"...WITH A PASSION FOR COFFEE"
Service manual
Bean to cup hot & cold TT
COFFEE QUEEN
S / EN
...............................................................................
Rev. 090918
...............................................................................

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bean to cup hot & cold TT and is the answer not in the manual?

Questions and answers

Related Manuals for Coffee Queen Bean to cup hot & cold TT

Summary of Contents for Coffee Queen Bean to cup hot & cold TT

  • Page 1 ”...WITH A PASSION FOR COFFEE” Service manual Bean to cup hot & cold TT COFFEE QUEEN S / EN ................Rev. 090918 ................

  • Page 2: Table Of Contents

    1. Table (list) of contents. Table of contents sid. General Overview of components front Overview of components mixing system Overview of components door, grinder Overview of components chilled water SERVICE: Installation and start Place the brewer Connectings: Electricity/Water Starting up machine Fill canisters with ingredients Fill bean container with coffee beans 5.

  • Page 3: General

    2. General. Bean to cup hot n cold TT We congratulate to your choice of a Coffee Queen Bean to cup hot n cold TT. Please read this manual before you take the machine into operation for the first time.

  • Page 4: Overview Of Components Front

    3. Overview of components , front Bean to cup hot n cold TT Bean container Volume/ 1kg Display Strength of drinks ++ / - - Key switch (cup and jug choice) Drinks Door lock Water outlet (warm and cold drinks) Cupholder Drip tray insert Drip tray...

  • Page 5: Overview Of Components Mixing System

    3. Overview of components , mixer system Bean to cup hot n cold TT Ingredients- canister Chute FUSE holder Mixer bowls ON/OFF- switch Brew mechanism Outlet drinks Waste box hot and cold Detail; Ingredients; Width; Height; Volume/litre; Amount/unit Canister; coffee Canister;...

  • Page 6: Overview Of Components Door, Grinder

    3. Overview of components , door grinder Bean to cup hot n cold TT Outlet grinder Adjusting screw for grinding Closing hatch Grinder house 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1...

  • Page 7: Overview Of Components Chilled Water

    3. Overview of components , chilled water Bean to cup hot n cold TT Thermostat Cooling unit Condenser Water OUT Water IN Compressor Dryer 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0...

  • Page 8: Service: Installation And Start

    4. Service. Installation and start Bean to cup hot n cold TT Place the brewer on a flat level and waterproof surface. Connect the electrical plug to a separate grounded wall socket OBSERVE! Make sure there is a space behind the machine for free flow of air.

  • Page 9: Fill Canisters With Ingredients

    4. Service (Installation and start) Bean to cup hot n cold TT Fill canisters with ingredients. Take out ingredient canisters (this to avoid unnecessary spillage in the machine) and fill them with ingredients. When placing the ingredient canisters; Make sure that the outlet pipes on the ingredient canisters are touching the steam traps (B) and that the coffee powder will fall into the centre of the brew mechanism (A).

  • Page 10: Fill Bean Container With Coffee Beans

    Adjusting the grinder. Grinder is pre-set from the factory. All other adjustments shall be done of an Coffee Queen trained service technician. Fig. 1. 13. Adjusting outlet from grinder. For correct adjustment of outlet. (angle(15 degrees). See Fig. 1 (B) and Fig. 2 (C).

  • Page 11: Brewing Of Coffee In Cup, Cold Water

    5. Operation: Brewing of coffee in cup Bean to cup hot n cold TT Brewing of coffe. Chocolate etc. Place a cup in the centre of the cup holder.. The strength has a standard setting, if you wish to increase or decrease it, do as follows if not continue to point 3.

  • Page 12: Brewing Of Jug

    5. Operation: Brewing of jug. Bean to cup hot n cold TT Brewing of jug. Place a jug in the centre of drip tray by lifting up the cup holder. Turn on the key with jug symbole clockwise. 6 cups of brewing is standard settings, Change amount of cups by pushing + or - button.

