AXIOMTEK PANEL6100 User Manual

10.4” industrial tft lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PANEL6100 & PANEL6100L
10.4" INDUSTRIAL TFT LCD MONITOR
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PANEL6100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AXIOMTEK PANEL6100

Summary of Contents for AXIOMTEK PANEL6100

  • Page 1 PANEL6100 & PANEL6100L 10.4” INDUSTRIAL TFT LCD MONITOR User’s Manual...
  • Page 2 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or other rights of third parties, which may result from its use. Axiomtek assumes no responsibility for any inaccuracies that may be contained in this document.

  • Page 3: Fcc Compliance

    Safety Approvals  CE Marking  FCC Class A FCC Compliance This equipment has been tested and complies with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 Safety Precautions Before getting started, read the following important cautions. The P6100&P6100L does not come equipped with an operating system. An operating system must be loaded first before installing any software into the computer. Be sure to ground yourself to prevent static charge when installing the internal components. Use a grounding wrist strap and place all electronic components in any static-shielded devices.

  • Page 5: Table Of Contents

    Table of Contents Disclaimers ............................ii FCC Compliance ..........................iii CHAPTER 1 INTRODUCTION General Description ......................1 Features ..........................2 Specifications ........................3 Dimension ..........................4 /O Inputs ..........................5 CHAPTER 2 SYSTEM SETUP System Configuration ......................7 Panel Mounting ........................8 Wall Mounting (Option) ......................
  • Page 6 MEMO :...

  • Page 7: Chapter 1 Introduction

    P6100&P6100L Series Panel PC User’s Manual CHAPTER 1 INTRODUCTION This chapter contains the general information and the detailed specifications of the P6100&P6100L.Chapter1 includes the following sections:  General Description  Features  System Specification  Dimensions  I/O Inputs General Description The Panel 6100&6100L, a industrial 10.4 inches view area LCD Monitor comes with slim, light and reliable features to replace traditional bulky CRT for Industrial application.

  • Page 8: Features

    P6100&P6100L Series Panel PC User’s Manual The differences between P6100 &P6100L is that support different I/O inputs. You can refer to the below table to check the differences. Model IO Ports 1 x RS-232 or USB for touchscreen 1 x VGA input 1 x DVI P6100 1 x Power input...

  • Page 9: Specifications

    P6100&P6100L Series Panel PC User’s Manual Specifications  Construction: Heavy-duty steel chassis  Brightness: 230 nits  Control: OSD (On Screen Display) control pad on front side  Mounting: Support Panel mount, VESA arm mounting, and Wall mount(optional)  Net weight: 2.6 KGS ...

  • Page 10: Dimension

    P6100&P6100L Series Panel PC User’s Manual Dimension Introduction...

  • Page 11: O Inputs

    P6100&P6100L Series Panel PC User’s Manual /O Inputs P6100&6100L Inputs DC +12V or DC+24V: This connector will be connected to the DC 12V Switching Power Supply. T/S Port (D-sub optional): This connector will be present only if a touchscreen is installed. It must be connected to the RS-232 port of the PC.
  • Page 12 P6100&P6100L Series Panel PC User’s Manual MEMO: Introduction...

  • Page 13: Chapter 2 System Setup

    P6100&P6100L Series Panel PC User’s Manual CHAPTER 2 SYSTEM SETUP This chapter details the system parts and components with figures. Sections include  System Configuration  Panel Mounting  Wall Mounting  Desktop Stand System Configuration The figure below shows the front and back views of P6100&P6100L series. Power switch: Press this button to turn on/off the monitor.

  • Page 14: Panel Mounting

    P6100&P6100L Series Panel PC User’s Manual Panel Mounting Two accessory items are needed for this application. Mounting bracket x 4 pcs Pan head screws (M4x0.7PxL50.0mm) x 4 pcs Installation instruction Find a plate and cut off a window, refer the 1.4 P6100&P6100L Dimensions for the dimension.
  • Page 15 P6100&P6100L Series Panel PC User’s Manual The panel itself can be from 1.6 to 19.0mm thick. Strengthening may be required for the panel. Be sure to consider the weight of the P6100&P6100L when designing the panel. Note: To enhance the P6100&P6100L’s maintainability, operability and ventilation, allow at least 35mm clearance between the P6100&P6100L and any other objects.

  • Page 16: Wall Mounting (Option)

    P6100&P6100L Series Panel PC User’s Manual Wall Mounting (Option) Wall Bracket The unit is designed to support wall mounting application. It let you to mount the unit on the wall. Three accessory items to support this feature. Wall mounting bracket x 1 pcs Binding head &...

  • Page 17: Desktop Stand (Option)

    P6100&P6100L Series Panel PC User’s Manual Desktop Stand (Option) Side View The unit is designed to support desktop stand application. Two accessory items are needed for this application. Wall mounting bracket x 1 pcs Binding head & washer screws (M4x0.7PxL6.0mm) x 2 pcs Installation instruction Mounting the wall mounting bracket with the binding header &...
  • Page 18 P6100&P6100L Series Panel PC User’s Manual MEMO: System Setup...

  • Page 19: Appendix A Supported Input Timing Modes

    P6100&P6100L Series Panel PC User’s Manual APPENDIX A SUPPORTED INPUT TIMING MODES Supported Input Timing Modes Horizontal Timing Vertical Timing Pixel SPEC Freq. Freq. Total Active Freq. Total Active Sync Sync MODE Polar Polar Pixel Pixel Line Line 640×480 25.175 31.469 59.940 @60Hz...
  • Page 20 P6122 Series Panel PC User’s Manual MEMO: Supported Input Timing Modes...

  • Page 21: Appendix Bosd Operation

    P6100&P6100L Series Panel PC User’s Manual APPENDIX B OSD OPERATION Function Description of OSD Menu ※The layout and format of OSD depends on customer’s request. OSD MENU Description Adjust the List：  Brightness of the screen .  Contrast of the screen . Horizontal size of the screen’s image .
  • Page 22 P6122 Series Panel PC User’s Manual OSD MENU Description Adjust the List：  OSD Time out .  OSD position .  OSD Transparent.  Recall : “Yes” allows you to recover to the preset mode .  Auto Adjust…Horizontal position, Vertical position, Horizontal size, Phase of Tools the screen’s image .
