Operating Instructions
Memory Card Camera-Recorder
AU-V35LT1G
Model No.
Before using this product, be sure to read "Read this first!" (pages 3 to 6).
For more information, please visit the Panasonic website (http://pro-av.panasonic.
ENGLISH
net/en/manual/index.html), and refer to the Operating Guide for VariCam LT.
Bitte lesen Sie sorgfältig die „Bitte lesen Sie zuerst diesen Hinweis!" vor der
DEUTSCH
Nutzung dieses Produkts. (Seiten 7 bis 8).
Avant d'utiliser cet appareil, assurez-vous de lire la section « Lire ces
FRANÇAIS
informations en premier ! " (pages 9 à 10).
Prima di utilizzare il prodotto, assicurarsi di leggere "Leggere prima quanto
ITALIANO
segue!" (pagine 11 a 12).
Antes de usar este producto, asegúrese de leer "Lea esto primero" (páginas 13
ESPAÑOL
a 14).
Please carefully read this manual, and save this manual for future use.
ENGLISH

Advertisement

   Also See for Panasonic AU-V35LT1G

   Related Manuals for Panasonic AU-V35LT1G

   Summary of Contents for Panasonic AU-V35LT1G

  • Page 1

    AU-V35LT1G Model No. Before using this product, be sure to read “Read this first!” (pages 3 to 6). For more information, please visit the Panasonic website (http://pro-av.panasonic. ENGLISH net/en/manual/index.html), and refer to the Operating Guide for VariCam LT. Bitte lesen Sie sorgfältig die „Bitte lesen Sie zuerst diesen Hinweis!“ vor der DEUTSCH Nutzung dieses Produkts.

  • Page 2

    Vizitați următoarea pagină web pentru informaţii de securitate și notificări importante cu Română privire la produs. Za varnostne informacije in pomembna obvestila v zvezi z izdelkom obiščite naslednje Slovenščina spletno mesto. Pre bezpečnostné informácie a dôležité oznámenia súvisiace s produktom navštívte túto Slovensky webovú stránku. http://pro-av.panasonic.net/en/manual/index.html...

  • Page 3: Read This First

    Read this first! Read this first! indicates safety information. WARNING: CAUTION: f To reduce the risk of fire, do not expose Do not lift the unit by its handle while this equipment to rain or moisture. the tripod is attached. When the tripod is attached, its weight will also affect the f To reduce the risk of fire, keep this unit’s handle, possibly causing the handle...

  • Page 4

    Read this first! indicates safety information. FCC NOTICE (USA) CAUTION: This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 5

    Directive 1999/5/EC. Customers can download a copy of the original DoC for this product from our DoC server: http://www.ptc.panasonic.de/ Manufactured by: Panasonic Corporation, Osaka, Japan Importer’s name and address of pursuant to EU rules: Panasonic Marketing Europe GmbH Panasonic Testing Centre...

  • Page 6

    Read this first! Декларація про Відповідність Вимогам Технічного Регламенту Обмеження Використання деяких Небезпечних Речовин в електричному та електронному обладнанні (затвердженого Постановою №1057 Кабінету Міністрів України) Виріб відповідає вимогам Технічного Регламенту Обмеження Використання деяких Небезпечних Речовин в електричному та електронному обладнанні (ТР ОВНР). Вміст...

  • Page 7: Bitte Lesen Sie Zuerst Diesen Hinweis

    Bitte lesen Sie zuerst diesen Hinweis! DEUTSCH Bitte lesen Sie zuerst diesen Hinweis! ist die Sicherheitsinformation. WARNUNG: VORSICHT: f Setzen Sie dieses Gerät zur Reduzierung Heben Sie die Kamera nicht am Handgriff der Brandgefahr weder Nässe noch an, während sie am Stativ befestigt ist. Das Feuchtigkeit aus.

  • Page 8

    DEUTSCH Bitte lesen Sie zuerst diesen Hinweis! Hergestellt von: Panasonic Corporation, Osaka, Japan Name und Adresse des Importeurs gemäß EU-Bestimmungen: Panasonic Marketing Europe GmbH Panasonic Testing Centre Winsbergring 11, 22525 Hamburg, Deutschland ENTFERNEN DER BATTERIE Hauptbatterie (Ni-Cd / Ni-MH / Li-ion Batterie) f Um die Batterie zu entfernen, gehen Sie in der umgekehrten Reihenfolge wie die der in dieser Bedienungsanleitung beschriebenen Installation vor.

