Industrial Managed Gigabit Ethernet Switch
User Manual
Order toll-free in the U.S. or for FREE technical support: Call 877-877-BBOX
Contact
(outside U.S. call 724-746-5500)
Information
www.blackbox.com • info@blackbox.com
LIG1014A
LIE1014A
