WARNING - LPG - CANADIAN Copyright © 2006 Winnebago Industries Inc.
Page 221 050225-01-000 EA LABEL - WARNING - STOVE VENT - US 134539-01-01A EA LABEL - WARNING - STOVE/HEATING - US - BLACK ON CLEAR KEY PART NUMBER U/M DESCRIPTION 095721-40-000 EA LABEL - CONTROL CENTER Copyright © 2006 Winnebago Industries Inc.
Page 222 062043-01-000 EA LABEL - FUEL - UNLEADED KEY PART NUMBER U/M DESCRIPTION 065748-01-000 EA LABEL - CAUTION - BATTERY CHARGING KEY PART NUMBER U/M DESCRIPTION 065748-02-000 EA LABEL - WARNING - BATTERY/FRENCH - CANADIAN Copyright © 2006 Winnebago Industries Inc.
Page 223 EA LABEL - WARNING - SMOKE DETECTOR KEY PART NUMBER U/M DESCRIPTION 079965-01-000 EA LABEL - LPG - 80% CAPACITY KEY PART NUMBER U/M DESCRIPTION 079966-01-000 EA LABEL - WARNING - STOWED - MOTION Copyright © 2006 Winnebago Industries Inc.
Page 224 U/M DESCRIPTION 087236-01-000 EA LABEL - CABLE - INPUT KEY PART NUMBER U/M DESCRIPTION 087236-02-000 EA LABEL - TV OUTLET KEY PART NUMBER U/M DESCRIPTION EA LABEL - A/C COVER "AIR CONDITIONING CIRCUIT ETC." 091243-01-000 Copyright © 2006 Winnebago Industries Inc.
Page 225 LABELS GROUP (CONTINUED) KEY PART NUMBER U/M DESCRIPTION 092547-06-000 EA LABEL - CIRCUIT BREAKER KEY PART NUMBER U/M DESCRIPTION 092547-07-000 EA LABEL - CIRCUIT BREAKER KEY PART NUMBER U/M DESCRIPTION 092547-08-000 EA LABEL - CIRCUIT BREAKER Copyright © 2006 Winnebago Industries Inc.
Page 226 EA LABEL - CIRCUIT BREAKER KEY PART NUMBER U/M DESCRIPTION 093236-13-000 EA LABEL - CIRCUIT BREAKER KEY PART NUMBER U/M DESCRIPTION 093236-15-000 EA LABEL - CIRCUIT BREAKER KEY PART NUMBER U/M DESCRIPTION 093236-16-000 EA LABEL - CIRCUIT BREAKER Copyright © 2006 Winnebago Industries Inc.
Page 227 EA LABEL - CIRCUIT BREAKER KEY PART NUMBER U/M DESCRIPTION 093236-19-000 EA LABEL - CIRCUIT BREAKER KEY PART NUMBER U/M DESCRIPTION 093236-20-000 EA LABEL - CIRCUIT BREAKER KEY PART NUMBER U/M DESCRIPTION 093236-21-000 EA LABEL - CIRCUIT BREAKER Copyright © 2006 Winnebago Industries Inc.
Page 228 EA LABEL - CONTROL CENTER - 30 AMP KEY PART NUMBER U/M DESCRIPTION 095721-26-000 EA LABEL - CONTROL CENTER - 30 AMP - CANADIAN KEY PART NUMBER U/M DESCRIPTION 095721-27-000 EA LABEL - CONTROL CENTER - 30 AM Copyright © 2006 Winnebago Industries Inc.
Page 229 EA LABEL - CONTROL CENTER - 50 AMP - US KEY PART NUMBER U/M DESCRIPTION 095721-34-000 EA LABEL - CONTROL CENTER - 50 AMP KEY PART NUMBER U/M DESCRIPTION 095721-38-000 EA LABEL - CONTROL CENTER - 30 AMP - US Copyright © 2006 Winnebago Industries Inc.
Page 230 U/M DESCRIPTION 098641-01-000 EA LABEL - FUEL - UNLEADED - DASH KEY PART NUMBER U/M DESCRIPTION 099509-01-000 EA LABEL - AWNING INSTALLATION KEY PART NUMBER U/M DESCRIPTION 099689-01-000 EA LABEL - WARNING - CANCER/TOXICITY Copyright © 2006 Winnebago Industries Inc.