  • Page 9: Lire Ces Informations En Premier

    Lire ces informations en premier ! FRANÇAIS Lire ces informations en premier ! Informations concernant la sécurité. AVERTISSEMENT: ATTENTION: f Pour réduire les risques d’incendie, évitez Ne pas soulever l’appareil par sa poignée d’exposer cet appareil à la pluie ou à alors que le trépied est fixé.

  • Page 10

    FRANÇAIS Lire ces informations en premier ! Fabriqué par : Panasonic Corporation, Osaka, Japon Nom et adresse de l’importateur en accord avec les règlements de l’Union Européenne : Panasonic Marketing Europe GmbH Panasonic Testing Centre Winsbergring 11, 22525 Hamburg, Allemagne POUR ENLEVER LA BATTERIE Batterie d’alimentation principale (batterie Ni-Cd / Ni-MH / Li-ion)

  • Page 11: Leggere Prima Quanto Segue

    Leggere prima quanto segue! ITALIANO Leggere prima quanto segue! sono le informazioni sulla sicurezza. ATTENZIONE: PRECAUZIONE: f Per ridurre il pericolo di incendio, non Non sollevare l’unità per il suo manico esporre questa apparecchiatura a pioggia mentre il treppiede è attaccato. Quando il o umidità.

  • Page 12

    ITALIANO Leggere prima quanto segue! Fabbricato da: Panasonic Corporation, Osaka, Giappone Nome e indirizzo dell’importatore in conformità con le normative UE: Panasonic Marketing Europe GmbH Panasonic Testing Centre Winsbergring 11, 22525 Hamburg, Germania PER RIMUOVERE LA BATTERIA Batteria di almentazione (batteria Ni-Cd / Ni-MH / ioni di litio) f Per estrarre la batteria, procedere nell’ordine inverso rispetto alla procedura di installazione...

  • Page 13: Lea Esto Primero

    Lea esto primero ESPAÑOL Lea esto primero indica información de seguridad. ADVERTENCIA: PRECAUCIÓN: f Para reducir el riesgo de producir un No levante la unidad por el asa cuando incendio, no exponga este equipo a la está instalado el trípode. Si el trípode se lluvia ni a la humedad.

  • Page 14

    ESPAÑOL Lea esto primero Fabricado por: Panasonic Corporation, Osaka, Japón Nombre y dirección del importador conforme a las normas de la UE: Panasonic Marketing Europe GmbH Panasonic Testing Centre Winsbergring 11, 22525 Hamburg, Alemania EXTRACCIÓN DE LA BATERÍA Batería de Alimentación Principal (Batería de Ni-Cd / Ni-MH / Li-ion) f Para extraer la batería, repita los pasos de la instalación de la misma, descritos en el manual,...

  • Page 15

    f SDXC logo is a trademark of SD-3C, LLC. f All other names, company names, product names, etc., contained in this document are trademarks or registered trademarks of their respective owners. f This product is licensed under the AVC Patent Portfolio License. All other acts are not licensed except private use for personal and non-profit purposes such as what are described below.

  • Page 16: Table Of Contents

    Contents Contents Read this first! Bitte lesen Sie zuerst diesen Hinweis! Lire ces informations en premier ! Leggere prima quanto segue! Lea esto primero Accessories Description of Parts Left side Right side Front Rear Bottom Mounting the module Mounting the control panel Power supply Using the external DC power supply Updating the camera firmware...

  • Page 17

    7 This product includes software licensed under MOZILLA PUBLIC LICENSE. For details on these descriptions (originally provided in English) and how to obtain the source code, visit the following website. http://pro-av.panasonic.net/ We do not accept inquiries about the details of the source code obtained by the customer.

  • Page 18: Accessories

    Accessories Accessories f Mount cap (already attached to the camera module) f Control panel f Control panel mounting part f Glass for IR recording f Control panel mounting part clamping screw (4 pcs.) NOTE t After unpacking the product, dispose of the packing material properly.

  • Page 19: Description Of Parts

    Description of Parts Description of Parts Left side 11 12 14 15 16 17 18 19 1 Accessory mounting holes For attaching accessories. f Mounting hole size - 3/8-16 UNC 2 Handle 3 Lens flange back adjustment hole Used when adjusting the lens flange back. 4 Focus hook/focus mark <...