  • Page 13: Cleaning Program

    6. Cleaning program CLEANING Bean to cup hot n cold TT Automatic cleaning of brew mechanism, mixing bowl: Shall been done every week. The brewmechanism can easily be cleaned with the key switch in ”cup” (normal) position. 1. Turn the key slowly ninety degress and back again. Fig.
  • Page 14 6. Cleaning program CLEANING Bean to cup Dismantling and cleaning/washing brew house: Dismantle brew house: 3. Flush brew house! To remove detergent and coffee remnants. Reassemble brew house. NOTE! When reassemble brew house make sure that (B) wiper are between (A) arms. 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1...

  • Page 15: Automatic Cleaning Of Mixing Bowl

    6. Cleaning program. CLEANING Bean to cup hot n cold TT Weekly cleaning! Automatic cleaning of mixing bowls 2 or 3. If you only wish to clean the mixer bowl and whipper house; Follow these instructions: The mixer bowls can easily be cleaned with the key switch in ”cup”...

  • Page 16: Automatic Cleaning Of In/Outlet Valves

    6. Cleaning program CLEANING: Bean to cup hot n cold TT Automatic cleaning of In/Outlet valves: The In/Outlet valves can easily be cleaned with the key switch in ”cup” (normal) position. Place a jug in the drip tray. Turn the key slowly ninety degrees and back again. Push button for drink 1 and 2 at the same time for 6 seconds.

  • Page 17: Rotate Brew Mechanism Without Water Or Ingredients

    6. Cleaning program CLEANING: Bean to cup hot n cold TT Rotate brew mechanism without water or ingredients: The brew mechanism can be rotatedwithout water and ingredients with the key switch in ”cup” (normal) position. To be used when brew mechanism has been dismounted forwashing and shall be remounted.

  • Page 18: Weekly Cleaning

    7. CLEANING: Weekly cleaning Bean to cup Dismantle : Mixer system Cleaning Loosen mixer bowl. Pull apart (C). 5. Clean with a wet rag and Loosen outlet hose (A) drought drily. turn lock knob (B) anti-clockwise. Wash these parts: A. Mixer bowl B.

  • Page 19: Assemble Mixer System

    7. CLEANING: Weekly cleaning Bean to cup REASSEMBLE: Mixer system Make sure that the motor whippers plane side will be in accordance with the whippers plane Reassemble the assembly plate by turning side. see next (G) and picture (H). lock knob (F) clockwise. INSPECT gaskets. pil (G).

  • Page 20: Cleaning And Maintenance

    8. Cleaning and maintenance CLEANING Bean to cup Cleaning when needed. Outside cleaning; use a soft rag and liquid cleaning agent to prevent scratches. When cleaning bean container. - Shut closing hatch. - Dismantle bean container. Use a soft rag and liquid cleaning agent to prevent scratches. Note! Make sure that all parts are dry before use.

  • Page 21: Cleaning Grinder

    8. Cleaning and maintenance. Cleaning grinder Bean to cup Cleaning of grinder shall be done every month. IMPORTANT! All maintenance and installations must be done of an authorized technician. Grindz, coffee cleaner art. no.E 1001001 will be supplied from your retail dealer. 1.

  • Page 22: Cleaning, Grinder

    8. Cleaning and maintenance. Cleaning grinder Bean to cup 14. Reassemble bean- 9. Put a cup under the outlet container and open (for grinder). closing hatch for beans. 15. Put a cup under the 10. Push button Enter, until grinder is empty outlet for grinder.

  • Page 23: Cleaning And Dismantling Of Coffee Filter

    Cleaning agent: (brew mechanism) Coffee Queen article no 1104161 Filter: (brew mechanism) Coffee Queen article no 47200213 Tool: (dismantling filter)

  • Page 24: Cleaning Condenser

    8. Cleaning and maintenance Condenser Bean to cup hot n cold TT Condenser cleaning: Chiller unit. Must be cleaned every 6 month. With an extremily dusty environment you must have a much moore frequently cleaning . Loosen screw. see fig A. fig.

