- Page 1 Studio Broadcast System BP24 Bodypack Transmitter SET UP and USE...
- Page 2 Studio Broadcast System REGULATORY AND COMPLIANCE STATEMENTS ......................3 BP24 BODYPACK TRANSMITTER ............................. POSITIONING AND SET UP………………………………………………………………………………………………………………………………………….. SYSTEM QUICK START ..............................Page 2 of 11...
-
Page 3: Regulatory And Compliance
Studio Broadcast System 1. REGULATORY AND COMPLIANCE Page 3 of 11... -
Page 4: Transmitter Controls
Studio Broadcast System 2 BP24 UWB Body Pack Transmitter 2.1 Transmitter Controls An On/Off power switch is located in the battery compartment. The adjustable transmitter parameters are: 1. System ID (SYS) – Each transmitter must be assigned a system ID (1-9) that must match the system ID set on the MCU3224 The transmitter will only transmit when it receives a sync pulse and matching system ID from an active system. - Page 5 Studio Broadcast System System ID Channel SYSTEM ID Parameter Selection Up/Down Keys Input Level SYSTEM ID Adjustment Process: 1. Press and Hold (2 sec) the button associated with the parameter to be adjusted - SYS, CHAN or GAIN. 2. The selected parameter value will flash on the screen. 3.
- Page 6 Studio Broadcast System 2.2 Batteries The BP24 operates via 2 x AA size batteries. When inserting the batteries into the BP24, observe correct polarity as marked. Do not peel off or damage the outer tube of the battery. Do not use a leaking battery. If battery leakage occurs, avoid contact with skin. If contact occurs, immediately was thoroughly with soap and water.
-
Page 7: System Quick Start
Place the display side (front side) of this bodypack transmitter facing out, and not directly against or towards a body or other solid object. Specifically, the antenna is located directly under the Audio-Technica logo on the front of this unit. Holding or continuously touching the logo directly over the antenna may de-tune the unit and negatively affect performance. - Page 8 Studio Broadcast System Apply power to the MCU3224 by connecting at least one IEC cable to AC wall supply. Press the front panel “power” button. The power light(s) corresponding to the IEC cable input will be visible on the front panel (one red and one blue), and the GUI screen will illuminate and enter a “set-up”...
- Page 9 Studio Broadcast System Ensure that the BP24 system ID is the same as the System ID of the MCU3224 (system will turn on in “default” system ID 1 for all devices). The System ID is visible in all screens on the left-hand side of the display for “navigation.”...
- Page 10 Studio Broadcast System Return to the MCU and select the “home screen” The BP24 that has just been turned on should be shown in the display on the channel number that you have set via the BP24 channel selection process. ...
- Page 11 Studio Broadcast System Page 11 of 11...