  • Page 20

    Description of Parts 10 Fan inlet Fan inlet for dissipating heat. Do not block this when the camera is in use. 11 <TOGGLE/WB> switch [WB]/[EI]/[SHUTTER] can be assigned. [WB] is assigned as the factory setting. Press and hold upward to operate the automatic white balance. 12 Power switch Used to switch the power to on <l>...

  • Page 21: Right Side

    Description of Parts Right side 1 Accessory mounting holes For attaching accessories. f Mounting hole size - 3/8-16 UNC 2 <CONTROL PANEL> terminal A terminal to connect the control panel. 3 <SDI OUT1>/<SDI OUT2> terminal Output terminals of 3G/HD SDI for video monitor. For the cable to connect to this terminal, prepare a double-shielded cable equivalent to 5C-FB.

  • Page 22: Front

    Description of Parts 10 Accessory mounting holes For attaching accessories. f Mounting hole size - 1/4-20 UNC (screw length 5.5 mm or shorter) 11 <USB HOST> terminal (inside the cover, 5.0 V 0.5 A max) For mounting the wireless module AJ-WM30 (optional). For the cable to connect to this terminal, prepare a double-shielded cable.

  • Page 23: Rear

    Description of Parts 3 EF lens mount EF lens is mounted. 4 <FILTER> dial <1><CLEAR>: Does not use the ND filter. <2><0.6ND>: Reduces the amount of light entering the MOS sensor to 1/4. <3><1.2ND>: Reduces the amount of light entering the MOS sensor to 1/16. <4><1.8ND>: Reduces the amount of light entering the MOS sensor to 1/64.

  • Page 24: Top

    Description of Parts 1 Viewfinder mounting holes For attaching the viewfinder. 2 Accessory mounting holes For attaching accessories. f Mounting hole size - 1/4-20 UNC - 3/8-16 UNC 3 GPS module position This part has a built-in GPS module. Do not cover this part with metallic objects when the GPS is in use.

  • Page 25: Bottom

    Description of Parts Bottom 1 Shoulder mount module/tripod mounting holes For attaching the shoulder mount module or a tripod. f Mounting hole size - 1/4-20 UNC (screw length 5.5 mm or shorter) - 3/8-16 UNC (screw length 5.5 mm or shorter)

  • Page 26: Mounting The Module

    Mounting the module Mounting the module Mounting the control panel The control panel is used by connecting the control panel cable to the <CONTROL PANEL> terminal at the rear of the camera. Normal operation may not be possible when the control panel is mounted or removed while the power is turned on.

  • Page 27: Power Supply

    Power supply Power supply Using the external DC power supply External DC power supply <DC IN> terminal DC cable Connect the external DC power supply to the <DC IN> terminal of the camera. Turn on the power switch of the external DC power supply (if the external DC power supply has a power switch).

  • Page 28

    Power supply DC IN +12 V Panasonic Parts No.: K1AA104H0038 Manufacturer Parts No.: HA16RX-4P (SW1) (76) (Hirose Electric Co.) NOTE t When both the battery and the external DC power supply are connected, the power supply from the external DC power supply has priority. The battery may be removed while using the external DC power supply.

  • Page 29: Updating The Camera Firmware

    Use the camera or P2 Viewer Plus to format the SD memory card. Fig. 1 Download the firmware from the website. http://pro-av.panasonic.net/ Save the downloaded firmware to an SD memory card. Insert the SD memory card with the firmware into the sub slot.

  • Page 30: Storing

    Storing t Update is also possible from [MENU] → [SYSTEM SETTINGS] → [INFORMATION] → [UPDATE]. Storing Cautions when storing the camera recorder Remove the battery when storing. Store each in a location with low humidity and that the temperature is relatively constant.

  • Page 31: Specifications

    Specifications Specifications For details on specifications, visit the Panasonic website (http://pro-av.panasonic.net/en/manual/index. html) and refer to the Operating Guide (HTML version). General Power DC e 12 V (11.0 V – 17.0 V) Power consumption 47 W (body only) 77 W (with all optional accessories connected and maximum power supplied from each output terminal) indicates safety information.

  • Page 32
