GCOS 7 System Operator's Guide
Table 2-1.
MAIN CIRCUIT
BREAKER
AC LINE
INDICATOR DPS
7000/X0 and 3x0
INIT SPA
PUSHBUTTON
SOP DISPLAY
SOP SWITCH
DISKETTE DRIVE
DK UNIT SWITCH
2-14
Functions of the DPS 7000/2X0 and 3X0 System Operator
Panel
Name
When this switch is ON (set at 1), the Central Subsystem
Units are powered on.
When LIT, it indicates that system power supply is ON at
the main distributor board.
The INIT 0 switch initializes SPA 0.
The INIT 1 switch initializes SPA 1.
This can also done by typing in a command at the console.
Indicates the current status of the SOP by means of a
two-digit display.
See Operator Reference Manual, Section 3, for details.
When this switch is ON (set at 1), it activates the Central
Subsystem(s). It must not be switched on before the Main
Circuit Breaker.
The Diskette drive is used if diskettes are to be used for
manual utilization.
When this Switch is ON (set at 1), it activates the
mini-disk normally used for initialization.
Function
47 A2 53US Rev03
