6. Sending the photos and videos

Waspmote can take pictures from two states. When Waspmote and the 3G/GPRS are in sleep mode it can wake up and take
a photo or start recording a video in 1,3 or 1,7 seconds according to the configuration of the camera. If the module 3G/GPRS
starts from the OFF state, the time required increases to 11-15 seconds due to the initialization time required. The table below
contains the time required to take a picture or to start recording a video in the different configurations.
Initial state
Waspmote and 3G/GPRS board are in sleep mode (consumption: 1-1,5mA)
Waspmote is in sleep mode and 3G/GPRS board is off (consumption: 60µA)
Figure : Time required to take a photo or start a video record
The minimum configuration do the next actions:
• 1st Disables the interruption from the presence sensor (PIR).
• 2nd Start the camera
• 3rd Check the ambient light and selects the IR cut filter
• 4th Sets the resolution
• 5th Takes the photo or starts to record
• 6th Power off the IR LEDs
The complete configuration do the next actions:
• 1st Disables the interruption from the presence sensor (PIR).
• 2nd Start the camera
• 3rd Check the ambient light and selects the IR cut filter
• 4th Sets the resolution
• 5th Brightness Setup
• 6th Rotates the image
• 7th Takes the photo or starts to record
• 8th Power off the IR LEDs
Once the photo has been taken or the video has been recorded, the file can be:
• sent to an FTP server
• sent as an attachment in an email
• stored in a Meshlium
Configuration
Minimum
Complete
Minimum
Complete
-32-
Sending the photos and videos
Time (s)
1,3
1,7
13-17
14-18
