Sharp FO-CC500 Service Manual

Accessory cordless handset.
Hide thumbs

Advertisement

Illustration: FO-CC500A
[1] Specifications ................................................................ 1-1
[2] Operation panel ............................................................ 1-2
[3] Transmittable documents .............................................. 1-4
[4] Installation ..................................................................... 1-5
[5] Quick reference guide ................................................. 1-10
(FO-6CR) ............................................................. 1-11
[1] Adjustments .................................................................. 2-1
[2] Diagnostics and service soft switch .............................. 2-2
[3] Troubleshooting .......................................................... 2-24
[4] Error code table .......................................................... 2-25
[1] General description ...................................................... 3-1
procedures ............................................................. 3-3
[1] Block diagram ............................................................... 4-1
[2] Wiring diagram .............................................................. 4-3
[3] Point-to-point diagram ................................................... 4-4
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for
maintaining the safety and performance of the set.
SERVICE MANUAL
Illustration: FO-K01A
CONTENTS
SHARP CORPORATION
No. 00ZFCC500ASME
FACSIMILE
MODEL
FO-CC500 Facsimile System cosisting of FO-CC500 (Facsimile Unit)
and FO-CC500K (Cordless Handset).
ACCESSORY CORDLESS HANDSET
MODEL
MODEL
SELECTION CODE DESTINATION
FO-CC500
FO-K01
[1] Circuit description ......................................................... 5-1
[2] Circuit description of control PWB ................................ 5-2
[3] Circuit description of LIU PWB .................................... 5-10
[4] Circuit description of cordless PWB ............................ 5-13
[7] Circuit description of CIS unit ...................................... 5-25
[1] Control PWB circuit ....................................................... 6-1
[2] LIU PWB circuit ............................................................. 6-9
[3] Cordless PWB circuit .................................................. 6-14
[4] Power supply PWB circuit .......................................... 6-19
[5] Operation panel PWB circuit ....................................... 6-21
[6] Cordless handset PWB circuit .................................... 6-23
[1] Protocol ......................................................................... 7-1
[2] Power on sequence ...................................................... 7-2
[1] Service tools ................................................................. 8-1
[2] IC signal name .............................................................. 8-4
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
FO-CC500A
FO-K01A
FO-CC500
FO-K01
A
Australia/
New Zealand
A
Australia/
New Zealand

Advertisement

Chapters

   Also See for Sharp FO-CC500

   Related Manuals for Sharp FO-CC500

   Summary of Contents for Sharp FO-CC500
