Driving Recorder
Model:CY-VRP112T1/T2/T3/T4/T5

Operating Instructions

Please read this instructions carefully before using this product and
keep this manual for future reference.
24240481301-A PTW0813-0 Printed in China

Advertisement

   Related Manuals for Panasonic CY-VRP112T1

No related manuals

   Summary of Contents for Panasonic CY-VRP112T1

  • Page 1: Operating Instructions

    Driving Recorder Model:CY-VRP112T1/T2/T3/T4/T5 Operating Instructions Please read this instructions carefully before using this product and keep this manual for future reference. 24240481301-A PTW0813-0 Printed in China...

  • Page 2: Table Of Contents

    Contents Safety Information ..............3 FCC Statement ..............8 WEEE Notice ................. 9 CE Regulatory Notice ............10 Notes on Installation ............10 Caution ................. 11 Introduction ..............12 Features ..............12 Package Contents............. 12 Product Overview............12 Getting Started.............. 14 Inserting the Memory Card ........

  • Page 3

    3.1.3 Record all other types of videos ....22 3.1.4 Emergency Recording ........22 3.1.5 The Recording Screen ........23 3.1.6 Taking Photographs........24 3.1.7 4 GRID FUNCTION CHART in the LCD screen …………………………………………………..25 Playback Videos and Photos ........26 3.2.1 Playing Videos ..........

  • Page 4: Safety Information

    Safety Information This pictograph intends to alert you to the presence of important operating instructions and installation instructions. Failure to heed the instructions may Warning result in severe injury or death. Warning Observe the following warnings when operating this unit. ■...

  • Page 5

    ■ Keep optional accessories (SD Card, etc.) away from the reach of children. There are risks that children may swallow the accessory. Keep accessories away from the reach of children. In the event of swallowing any the accessory, seek medical care immediately.

  • Page 6

    Safety Information Warning Observe the following warnings when installing this unit. ■ Install the product so that it does not hinder the view of the vehicle. ■ Never install the unit within the range of air bag movement or in a position that obstructs activation of the of air bag. Please also verify warnings and precautions regarding the vehicle’s air bag.

  • Page 7

    Safety Information Caution Observe the following cautions when using this unit. ■ When disposing of the unit, follow statutory regulations to recycle the built-in lithium battery, so as to prevent environmental pollution. ■ For some vehicles, the unit continues recording after the engine has being shut off.

  • Page 8

    Safety Information Caution Observe the following cautions when installing this unit. ■ It is recommended that the unit should be installation by a professional. The installation requires specialty and technical experience; to ensure safety, entrust the dealer to carry out the installation. ■...

  • Page 9: Fcc Statement

    FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 10: Weee Notice

    WEEE Notice Information for Users on Collection and Disposal of Old Equipment and Used Batteries These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should not be mixed with general household waste. For proper treatment, recovery and recycling of old products and used batteries, please take them to applicable collection points, in accordance with your...

  • Page 11: Ce Regulatory Notice

    CE Regulatory Notice Herewith confirm to comply with the requirements set out in the Council Directives on the Approximation of the Laws of the Member States relating Electromagnetic Compatibility of Radio and Telecom device (1995/5/EC); the Low Voltage Directive (2006/95/EC); the Restriction of The Use of Certain Hazardous Substances in Electrical And Electronic Equipment Directive (2002/95/EC), Turkish EEE Directive;...

  • Page 12: Caution

    Caution  Use the authorized charger only.  Never disassemble by yourself.  Never short-circuit the battery.  Dispose of the battery properly.  Exposing the battery to open flames can cause explosion.  Due to local laws and vehicles safety considerations, do not operate the device while driving.

  • Page 13: Introduction

    1 Introduction 1.1 Features • Full HD Car Camcorder (1920x1080 @ 30fps) • 2.4” LCD color screen • 128 degree Wide angle lens • Motion detection • Automatic Emergency recording for collision detection • Supports Micro-SDHC up to 32GB (Class 6 or greater speed required for HD video) 1.2 Package Contents The package contains the following items.