Page 231 KEY PART NUMBER U/M DESCRIPTION 104678-01-000 EA LABEL - CB PREP KEY PART NUMBER U/M DESCRIPTION 107571-01-000 EA LABEL - EXIT/ESCAPE WINDOW KEY PART NUMBER U/M DESCRIPTION 109051-02-000 EA LABEL - SWITCH - 50 AMP POWER Copyright © 2006 Winnebago Industries Inc.
Page 232 EA LABEL - HITCH - READ MANUAL - WHITE 111104-02-000 EA LABEL - HITCH - READ MANUAL - BLACK KEY PART NUMBER U/M DESCRIPTION 111537-07-000 EA LABEL - FUSES KEY PART NUMBER U/M DESCRIPTION 111537-08-000 EA LABEL - FUSES Copyright © 2006 Winnebago Industries Inc.
Page 233 KEY PART NUMBER U/M DESCRIPTION 111537-09-000 EA LABEL - FUSES KEY PART NUMBER U/M DESCRIPTION 111802-01-000 EA LABEL - CFC WARNING KEY PART NUMBER U/M DESCRIPTION 113402-01-000 EA LABEL - CAUTION - WATER HEATER EXHAUST Copyright © 2006 Winnebago Industries Inc.
Page 234 EA LABEL - PHONE & CABLE INPUT - BLACK/CLEAR BACKGROUND KEY PART NUMBER U/M DESCRIPTION 115600-01-000 EA LABEL - WARNING LPG VALVE KEY PART NUMBER U/M DESCRIPTION 115869-01-000 EA LABEL - WARNING - TIRE Copyright © 2006 Winnebago Industries Inc.
Page 235 KEY PART NUMBER U/M DESCRIPTION 116549-01-000 EA LABEL - WARNING - SLIDEOUT KEY PART NUMBER U/M DESCRIPTION 116756-01-000 EA LABEL - WARNING ETHER/STARTING KEY PART NUMBER U/M DESCRIPTION 117629-03-000 EA LABEL - WATER PUMP/FILL-BLK LETTERS/CLEAR BACKGROUND-.31" Copyright © 2006 Winnebago Industries Inc.
Page 236 KEY PART NUMBER U/M DESCRIPTION 120431-01-000 EA LABEL - LOCATION - COAXIAL CABLE/SATELLITE ANTENNA KEY PART NUMBER U/M DESCRIPTION 120677-01-000 EA LABEL - TV KEY PART NUMBER U/M DESCRIPTION 123562-01-000 EA LABEL - SERVICE/UTILITY ACCESS Copyright © 2006 Winnebago Industries Inc.
Page 237 U/M DESCRIPTION 124520-01-01A EA LABEL - LP GAS ONLY - BLACK ON CLEAR 124520-01-02A EA LABEL - LP GAS ONLY - WHITE ON CLEAR KEY PART NUMBER U/M DESCRIPTION 124572-01-000 EA LABEL - SWITCHES Copyright © 2006 Winnebago Industries Inc.
Page 238 EA LABEL - GRAY HOLDING TANK-WHITE LETTERS/CLEAR BACKGROUND 126247-05-000 EA LABEL - GRAY HOLDING TANK-BLACK LETTERS/CLEAR BACKGROUND KEY PART NUMBER U/M DESCRIPTION 126247-02-000 EA LABEL - BLACK HOLDING TANK-WHITE LETTERS/BLACK BACKGROUND 126247-06-000 EA LABEL - BLACK HOLDING TANK-BLACK LETTERS/CLEAR BACKGROUND Copyright © 2006 Winnebago Industries Inc.
Page 239 EA LABEL - HANG TAG - AIR BAG - DASH KEY PART NUMBER U/M DESCRIPTION 127170-01-000 EA LABEL - WATER TANK DRAIN KEY PART NUMBER U/M DESCRIPTION 128218-01-01A EA LABEL - WARNING - SLIPPERY ROOF Copyright © 2006 Winnebago Industries Inc.
