User Manual
UHF SYNTHESIZED WIRELESS
TRANSMITTER
ATW-T6001 S
Thank you for purchasing this product.
Before using the product, take time to read this user manual
thoroughly to ensure that you will use the product correctly.
Also keep this user manual handy, along with the warranty,
so that they are always available for reference.
Advertisement
Table of Contents
Related Manuals for Audio Technica ATW-T6001 S
Summary of Contents for Audio Technica ATW-T6001 S
- Page 1 User Manual UHF SYNTHESIZED WIRELESS TRANSMITTER ATW-T6001 S Thank you for purchasing this product. Before using the product, take time to read this user manual thoroughly to ensure that you will use the product correctly. Also keep this user manual handy, along with the warranty,...
-
Page 2: Table Of Contents
Contents Features ・・・・・・・・・・・・・・・・・・・・・・ 2 Important information ・・・・・・・・・・・・・・ 3 Notes on use ・・・・・・・・・・・・・・・・・・・ 4 Using multiple wireless systems ・・・・・・・・・ 4 Part names and functions ・・・・・・・・・・・・ 5 Inserting batteries ・・・・・・・・・・・・・・・・・ 6 Display ・・・・・・・・・・・・・・・・・・・・・・・ 7 Settings ・・・・・・・・・・・・・・・・・・・・・・ 8 Menu screen ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ 8 ... -
Page 3: Important Information
Important information Warning: To prevent fire or shock hazard, do not expose this apparatus to rain or moisture. Caution: Do not expose this apparatus to drips or splashes. To avoid electric shock, do not open the cabinet. Refer servicing to qualified personnel only. Do not expose this apparatus to excessive heat such as sunshine, fire or the like. -
Page 4: Notes On Use
Notes on use · Be sure to read the user manual for any microphone or cable that you attach to the product. · If you use the product close to an electronic or communications device (such as a mobile phone), the product may produce unwanted noise. -
Page 5: Part Names And Functions
Use when syncing the Lights in green when the product to the receiver. power is on. Lights in red when battery power is low. Rear ATW-T6001 S FREQ. : 946-950 MHz FREQ.: 704-708MHz CMIIT ID: ******** FCC ID: JFZT6001S BATT: LR6, AAx2, 3V BATT.: LR6, AA×2, 3 V... -
Page 6: Inserting Batteries
Inserting batteries Slide the battery cover latches inward as shown by the arrows. With the latches pressed in, slide the cover down as shown by the arrow. Open the battery cover as shown in the diagram. Insert the batteries according to the plus (+) and minus (-) marks found inside the battery compartment. -
Page 7: Display
Display The main screen is displayed when the power is switched on. 946. 125MHz (1) Frequency/NAME Press the UP/DOWN to switch screens. * Frequency displays as the default setting. (2) Battery power indicator Shows how much battery power is remaining. : 75 % or more battery power remaining. -
Page 8: Settings
Settings ■ Menu screen Press SET ( ● ) on the lever push switch for menu screen mode. Moving UP ( ▶ ) / DOWN ( ◀ ) takes you to the various setting screens in the order shown below. * If there is no switch operation within 10 seconds, the display returns to the main screen. -
Page 9: Transmission Frequency Setting
■ Transmission frequency setting From the menu screen, use UP/DOWN to FREQUENCY select "FREQUENCY," and then press SET. 947. 000MHz A line is displayed under the first three FREQUENCY digits. 947. 000MHz Use UP/DOWN to select the frequency. FREQUENCY 948. 000MHz Press SET. -
Page 10: Correcting Characters
■ Correcting characters To correct a character after it is entered, select "BS" with UP/DOWN. When SET is pressed, the last entered character is deleted and the cursor moves one position to the left. NAME v o c a ■ RF power setting From the menu screen, use UP/DOWN to RF POWER select "RF POWER,"... -
Page 11: Key Lock Setting
■ Key lock setting Display the key lock status. LOCK KEY Unlock: Keys unlocked Unlock Lock: Keys locked From the menu screen, use UP/DOWN to LOCK KEY select "LOCK KEY," and then press SET. Unlock Use UP/DOWN to select the key lock LOCK KEY setting, then press SET. -
Page 12: Using The Mute Function
Using the mute function The mute function allows you to manually mute your microphone when, for example, there is a gap in the middle of a speech, or you want to change the settings and transmitting audio would be a problem. MUTE OFF When you press and hold the Recall/Mute button, "MUTE ON"... -
Page 13: Ir Sync
Pull both sides of the clip firmly to the outside to remove the clip from the product. W-T6001 R ATW-T6001 R ATW-T6001 S FREQ. : 946-950 MHz FREQ. : 710-714 MHz FREQ. : 710-714 MHz FCC ID: JFZT6001S BATT.: LR6, AA×2, 3 V BATT.: LR6, AA×2, 3 V... -
Page 14: Specifications
Specifications Operating frequency: 946.125 MHz to 949.875 MHz (31 channels) Frequency step: 125 kHz Spurious emissions: Following federal and national regulations RF power output: 50 mW/ 10 mW/ 2 mW Normal deviation: ±5 kHz Maximum deviation: ±16.25 kHz Frequency response: 70 to 15,000 Hz Batteries: Two 1.5 V AA alkaline ℃... - Page 15 Memo...
- Page 16 Audio-Technica Corporation ©2016 Audio-Technica Corp. 232305380-01-01 ver.1 2016.11.22...