  • Page 14: Product Overview

    1.3 Product Overview Front View Top and Bottom Views Side (Left and Right) Views Rear View Item Item Bracket Socket LED Light Microphone LCD Panel Power Button Up Button ( Memory Card Slot Down Button ( USB Connector Enter Button ( HD(Mini HDMI) Connector Wide Angle Lens Back Button (...

  • Page 15: Getting Started

    2 Getting Started 2.1 Inserting the Memory Card Insert the memory card with the gold contacts facing the back of the camcorder. Push the memory card until it clicks into place. (Use class 6 or above the micro SD cards for this camcorder; It is recommended to format the micro SD cards before the initial use.) To remove the memory card Push to eject the memory card out of the slot.

  • Page 16: Installing In Vehicles

    2.2 Installing in Vehicles 2.2.1 Mount to Windshield Attach the bracket to the device. Slide it into the bracket holder until you hear a click. With the suction-cup laying flat, position the suction-cup on the windshield. Hold the base firmly on the windshield and press down the clamp to mount the car holder to the windshield.

  • Page 17: Adjust The Device Position

    2.2.2 Adjust the device position Loose the knob to swivel the device vertically. Knob Loose the knob to swivel the device horizontally up to 360°. Knob Then tighten the knob to make sure the device is securely locked in place.

  • Page 18: Connecting To Power

    2.3 Connecting to Power Use only the exclusive car adapter to power up the device and charge the built-in battery. Connect one end of the car adapter to the USB connector of the camcorder. Plug the other end of the car charger to the cigarette lighter socket of your vehicle.

  • Page 19: Powering The Camcorder On / Off

    2.4 Powering the Camcorder On / Off 2.4.1 Auto Power On/Off Once the vehicle engine is started, the device automatically turns on. If the Automatic Record function is enabled, the recording will automatically start right after the camcorder powers on. See Set Automatic Recording (2.5.1).

  • Page 20: Set Automatic Recording

    2.5.1 Set Automatic Recording To enable the recording to start automatically after you turn on the power, do the following: Press the button to enter the OSD menu. Press the button to select Automatic Record and press the button. Press the button to select On and press the button.

  • Page 21: Set The Satellite Synchronization

    2.5.3 Set the Satellite Synchronization To set the proper satellite time zone (satellite synchronization), follow the steps below: Press into MENU function. Press to select SATELLITE SYNCHRONIZATION and press into the function. Press to select ON,then press to turn on the function.

  • Page 22: Using The Car Recorder

    3 Using the Car Recorder 3.1 Recording Videos 3.1.1 Record videos while driving When the vehicle engine starts up and the Automatic Record function is enabled, the camcorder automatically turns on and starts recording. Recording will automatically stop when the engine is switched off. Or, press the button to stop recording manually.

  • Page 23: Record All Other Types Of Videos

    3.1.3 Record all other types of videos Press the button to start recording. Press the button to stop recording. Note: 1. One video file is saved for every 3 or 5 minutes of recording. See Using the Menu (4.1). 2. The device saves the recording in the memory card. If the memory card capacity is full, the oldest file in the memory card is overwritten.

  • Page 24: The Recording Screen

    3.1.5 The Recording Screen Item Description Duration Indicates the recording duration. Indicates sound will not be recorded with the Voice Record video. Enter the OSD menu to enable "Voice Record". There are two options for the Smart Scene Mode: Smart 1.

  • Page 25: Taking Photographs

    " will show on the top-right corner of the screen. Battery Indicates the remaining battery power. Prompt : reset Prompt : NOT reset of date / time of date / time Guide icon Press the button to stop the recording. (Stop) Press the button to continuously record...

  • Page 26: Grid Function Chart In The Lcd Screen

    3.1.7 4 GRID FUNCTION CHART in the LCD screen Please push button when you are recording, then you can see the 4 GRID FUNCTION CHART in the LCD screen. Item Driving speed Time Driving direction Distance warning to the speed camera set points Note: The driving speed and driving direction will become gray scale chart if GPS has no signal.

  • Page 27: Playback Videos And Photos

    3.2 Playback Videos and Photos If recording is in progress, press the button to stop recording. The standby screen is displayed. Press the button to enter the OSD menu. Press button , the select File Playback and press the button. Press the button to select the file category that you want to browse and press the...