Page 240 EA LABEL - HITCH/VEHICLE RATE - 5OO - WHITE ON CLEAR 129669-02-02A EA LABEL - HITCH/VEHICLE RATE - 5OO - BLACK ON CLEAR KEY PART NUMBER U/M DESCRIPTION 129684-01-000 EA LABEL - TIRE ROTATION KEY PART NUMBER U/M DESCRIPTION 130166-01-000 EA LABEL - DRAIN Copyright © 2006 Winnebago Industries Inc.
Page 241 EA LABEL - SWITCH PANEL - BLK/CLEAR BACKGROUND-1.8"H X 5.9"L KEY PART NUMBER U/M DESCRIPTION 130170-02-000 EA LABEL - SWITCH PANEL - BLK/CLEAR BACKGROUND-1.4H X 3.9"L 117628-02-000 EA LABEL - SWITCH - WATER PUMP/LIGHTS-WHITE/CLEAR BACKGROUND Copyright © 2006 Winnebago Industries Inc.
Page 242 KEY PART NUMBER U/M DESCRIPTION 133423-01-01A EA LABEL - DRAIN KEY PART NUMBER U/M DESCRIPTION 133424-01-01A EA LABEL - BYPASS - WATER HEATER KEY PART NUMBER U/M DESCRIPTION 133425-01-01A EA LABEL - VALVE - WINTERIZATION Copyright © 2006 Winnebago Industries Inc.
Page 243 U/M DESCRIPTION 133533-02-01A EA LABEL - CHECK ANTENNA - CLEAR W/WHITE LETTERING KEY PART NUMBER U/M DESCRIPTION 133533-03-01A EA LABEL - LOCK/UNLOCK - BLACK/WHITE KEY PART NUMBER U/M DESCRIPTION 133629-01-01A EA LABEL - WATER CENTER Copyright © 2006 Winnebago Industries Inc.
Page 244 EA LABEL - WATER CENTER - BLACK/CLEAR KEY PART NUMBER U/M DESCRIPTION 134250-01-01A EA LABEL - SATELLITE RECEIVER - BLACK/CLEAR KEY PART NUMBER U/M DESCRIPTION 134538-01-01A EA LABEL - OCCUPANCY - NO SEAT BELT - BLACK ON CLEAR - US Copyright © 2006 Winnebago Industries Inc.
Page 245 U/M DESCRIPTION 134563-01-01A EA LABEL - SWITCH - HEATER KEY PART NUMBER U/M DESCRIPTION 135869-01-01A EA LABEL - MERCURY CONTENT - BLACK 0N CLEAR KEY PART NUMBER U/M DESCRIPTION 136047-01-01A EA LABEL - LIQUID SOAP Copyright © 2006 Winnebago Industries Inc.
Page 246 EA STICKER - STATIC CLING - ADVANTAGE 136164-01-16A EA STICKER - STATIC CLING - FREEDOM 136164-01-17A EA STICKER - STATIC CLING - KEY FEATURE KEY PART NUMBER U/M DESCRIPTION 136360-01-01A EA LABEL - AIR BAGS Copyright © 2006 Winnebago Industries Inc.
Page 247 LABELS GROUP (CONTINUED) KEY PART NUMBER U/M DESCRIPTION 093236-22-000 EA LABEL - CIRCUIT BREAKER KEY PART NUMBER U/M DESCRIPTION 136161-01-01A EA LABEL - RELAY - MATTE BLACK/WHITE LETTERS Copyright © 2006 Winnebago Industries Inc.
Page 248 EA LABEL - CIRCUIT BREAKER - MAIN KEY PART NUMBER U/M DESCRIPTION 116756-02-000 EA LABEL - WARNING - ETHER/STARTING KEY PART NUMBER U/M DESCRIPTION 116829-02-000 EA LABEL - COFFEEMAKER KEY PART NUMBER U/M DESCRIPTION 132651-01-01A EA DECAL - MIRROR/GALLEY Copyright © 2006 Winnebago Industries Inc.
Page 249 KEY PART NUMBER U/M DESCRIPTION 137090-01-000 EA LABEL - ELECTRICAL CENTER KEY PART NUMBER U/M DESCRIPTION 137090-02-000 EA LABEL - 4 MODULE BASE KEY PART NUMBER U/M DESCRIPTION 137997-01-01A EA LABEL - WINTERIZATION VALVE - BLACK/CLEAR Copyright © 2006 Winnebago Industries Inc.
