FYI: In some systems, the time for the billing or modem management system to update with the
most recent cable modem client table information may take a few minutes to a few hours. If you
have alternative means to find out the IP address assigned to the client with the DigiVu MAC
address more rapidly, you can save time as the DigiVu is available for remote access as soon as
the new IP address is acquired, regardless of whether the billing or modem management system
has this information.
Once you have the assigned public IP address of the DigiVu:
1. Open an Internet Explorer web browser and in the address bar enter 'http://xxx.xxx.xxx.xxx/site' replacing the x's with
the IP address of the unit.
2. When the login screen appears, enter the Username and Password for the unit.
3. Upon validation of the login and password, the GUI opens and displays the 'DVIS Settings' page. The unit is ready
to be managed remotely.
5.6.7 Static IP Address Assigned
1. Login to a computer with internet access. If you are using the same computer that was used for direct connection to
the DigiVu, remember to restore the computer's network settings to the appropriate values (the settings used prior to
changes made for connection to the DigiVu or other settings, as appropriate).
2. Open a new Internet Explorer browser window to establish a fresh internet session entering the IP address of the
DigiVu GUI in the address window.
3. You should be presented with the following screen on the left, prompting you to log in:
When the login screen, above left, appears prompting you to log in, enter an appropriate User Name and Password for the
unit from the table below. When the login username and password are successfully entered, the default screen, above right,
will be presented.
DigiVu Series Multichannel MPEG-2/H.264 Encoder/Multiplexer with QAM &/or IP Output - Installation & Operation Manual
®
Factory Default Username and Password
Username
atx
Figure 5-9: Prompt for
Username & Password
Password
atx
Figure 5-10: Default Screen when Logged In