  • Page 28: Playing Videos

    3.2.1 Playing Videos To play videos, do the following: If recording is in progress, press the button to stop recording. Press the button to enter the OSD menu. Press the button to select File Playback and press the button. Press the button to select Video or Emergency and press the button.

  • Page 29: The Playback Screen

    3.2.3 The Playback Screen Video Playback Screen Photo Playback Screen Description Item Date and time Indicates the recorded date and time. Press the button to return to file selection Guide icon display. (Back) Press the button to view the previous Guide icon video/photo.

  • Page 30: Deleting Files

    3.2.4 Deleting Files To delete file(s), do the following: If recording is in progress, press the button to stop recording. Press the button to enter the OSD menu. Press the button to select File Deletion and press the button. Press the button to select the file category and press the button.

  • Page 31: Adjusting The Settings

    4 Adjusting the Settings 4.1 Using the Menu You can customize the video recording and other general settings via the on-screen display (OSD) menus. If recording is in progress, press the button to stop recording. Press the button to enter the OSD menu. Press the button to select a menu option and press the button to enter the selected menu.

  • Page 32: Menu Tree

    4.2 Menu Tree Refer to the below table for details on menu items and available menu options. Menu option Description Available option Select the file category Video / Emergency / File Playback that you want to view. Picture. Default: Video Displays the current state Satellite Status of the satellite reception.

  • Page 33

    Menu option Description Available option Calculates exposure based on the entire image area. When enabled, the camcorder sounds an Driver Fatigue On / Off. Default: Off Alert audible tone after an hour of driving. On / Turn Off After 30 Set the duration for the sec.

  • Page 34: Default: Off

    Menu option Description Available option object movement is detected. Enable / Disable the collision detection. If this High Sensitivity / function is enabled and Normal Sensitivity / Collision any collision is detected, Low Sensitivity / off. Detection the device will Default: Normal automatically trigger the Sensitivity...

  • Page 35

    Menu option Description Available option English / 繁體中文 / 简 体中文 / 한국어 / 日本 語 / Русский / Deutsch / Français / Italiano / Set the on-screen display Español / Português / menu language. Language Türkçe / Bahasa Indonesia / Bahasa Melayu / �ह...

  • Page 36: Installing The Software

    5 Installing the Software 1. Place the CD disc bundled with the car camcorder in your PC/Laptop optical drive. 2. If the CD does not execute automatically, please use Windows File Manager to execute the Install_CD.exe file in the CD. The following screen will be shown up.

  • Page 37: Supercar

    6 SuperCar Item Item Video Player File Path Play / Pause Browser File Previous File List Next File Name Stop Volume Current Duration / Total Google Map Duration Compass Signal Noise Ratio (SNR) Speed Meter G-Sensor Note: 1. To display the route on Google Maps, please make sure the internet is connected before starting the video playback 2.

  • Page 38: Specifications

    Specifications Item Description Image sensor 1/3” CMOS sensor The device : 5V,1A ; Car Charger : 2~24V Input Voltage Recording with battery charging : 4.4 W , Power Preview with battery charging : 3.7W Consumption 2304 (H) x 1536 (V) Effective pixels Storage media Supports Micro SDHC, up to 32GB class 6 or above...

  • Page 39

    Item Description Interface Mini USB, Mini C Type HDMI Built-in 470mAH Li-polymer rechargeable (This battery Battery is NOT replaceable) Operating -10° ~ 60° C Temperature Operating 20 ~ 70% RH Humidity Storage -20° ~ 80° C Temperature Dimensions 63 x 70 x 28.7 mm Weight Approx.

  • Page 40: Trouble Shooting

    Trouble Shooting  Problem:Function key can not work after the screen become blue color or after formatting the card or the screen show ‘’on the process ‘’ Solution : reset the device via press and hold the power key for over 4 seconds. ...

  • Page 41

     Problem : Why the sound of recording file can not heard when using other playback software ? Solution : Please use the QUICKTIME PLAYER software from the CD in the gift box package .  Problem : Why the right figure appears on screen when power on ? Solution : Remind the user to reset the time before start to use the device .