Page 250: Lp Group
EA DETECTOR - LP GAS - W/O SHUT-OFF VALVE 105658-01-000 EA COMPARTMENT - LP REGULATOR 106150-01-000 EA REGULATOR - TWO STAGE-W/90 DEGREE ELBOW & 3/8" FPT OUTLET *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 251: Component Parts For Lp System
EA VALVE-FILL-SHORT, LP 7547B 040421-01-711 EA VALVE-80% FILL W/AUTO STOP LLL/TL3 040421-01-707 EA FLOAT/BOLT ON-SCREW ON DIAL 088253-09-700 EA FLOAT/SCREW IN-SNAP ON DIAL SG14C0001466 NOT WHAT IS ILLUSTRATED HERE NOT WHAT IS ILLUSTRATED HERE Copyright © 2006 Winnebago Industries Inc.
Page 252: Lounge Group
133119-01-M42 EA CABINET - OVERHEAD/FRONT - W/O DOORS/HARDWARE - W/O DELUXE SOUND 133119-02-M42 EA CABINET - OVERHEAD/FRONT - W/O DOORS/HARDWARE - W/ DELUXE SOUND 103128-02-M22 EA END CAP - OVERHEAD CABINET - LEFT HAND Copyright © 2006 Winnebago Industries Inc.
Page 253: Tables
FROM: 09-20-00 THRU: 99-99-99 119559-12-L81 EA CABINET/LEFT SIDE - F/PULLOUT TABLE - 8.3" X 28.7" FROM: 00-00-00 THRU: 09-19-00 136683-12-M53 EA CABINET/LEFT SIDE - F/PULLOUT TABLE - 5.7" X 28.7" FROM: 09-20-00 THRU: 99-99-99 Copyright © 2006 Winnebago Industries Inc.
Page 254: Sealants & Fasteners Group
EA FILM/ABRASION-RESISTANT - TRANSPARENT - 1" DIA. 110274-01-000 FT TAPE - DOUBLE SIDED/FOAM - .45" X 1" X 216' - BLACK 111940-02-000 LB SEALER - PUTTY - THUMBING 112864-01-000 FT SEAL - FOAM/BUTYL COVERED - 3/8" Copyright © 2006 Winnebago Industries Inc.
Page 255: Bolts, Nuts And Washers
EA BOLT - HEX - 7/16-20 X 2 1/2 - GRADE #5 - ZINC 000C13-07-48B EA BOLT - HEX - 7/16-20 X 3 - GRADE #5 - ZINC 000C14-07-20B EA BOLT - HEX - 7/16-14 X 1 1/4 - GRADE #8 - ZINC Copyright © 2006 Winnebago Industries Inc.
Page 256 EA WASHER - LOCKING - 1/2 MED SPLIT - ZINC 000E13-17-00B EA WASHER - FLAT - 3/8 AR - ZINC 000E13-18-00B EA WASHER - FLAT - 3/8 WIDE - ZINC 000E13-18-00K EA WASHER - FLAT - 3/8 WIDE - YELLOW CHROMATE Copyright © 2006 Winnebago Industries Inc.
Page 257 EA BOLT - HEX - SERRATED FLANGE - 1/2-20 X 1 3/4-GRADE 5 ZINC 135092-02-01A EA BOLT - HEX - SERRATED FLANGE - 1/2-20 X 2 1/2-GRADE 5 ZINC 135092-04-01A EA BOLT - HEX - SERRATED FLANGE - 1/2-20 X 4 1/2 GRADE 5 ZINC Copyright © 2006 Winnebago Industries Inc.
Page 258: Screws
EA SCREW - 8-18 X 3/8 PPH BRASS 000G11-08-06B EA SCREW - 8-18 X 3/8 PPH - ZINC 000G11-08-20B EA SCREW - 8-18 X 1 1/4 PPH - ZINC 000G11-08-10B EA SCREW - 8-18 X 1/2 PPH - ZINC Copyright © 2006 Winnebago Industries Inc.
Page 259 EA SCREW - SF/DR - 8-18 X 1/2 PPH - BLACK 000G39-10-088 EA SCREW - SF/DR - 10-16 X 1/2 PPH - FLEX FLUOROCARBON 000G39-10-08B EA SCREW - SF/DR - 10-16 X 1/2 PPH - ZINC Copyright © 2006 Winnebago Industries Inc.
