MO1612-EA
© 2016 CASIO COMPUTER CO., LTD.
Each section of this manual provides you with the information you need to perform
operations in each mode. Further details and technical information can be found in
the "Reference" section.
E-2
Recall Mode .......................................................................................E-24
To recall stopwatch time records......................................................E-25
To delete a log ...........................................................................E-27
Countdown Timer.................................................................................E-28
To use the countdown timer ............................................................E-29
Alarms ................................................................................................E-32
To set an alarm time .....................................................................E-34
To test the alarm ........................................................................E-36
To turn Alarms and on and off ...................................................E-38
To turn the hourly time signal on and off ..........................................E-38
Dual Time ..........................................................................................E-39
To set the Dual Time .....................................................................E-39
E-4
General Guide
Press C to change from mode to mode.
In any mode (except when a setting screen is on the display), press B to illuminate
the face of the watch.
Timekeeping Mode
E-6
Timekeeping
Day of week
Month - Day
Minutes
Hours
PM indicator
Seconds
E-8
Operation Guide 5510
Stopwatch Mode
C
Hand Setting Mode
C
Use the Timekeeping Mode to set and view the current
time and date. This watch features separate digital and
analog timekeeping. The procedures for setting the digital
time (page E-9) and analog time (page E-13) are different.
Setting the Digital Time and Date
Use the Timekeeping Mode to set and view a digital
display of the current time and date. When setting the
digital time, you also can configure settings for the
summer time (Daylight Saving Time or DST).
About This Manual
Contents
General Guide .................................................................................... E-6
Timekeeping ....................................................................................... E-8
To set the digital time and date ...................................................... E-9
To toggle between 12-hour and 24-hour timekeeping ...........................E-11
To toggle the Timekeeping Mode digital time between DST and
Standard Time ........................................................................E-12
To adjust the analog time ...............................................................E-13
Stopwatch ..........................................................................................E-15
To measure elapsed time ...............................................................E-18
To measure elapsed time with lap times ..........................................E-19
To measure elapsed time with split times ..........................................E-20
Illumination .......................................................................................E-41
To illuminate the display manually ...................................................E-41
To specify the illumination duration...................................................E-42
To turn the auto light switch on and off .............................................E-44
Reference ..........................................................................................E-45
To turn the button operation tone on and off .......................................E-46
Specifications ....................................................................................E-51
Recall Mode
C
Dual Time Mode
C
To set the digital time and date
Seconds
Button operations are indicated using the letters shown
in the illustration.
Depending on the model of your watch, display text
appears either as dark figures on a light background, or
light figures on a dark background. All sample displays
in this manual are shown using dark figures on a light
background.
Note that the product illustrations in this manual are
intended for reference only, and so the actual product
may appear somewhat different than depicted by an
illustration.
Countdown Timer
Mode
C
Alarm Mode
C
1. In the Timekeeping Mode, hold down A until the
seconds start to flash, which indicates the setting
screen.
2. Press C to move the flashing in the sequence shown
below to select other settings.
Seconds
DST
Hour
Day
Month
E-1
E-3
E-5
C
E-7
Minutes
Year
E-9

Advertisement

loading

  Summary of Contents for Casio 5510

  • Page 1: Table Of Contents

    MO1612-EA © 2016 CASIO COMPUTER CO., LTD. Operation Guide 5510 About This Manual • Button operations are indicated using the letters shown in the illustration. • Depending on the model of your watch, display text appears either as dark figures on a light background, or light figures on a dark background.
  • Page 2 Operation Guide 5510 3. When the setting you want to change is flashing, use D and B to change it as 4. Press A to exit the setting screen. described below. • The day of the week is displayed automatically in accordance with the date (year, month, and day) settings.
  • Page 3: Recall Mode

    Operation Guide 5510 6. Press A to clear the stopwatch to all zeros. 3. Press A to record the time of the first split. Lap time Split Time Recording • Lap numbers are incremented automatically starting (Displayed for eight •...
  • Page 4: To Configure Countdown Start Time And Auto-Repeat Settings

    Operation Guide 5510 To configure countdown start time and auto-repeat settings 3. Perform the following operations, depending on which setting currently is selected 1. While the countdown start time is on the display in the on the display. Countdown Timer Mode, hold down A until the hour While the start time setting is flashing, use D (+) and B (–) to change it.
  • Page 5: Standard Time

    Operation Guide 5510 4. When the setting you want to change is flashing, use B and D to change it as Illumination described below. An LED (light-emitting diode) illuminates the face of the Screen: To do this: Do this: watch for easy reading in the dark. The watch’s auto light switch turns on illumination automatically when you angle the watch towards your face.
  • Page 6: Specifications

    Operation Guide 5510 Specifications • Static electricity or magnetic force can interfere with proper operation of the auto light switch. If illumination does not turn on, try moving the watch back to the starting position (parallel with the ground) and then tilt it back toward you again. If Accuracy at normal temperature: ±...
