Weslo MOMENTUM 710 User Manual

Hide thumbs Also See for MOMENTUM 710:

Advertisement

Table of Contents

Patent Pending
Model No. WLEL20130
Serial No.
Serial
Number
Decal
QUESTIONS?
If you have questions, or if
there are missing or damaged
parts, we will guarantee com-
plete satisfaction through
direct assistance from our
factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and
instructions in this manual
before using this equipment.
Keep this manual for future
reference.
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOMENTUM 710 and is the answer not in the manual?

Questions and answers

Related Manuals for Weslo MOMENTUM 710

Summary of Contents for Weslo MOMENTUM 710

  • Page 1 CUSTOMER HOT LINE: 1-800-999-3756 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Visit our website at Read all precautions and instructions in this manual www.weslo.com before using this equipment. Keep this manual for future new products, prizes, reference. fitness tips, and much more!

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .

  • Page 3: Before You Begin

    MOMENTUM 710 low-impact elliptical exerciser. The Monday through Friday, 6 a.m. until 6 p.m. Mountain MOMENTUM 710 is an incredibly smooth exerciser Time (excluding holidays). To help us assist you, that moves your feet in a natural elliptical path, mini- please note the product model number and serial mizing the impact on your knees and ankles.

  • Page 4: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires a phillips screwdriver , two adjustable wrenches , and a rubber mallet Refer to the drawings below to identify the small parts needed for assembly.

  • Page 5: Slot In The Frame (1), And Insert The Front Stabilizer (3

    1. Attach the Rear Stabilizer (4) to the Frame (1) with two M10 x 105mm Carriage Bolts (34) and two M10 Nylon Locknuts (29). 2. Hold the Lower Wire Harness (65) in the indicated slot in the Frame (1), and insert the Front Stabilizer (3) into the Frame.
  • Page 6 5. Hold the Console Bracket (26) near the Upright (2), Wire and locate the wire extending from the bottom of the Console Bracket. Carefully pull the upper end of the Upper Wire Harness (79) to remove any slack, and tie the wire around the Upper Wire Harness, as shown in the inset drawing.
  • Page 7 8. Identify the Left Handlebar (9) and the Left Handlebar Leg (73), which are marked with stickers. Insert the Left Handlebar (9) into the Left Handlebar Leg (73). Make sure that the short tube on the Left Handlebar and the hexagonal holes in the Left Handlebar Leg are on the same side.

  • Page 8: How To Use The Elliptical Exerciser

    11. Apply a thin film of grease to the shaft of a Bolt Set (27) and the post on the left Crank Arm (36). Slide the Left Pedal Arm (14) onto the post on the left Crank Arm (36). Attach the Left Pedal Arm with an M8 Grease x 19mm Button Screw (22) and an M8 Large Washer (17).
  • Page 9 HOW TO OPERATE THE CONSOLE The advanced console offers a selection of features HOW TO USE THE MANUAL MODE designed to make your workouts more enjoyable and effective. When the manual mode of the console is selected, the resistance of the elliptical crosstrainer Turn on the console.
  • Page 10 To reset the display, press the On/Reset button. Begin pedaling and adjust the resistance of Note: The console can display speed and dis- the pedals. tance in either miles or kilometers. To change the unit of measurement, hold down the On/Reset As you pedal, button for about six seconds.
  • Page 11 At the end of each one-minute period, the resis- HOW TO USE A WORKOUT PROGRAM tance of the pedals will automatically change if a different resistance setting is programmed for the next period. Note: If the resistance level is too Turn on the console.

  • Page 12: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and properly tighten all parts of the elliptical Remove the indicated Screws (62) from the Right exerciser regularly. Replace any worn parts immedi- Side Shield (7). Remove the indicated Screws (66) ately. from both Side Shields (6, 7). Lift the Side Shields off the elliptical exerciser.

  • Page 13: Conditioning Guidelines

    CONDITIONING GUIDELINES Fat Burning WARNING: To burn fat effectively, you must exercise at a relative- ly low intensity level for a sustained period of time. • Before beginning this or any exercise pro- During the first few minutes of exercise, your body gram, consult your physician.

  • Page 14: Part List

    PART LIST—Model No. WLEL20130 R0703A Key No. Qty. Description Key No. Qty. Description Frame M4 x 64mm Screw Upright M8 Nylon Locknut Front Stabilizer Crank Screw Rear Stabilizer Right Crank Arm Console M6 x 20mm Bolt Left Side Shield M8 x 42mm Button Bolt Right Side Shield M6 x 16mm Button Bolt Pedal Disc...

  • Page 15: Exploded Drawing

    EXPLODED DRAWING—Model No. WLEL20130 R0703A 32 33...

  • Page 16: How To Order Replacement Parts

    • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) from page 14 of this manual WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health &...