Page 260 EA SCREW - 10-12 X 1/2 PPH - OFF WHITE 000G67-10-08B EA SCREW - 10-12 X 1/2 PPH - ZINC 000G67-10-48B EA SCREW - 10-12 X 3 PPH - ZINC 000G67-10-36T EA SCREW - 10-12 X 2 1/4 - PPH - BLACK Copyright © 2006 Winnebago Industries Inc.
Page 261 EA SCREW - EUROPEAN M6.3 X 10 134126-01-01A EA SCREW/NAIL - HEX HEAD - 3/4" 134126-02-01A EA SCREW/NAIL - HEX HEAD - 1 1/4" 140040-01-000 EA SCREW - 1/4-20X1 - BUTTON HEAD SOCKET - W/LOCTITE Copyright © 2006 Winnebago Industries Inc.
Page 262: Clamps, Clips, Grommets, Rivets & Plugs
EA PLUG/PLASTIC - .46 DIAMETER - BLACK 083609-01-000 EA CLAMP - WIRE - DUAL - EQUAL DIAMETERS - 5/8" 083610-01-000 EA CLAMP - WIRE - DUAL - UNEQUAL DIAMETERS - 3/4" & 1 1/4" Copyright © 2006 Winnebago Industries Inc.
Page 263: Miscellaneous Fasteners
EA RIVET - POP - ALUMINUM - 3/16 X .252 - .504 - BLACK 115361-01-01A EA PLUG/PLASTIC - 1/2" DIAMETER 123816-04-000 FT TAPE - DOUBLE SIDED - 6" X 750' 127960-01-01A EA RETAINER - 3/8" - STAINLESS STEEL Copyright © 2006 Winnebago Industries Inc.
Page 264: Water & Sewage Group
EA TEE - PLASTIC - 3" FEMALE FROM: 00-00-00 THRU: 10-08-00 062415-01-000 EA CAP - SEWER - 3" DIAMETER FROM: 00-00-00 THRU: 10-08-00 062417-01-000 EA ADAPTER - TERMINATION - 3" FROM: 00-00-00 THRU: 11-05-00 Copyright © 2006 Winnebago Industries Inc.
Page 265 FROM: 00-00-00 THRU: 06-10-01 139513-01-000 EA HOSE - SEWER - 3" X 10í - W/ADAPTER FROM: 06-11-01 THRU: 99-99-99 123283-03-02B EA BRACKET - WATER TANK - E-COATED *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 266: Component Parts For Drainage System
EA BOWL/CHINA 310615 085330-04-701 EA HAND SPRAY W/HOSE(500 & 900) 340683 085330-06-701 EA BREAKER-VACUUM/DIVERTER(900) 230335 CONTACT WINNEBAGO PART SALES FOR THIS COMPONENT 085330-01-703 EA RING & HALF CLAMPS, BONE 385310048 085330-01-704 EA TEFLON & RUBBER SEAL KIT 385316140 085330-01-706 EA BALL(FLAPPER)SHAFT/CARTRIDGE...
Page 267: Water System
EA ELBOW - 1.3" BARB X 1.3" BARB - 90 DEGREE - PLASTIC 010009-01-000 EA ELBOW - 90 DEGREE - 1/4 BEND - 1 1/2" PLASTIC 132782-01-000 EA ELBOW - 1"FPT X 1.3" BARB - 90 DEGREE - PLASTIC Copyright © 2006 Winnebago Industries Inc.
Page 268 044927-01-000 EA ADAPTER - HOSE TO PIPE-1 1/4 MPTX1 1/4 BARB-BLACK PLASTIC 133835-01-000 EA ADAPTER - REDUCING - 1 1/2" X 1 1/4" 123152-01-000 EA ADAPTER - 1/2 FPT X 1/2 BARB - SWIVEL Copyright © 2006 Winnebago Industries Inc.
Page 269 EA FITTING - BRASS-TEE - 1/4C X 1/4C X 1/4C 120868-01-000 EA VALVE - NEEDLE - 1/4" COMPRESSION X 1/4" COMPRESSION 114431-05-000 EA VALVE - NEEDLE - 1/8" MPT X 1/4" COMPRESSION (ICE MAKER) Copyright © 2006 Winnebago Industries Inc.
