- Page 1 Model: RT310i Smartphone Controlled Thermostat Installation Manual...
-
Page 2: Table Of Contents
Box contents ......................... 5 Features ........................... 5 Connecting the RXRT510 receiver ..............6 Installation ........................6 RT310i thermostat ..................... 7 Connecting the iTG310 Gateway ..............7 Test Pairing Function ....................7 Registration ........................8 Button functions and keys ................... 9 LCD and App icons .................... -
Page 3: Product Compliance
This product must be installed by a competent person and in accordance with all the EU and national regulations. Always isolate the AC Mains supply before installing or working on any components that require 230 VAC 50Hz supply. RT310i Installation Manual... -
Page 4: Introduction
The SALUS RT310i is a Smart phone controlled programmable thermostat. The RT310i thermostat will switch your heating system on or off, as needed, in accordance with the temperature set by you, locally on the device or remotely using the dedicated app. -
Page 5: Overview
Overview The RT310i is a stylish thermostat with easy readable LCD and a user-friendly interface. The Receiver is used for wiring connections and heat on/off control. The thermostat provides the user interface and temperature sensing / control. The two units are linked together by a Radio Frequency (RF) signal. The Gateway has a... -
Page 6: Connecting The Rxrt510 Receiver
Receiver Terminals Switch Terminal Common Switch Terminal Mains Live (230VAC) Mains Neutral Wiring Electrical diagram Wall mounting Fix the backplate to the wall Align the front housing Fit the front housing. at the top edge. Press lightly 06 RT310i Installation Manual... -
Page 7: Rt310I Thermostat
Press the button once to test the connection between the thermostat and the receiver. If the devices are paired the ON and AUTO LEDs will both flash. You can wait 9 minutes for the process to end or can press the button again to stop. AUTO MANUAL TEST/PAIRING TEST/PAIRING AUTO MANUAL TEST/PAIRING TEST/PAIRING RT310i Installation Manual... -
Page 8: Registration
Registration Download the RT310i App and create an account to start controlling your thermostat via the App. Please follow the steps below. Enter name and Enter the SRT device Tap register to create Enter email and Enter the code you address and tap Next code. -
Page 9: Button Functions And Keys
Button functions and keys There are few user controls for the RT310i, making this thermostat very easy to operate. These controls are shown below, along with a description of each of their functions. The temperature displayed on the LCD is the current room temperature. -
Page 10: Lcd And App Icons
ITG310 gateway transmission to RX boiler Frost Protection On Holiday Mode On Schedule Mode On Temperature display Menu button Thermostat name Setpoint temperature Temperature increase/decrease Heating/Cooling Mode RF Signal Strength Room temperature Frost Protection Mode Schedule/Manual Mode 10 RT310i Installation Manual... -
Page 11: Operations
Select temperature Select clock format format After you adjust all of your settings, tap Save. The app will then return to the home screen where you can start adding programs. Select time zone DST on/off Tap Save RT310i Installation Manual... -
Page 12: Heat/Cool Mode
LCD, received meaning thermostat meaning thermostat is is calling for cooling. calling for cooling. After the thermostat is calling for cooling, the green light on the RXRT510 receiver AUTO MANUAL will go on steady green. 12 RT310i Installation Manual... - Page 13 Note: You can ONLY shuffle between heat/cool mode from the App. When the Internet connection is lost and the thermostat is not communicating to the gateway and App it switches to Local mode. RT310i can still run temperature control, auto program, manual override, and control RXRT510 directly. You can still change the setpoint directly from the thermostat, by pressing the keys directly from the thermostat.
-
Page 14: Setting Schedules
Select day Tap Copy Selected day will be Tap Paste Schedule is saved marked with blue. Tap the day you want to paste into 14 RT310i Installation Manual... -
Page 15: Temporary Or Permanent Override Program Mode
During Permanent Override, manually override setpoint will run forever, until schedule model is selected from App again, or another temperature is set. During Permanent Override, HAND icon is turned ON Via App Via device TESTING/PAIRING TESTING/PAIRING Permanent override mode Permanent override mode RT310i Installation Manual... -
Page 16: Frost Protection
Select clock format format Frost Protection Setpoint You can adjust the Frost Protection setpoint using the App. The setpoint range is between 5-9 ⁰C Tap menu icon Go to Frost Protection Adjust temperature Tap Save Default 5⁰C 16 RT310i Installation Manual... -
Page 17: Holiday Mode
Holiday Mode You can set your RT310i to holiday mode. Thermostat will be turned OFF during this mode and no commands will be sent to the heating unit. During this mode, the thermostat will run like in Frost Protection Mode. When... -
Page 18: Other Functions
Temperatures below 10 °C are displayed without the leading ‘0’ . Temperatures exceeding the measurable range will be indicated by ‘HI’ for temperatures above the upper limit, and ‘LO’ for temperatures below the lower limit, as shown in the images. 18 RT310i Installation Manual... -
Page 19: Operating In Offline Mode
0.5°C steps per key press. The RT310i will return to Normal mode if no keys are pressed for more than 2 seconds. Once the new Setpoint has been implemented, the change is permanently overridden until a new Setpoint is set again. Setpoint temperature cannot be changed if Frost Protection mode is enabled. -
Page 20: Factory Reset
Remove the batteries without pressing any button. Wait 2 minutes and insert the batteries again. Via App Tap Yes Tap menu icon Go to Manage devices Tap delete After that you will need to add and set your thermostat all over again. 20 RT310i Installation Manual... -
Page 21: Technical Info
230Vac 50Hz Switch Rating Switching Voltage: 230V/50Hz Switching Current: 16A resistance 8A inductance Protection Rating: IP 30 Environment Operating Temperature/ 0°C ~ 50°C, 10% – 90% non-condensing Humidity: Storage Temperature/ -20°C~- 60°C, 10% – 90% non-condensing Humidity: RT310i Installation Manual... -
Page 22: Warranty
SALUS Controls sole liability for breach of this warranty will be (at its option) to repair or replace the defective product. - Page 23 SALUS Controls is a member of the Computime Group Maintaining a policy of continuous product development, SALUS Controls plc reserves the right to change specification, design and materials of products listed in this brochure without prior notice. For the latest PFD Instruction Manual, go to www.salus-manuals.com...
