Summary of Contents for Boly BG320
- Page 1 User Manual BG320/ BG320-BW...
-
Page 3: Table Of Contents
Content 1.0 Getting Started ....................1 2.0 Camera Operations..................4 2.1 Batteries / Power Supply..............4 2.2 SD Card Information ................4 2.3 Camera Modes..................5 2.4 Additional Notes..................7 3.0 Camera Settings ....................8 4.0 Trouble Shooting....................11 5.0 PIR Detection Zone..................12 6.0 Technical Specifications ................ -
Page 4: Getting Started
1.0 Getting Started Front View LCD Screen LED Indicator OK/Power Menu Lens Right PIR Sensor Latch Bottom View Battery Tray... - Page 5 The unit is resistant against water and snow and is offered in two different models: BG320 ：A digital trail camera with four 940nm low-glow IR LED lights. It takes black and white pictures and videos during the day and night.
- Page 6 Additional Product Features: High quality 10MP and 720p video. 73 ft. detection and 60 ft. lighting range Quick trigger time:<1.2s Trigger delay interval: 0s-1h Supports up to 32GB SD card 1.33”LCD display...
-
Page 7: Camera Operations
2.0 Camera Operations 2.1 Batteries / Power Supply The camera is powered by four or eight AA batteries - High-density, high-performance alkaline, rechargeable Alkaline or NiMH batteries are recommended. A DC 6-Volt, 2 Amp external power supply adapter can also be used to power the camera (not included). Please take caution when installing batteries to match the shown polarity on the battery tray. -
Page 8: Camera Modes
Do not remove the SD card while the camera is on By removing the SD card while the camera is on risks damaging the internal components of the camera. If you experience any problems with an inserted SD card Try reformatting the SD card utilizing the camera’s main settings option. - Page 9 If the camera is left unattended for 20 seconds, the camera switches to “Hunting Mode”, which is the normal operation for the camera to react to motion and capture photos/videos. Before entering “Hunting Mode”, the front (red) LED light will continuously blink for approximately 10 seconds and then turn off –...
-
Page 10: Additional Notes
2.4 Additional Notes Avoid varying temperature and motion disturbances in front of the camera, such as falling leaves, air-conditioner outlets, and other sources that may easily sway and move to prevent false triggering. To adequately capture the full image of the tracked game, the camera should be placed high above the ground, respective to the object size of the game. -
Page 11: Camera Settings
3.0 Camera Settings To view the camera settings menu, Press OK to “wake up” the camera or when the screen is active, press MENU to enter into the menu settings. Use the RIGHT key to select the different options, press OK to save the setting and press MENU to exit the camera settings menu. - Page 12 Choose the continuous shooting numbers Photo Burst after each triggering: 1 Photo, 3 Photo Default: 1 Photo Choose video size: 1280x720 Video Size 640x480. Default: 1280x720 Advanced Description Menu Choose duration of recording video. It has Video three values: 10 sec, 30 sec and 60 sec Length Default: 10 seconds The camera can capture images or videos at...
- Page 13 climates. Use LOW sensitivity for areas that have a lot of interference. The sensitivity of the PIR is effected by temperature. Higher temperatures leads to lower sensitivity. If Trigger/Sensitivity Time Lapse options are BOTH OFF, the camera will not capture any photos or videos.
-
Page 14: Trouble Shooting
4.0 Trouble Shooting 1、There is something in front of the camera lens - Is the camera broken? A: The camera is not broken. It’s an IR-cut filter. When the camera is powered on, the IR-cut will cover the lens. Only when the camera is powered off, the IR-cut will be at a random place, sometimes covering the lens. -
Page 15: Pir Detection Zone
5.0 PIR Detection Zone This camera has a new patented PIR design, which allows the detection range to reach to 85ft in good environments. Following picture shows the compared detection zone between normal PIR and the new patented PIR. The PIR detection angle (α) is just smaller than the field of view (FOV) angle (β). -
Page 16: Technical Specifications
6.0 Technical Specifications 3MP CMOS Sensor Image Sensor 6MP, 10MP Interpolation F/NO=2.2 Lens FOV(Field of View)=53° PIR detection range 73ft Display Screen of 1.33” LCD Remote Control Memory Card Up to 32 GB 1280x720(20fps) Video Resolution 640×480(20fps) PIR Sensitivity Adjustable (High/Normal/Low) Trigger Time <1.2s Weight... -
Page 17: Parts List
7.0 Parts List Part Name Quantity Camera Belt User Manual Warranty Card For more details about our product or software, please visit our website at : http://www.bolyguard.com/download.html ...