Page 270 FT TUBING - POLYBUTYL - 1/4"OD 077954-02-000 EA FILTER - WATER TANK - W/SCREEN IN TANK 114966-01-000 EA FILTER - IN LINE - TWIST ON - 1/2" 133889-01-000 EA UNION - 1 1/2 DOUBLE SLIP - PVC Copyright © 2006 Winnebago Industries Inc.
Page 271 EA INLET - WATER - FLUSHING SYSTEM 125697-04-000 EA BREAKER - VACUUM - FLUSHING SYSTEM 125697-03-000 EA CHECK VALVE - FLUSHING SYSTEM 125697-02-000 EA NOZZLE - WELD-A-FLUSH 125697-06-000 EA INSTRUCTIONS - USER - FLUSHING SYSTEM Copyright © 2006 Winnebago Industries Inc.
Page 272 EA CYLINDER - LOCKING 138289-06-000 EA CYLINDER - LOCKING 138289-07-000 EA CYLINDER - LOCKING 138289-08-000 EA CYLINDER - LOCKING 138289-09-000 EA CYLINDER - LOCKING 138289-10-000 EA CYLINDER - LOCKING *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 273 EA TANK - WATER - 40 GAL - W/FITTINGS - SECONDARY 132224-04-000 EA TANK - WATER - 40 GAL - W/FITTINGS - PRIMAR 132224-01-000 EA TANK - WATER - 40 GALLON - W/O FITTINGS Copyright © 2006 Winnebago Industries Inc.
Page 274: Component Parts For Water System
WATER & SEWAGE GROUP (CONTINUED) COMPONENT PARTS FOR WATER SYSTEM Yellow Dot Appears Between Leads on ECO Brown (a) Brown (b) Red (a) Red (b) 051391-05-000 Copyright © 2006 Winnebago Industries Inc.
Page 275: 131340-01-01A
EA HOUSING, W/SWITCH ONLY 94-231-20 098607-01-707 EA MOTOR W/BASEPLATE 11-148-04 131340-01-01A KEY PART NUMBER U/M DESCRIPTION VENDOR NO 131340-01-700 EA BUTTON - HOT/COLD N1201-16 131340-01-701 EA KNOB - CLEAR N1201-9 119677-01-701 EA SHOWER HEAD ONLY 1/2" 34PB Copyright © 2006 Winnebago Industries Inc.
Page 276: 135027-01-01A
EA DIVERTER-PUSH BUTTON-CHROME 1394 135027-01-703 EA HANDLE/EXT - 1" - CHROME 1136 135027-01-704 EA BALANCING SPOON 1423 135027-01-705 EA CARTRIDGE REPLACEMENT 1200-1225 135027-01-706 EA ESCUTCHEON - GOLD 150T 135027-01-707 EA KNOB KIT - CLEAR PLASTIC 13094 Copyright © 2006 Winnebago Industries Inc.
Page 277: Window & Vents Group
EA PANEL - SKYLIGHT - INNER W/LIGHT CUTOUT - 20.7" X 35.4" - G32V, G35U 122214-01-02A EA PANEL - SKYLITE - INNER - W/ANGLED CORNER - WHITE - G35B, G37G *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 278 EA WINDOW - PASSENGER HORIZ SLIDER - THERMO - 28.5" X 15.7" 112463-03-02A EA WINDOW - TIPOUT W/RETAINER - 33.3" X 30.2" 129929-09-01A EA WINDOW - TORQUE - THERMO - 30" X 33" *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 279: Component Parts For Windows & Vent Layout
FT WEATHERSTRIP - SCREEN BLACK 171-016965 098644-12-700 EA GLASS - STATIONARY 106-026015 098644-12-701 EA GLASS - SLIDING W/SASH/LATCH H080-G9 098644-12-702 EA SCREEN ASM - W/SEALS/CLIPS 410-016483 098644-12-703 EA RETAINER - TRIM 808060 098644-01-717 FT SPLINE - SCREEN 132-004716 Copyright © 2006 Winnebago Industries Inc.
