4. Night Vision

The Video Camera Sensor Board has been developed to allow Waspmote to take pictures and record video with few light or
in total darkness. To use this feature the Video Camera Sensor Board has integrated 22 IR LEDs to illuminate the focused zone.
Also, to combine this feature with the use of the camera with daylight, the Video Camera Sensor Board includes a IR cut filter to
eliminate a pink distortion on the image.
Daylight photos
Figure : Photo daylight1
Indoor low light level comparative
Figure : Photo without night vision
Corridor
Figure : Photo with light
Figure : Photo without light and
with night vision deactivated
-14-
Figure : Photo daylight2
Figure : Photo with night vision activated
Figure : Photo without light and
with night vision activated