Page 280: 098644-13-01A
FT WEATHERSTRIP - SCREEN BLACK 171-016965 098644-13-700 EA GLASS - STATIONARY 106-028698 098644-13-701 EA GLASS - SLIDING W/SASH/LATCH H702-G9 098644-13-702 EA SCREEN ASM - W/SEALS/CLIPS 410-028663 098644-13-703 EA RETAINER - TRIM H702-60 098644-01-717 FT SPLINE - SCREEN 132-004716 Copyright © 2006 Winnebago Industries Inc.
Page 281: 098647-25-02A
098647-25-702 EA GLASS - STATIONARY 106-017657 098647-25-703 EA GLASS-SLIDING W/SASH & LATCH H286-G9 098647-25-704 EA SCREEN ASM - W/SEALS & CLIPS 410-019065 098647-25-705 EA RETAINER - TRIM H286-66 098644-01-717 FT SPLINE - SCREEN 132-004716 Copyright © 2006 Winnebago Industries Inc.
Page 282: 098647-33-02A
098647-47-700 EA GLASS - STATIONARY 106-025224 098647-47-701 EA GLASS-SLIDING W/SASH & LATCH H493-G9 098647-47-702 EA SCREEN ASM - W/SEALS & CLIPS 410-025226 098647-47-704 EA RETAINER - TRIM H493-66 098644-01-717 FT SPLINE - SCREEN 132-004716 Copyright © 2006 Winnebago Industries Inc.
Page 283: 112463-03-02A
EA VENT- ASSEMBLY TIPOUT 106-018414 112463-05-702 EA OPERATOR & BAR ASSEMBLY CH65-15 112463-05-701 EA SCREEN ASM - W/SEALS & CLIPS 410-018441 112898-06-704 EA HANDLE-LATCH/RED-RH (TIPOUT) 182-11293 112898-06-705 EA HANDLE-LATCH/RED-LH (TIPOUT) 182-11294 100322-01-717 EA E-RING 245-015975 Copyright © 2006 Winnebago Industries Inc.
Page 284: 112795-71-01A
FT WEATHERSTRIP - SCREEN BLACK 171-016965 112795-71-700 EA GLASS - STATIONARY 390-028380 112795-71-701 EA GLASS - SLIDING W/SASH LATCH DH286-G8 098647-25-704 EA SCREEN ASSY - W/SEAL & CLIPS 410-019065 098647-25-705 EA RETAINER - TRIM H286-66 Copyright © 2006 Winnebago Industries Inc.
Page 285: 112795-72-01A
EA VENT - ROOF - W/FAN/POWER LIFT - W/O INSIDE GARNISH - CSA 064469-03-708 EA GEAR-DRIVE RP-1024 064470-01-700 EA COVER - VENT J7291 064470-01-701 EA SLIDE BAR - VENT LID JRP1291B 110051-07-701 EA MOTOR-LIFT, W/BRKT-GEAR 3/16 RP1099B 122882-04-700 EA SCREEN J29-670-01A Copyright © 2006 Winnebago Industries Inc.
Page 286: 123780-03-01A
705221K38 123780-01-702 EA SCREEN W/FRAME 103581 123780-03-700 EA GARNISH - INT. 3"-4" BRT/WHT 2040-81 084079-01-703 EA KNOB-LIFT, W/EXT. & SCREW 1140K-00 123780-03-701 EA SCREEN ASM 78-100MM W/SWITCH 1030BT-81 084079-01-706 EA PLUG, 12 VOLT 1090 Copyright © 2006 Winnebago Industries Inc.
Page 287: 123780-10-01A
084079-01-710 EA THERMOSTAT, WALL MOUNT 9988-39 123780-05-701 EA SCREEN ASM., INT W/SWITCHES 2000TK-81 084079-11-705 EA MOTOR - LIFT (BC MOTOR) 5050-40 084079-11-703 EA MOTOR-LIFT (AUTOTROL) W/CAP 6050-05 CONTACT WINNEBAGO PART SALES FOR UNLISTED COMPONENTS Copyright © 2006 Winnebago Industries Inc.
Page 288: 125582-01-01A
EA GLASS - STATIONARY - UPPER 106-026082 098644-01-717 FT SPLINE - SCREEN 132-004716 112520-01-706 EA WEATHERSTRIP-SCREEN, (FUZZY) 171-017245 125582-01-708 EA WEEPHOLE COVER - RIGHT HAND 130-026598 125582-01-709 EA WEEPHOLE COVER - LEFT HAND 130-026599 Copyright © 2006 Winnebago Industries Inc.
Page 289: 125583-01-01A
H57027L 125600-01-01A KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 125600-01-01A EA WINDOW - VISTA - THERMOPANE 125600-01-700 EA GLASS - STATIONARY 390026099 116000-01-704 EA VINYL - GLAZING 132-018161 125586-01-701 EA RETAINER - TRIM H57027L Copyright © 2006 Winnebago Industries Inc.
Page 290: 129929-09-01A
390-028300 129929-10-701 EA VENT GLASS ASSEMBLY DTH002-G8 129929-02-702 EA SCREEN ASM - W/SEALS & CLIPS 410-026861 129929-02-707 EA RETAINER - TRIM CH10162 129929-02-704 EA OPERATOR BAR ASSEMBLY DTH002-15 129929-02-706 FT SEAL - FOAM 140-027022 Copyright © 2006 Winnebago Industries Inc.
Page 292: 134004-03-01A
134004-03-702 EA RETAINER - TRIM H702-56 098644-13-702 EA SCREEN ASM W/SEALS & CLIPS 410-028663 134004-03-701 EA GLASS-SLIDING W/SASH & LATCH DH702-G8 112898-04-703 EA VERTICAL LATCH (SASH KIT) DH343-CK 098644-01-717 FT SPLINE - SCREEN 132-004716 Copyright © 2006 Winnebago Industries Inc.
Page 293: Windshield & Wiper Group
EA TRIM - WINDSHIELD - A-PILLAR - DRIVER - BLACK 081914-02-000 EA BUMPER - RUBBER - ROUND - 5/16" DIA. X 13/64" THICK 099418-01-000 FT SEAL - D-SECTION/ADHESIVE BACK - .44" X .44"- BLK RUBBER Copyright © 2006 Winnebago Industries Inc.
Page 294: Wiper
EA SHAFT - ADAPTER - PANTOGRAPH ARM 117769-01-000 EA ARM - WIPER - PANTOGRAPH - 28" 110742-02-000 EA GASKET - NEOPRENE - WIPER ADAPTER SHAFT - .5" ID X .9" OD *COMPONENT PARTS LISTED LATER IN THIS GROUP Copyright © 2006 Winnebago Industries Inc.
Page 295: Component Parts For Wiper
EA CAP-NUT(ACORN) HD W/.687 BRL 51065-40-NT27WC 117769-01-000 KEY PART NUMBER U/M DESCRIPTION VENDOR NO. 117769-01-000 EA ARM - WIPER - PANTOGRAPH - 28" UT 6701620LE25WJ 096931-01-700 FT HOSE-WIPER XTU-66-0001 117769-01-700 EA RETAINER CLIP - HOSE Copyright © 2006 Winnebago Industries Inc.

Winnebago WFG35U 2001 Manual

Floorplan

Accessories Group

Appliance Group

Audio Video Group

Bath Group

Bedroom Group

Chassis Group

Curtain & Cushion Group

Dinette Group

Drivers Compartment Group

Electrical Group

Exterior Body Group

Exterior Doors & Compartments Group

Exterior Slideout Group

Galley Group

Generator Group

Heating & A/C Group

Interior Finish Group

Labels Group

Lp Group

Lounge Group

Sealants & Fasteners Group

Water & Sewage Group

Window & Vents Group

Windshield & Wiper Group

Quick Links

Need help?

Questions and answers

Related Manuals for Winnebago WFG35U 2001

Summary of Contents for Winnebago WFG35U 2001