  • Page 25: Cup Counter And Easy Access

    9. Cup counter -Easy Access Bean to cup hot n cold TT Cup counter: The machine has a cup counter which is available to see and reset with the key switch in ”cup” (normal) position. Push ”-” button for 6 seconds. After 4 seconds the signal will go faster..

  • Page 26: Safety Functions

    10. Safety functions. Bean to cup hot n cold TT The machine is equipped with following safety functions ”Door open” Indication of door Door not closed The display shows; ”Door open” When machine is not in use: The valves are blocked. 11.

  • Page 27: Dimension Sketch

    13. DIMENSION SKETCH. Bean to cup hot n cold TT 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1...

  • Page 28: Circuit Diagram

    14. Circuit diagram. 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1...

  • Page 29: Installation Of Coin Mechanism

    15. Installation of coin mechanism. Installation of coin mechanism for Freshbrew machines CQ. IMPORTANT: Installation must been done of an authorized technician. 1. Assemble coin mec and connect to display-card, placed inside door. (see fig. 10). (10) ( Connect with the enclosed fig.

  • Page 30: Exchange Of Water Cleaning Filter

    Loosen cartridge by turn it 1/4 lap. See fig. A. (Open) Assemble the new cartridge by turn it 1/4 lap. See fig. A. (Close) Only use Coffee Queen original water cleaning filter: Article no: 1505344 Fig. A. Reset Timer: go to Easy Access.
  • Page 31 17. Spare part list. Bean to cup hot n cold TT Amount/unit Description; Art. no. Pos. no. Level sensor complete 120548 Gasket, silicone for sensor 150118-02 Heating element 2200W 230V 1601361 Water tank complete 7001305 Gasket, (lid water tank) 1206591 Motor gear 145 rpm, without axle 1604612 Motor axle for 1604612, 16mm...
  • Page 32 17. Spare part list. Bean to cup hot n cold TT Amount/unit Description; Art. no. Pos. no. 1604171 Grid cover for fan 1604172 Valve inlet 2,5 l/min 1206281 Solid state 1604201 Elektronik-card Ver. II 1604102 Fuse 4 Ampere (slow 5x20) 1604381 Decal - fuse 5/1Amp.
  • Page 33 17. Spare part list. Bean to cup hot n cold TT Amount/unit Description; Art. no. Pos. no. Ingredients canister B67 x H250 topp,choc. 1205617 1205671 Ingredients canister B160 x H250 (coffee) 1205621 1205675 Flat conductor cable 1606727 Diode lamp complete 1104544 Grinder 1604751...
  • Page 34 17. Spare part list. Bean to cup hot n cold TT Amount/unit Description; Art. no. Pos. no. Cooling unit 1104517 Compressor GD 40 MB 1104580 Starting capacitor för GD 40 MB 1104582 Thermostat K-50 L3019 1104594 Filter-dryer 10g 6,2-2,5 1104590 Condenser STFT 10215 MINI 1104609 Klixon...

  • Page 35: Spare Parts List

    17. Spare parts list. Bean to cup hot n cold TT Brew mechanism Description: Article no. Pos.no. Amount / unit Deflector, Cylinder 4720008 Pin, Crank Arm 4720010 O-ring Piston 4720012 Rubber Ring, Piston 4720013 Teflon Seal 4720014 Plate, Top 4720015 Screw, 8 x 1/2, Truss, AB, TAPP 4720016 Cylinder...

  • Page 36: Exploded View

    Bean to cup hot n cold TT 18. Exploded View. Watertank and mixing system Pos. 32. Silicone hose sales by metre see spare parts list...
  • Page 37 Bean to cup hot n cold TT 18. Exploded View. Parts in machine Exploded View brew mechanism. Fuse holder FUSE 4AT decal fuse Waste funnel top cabinet Fuse holder FUSE 2AT decal fuse Waste box top cabinet...
  • Page 38 Bean to cup hot n cold TT 18. Exploded View. Canisters Canister complete Canister complete 67 x 250 160 x 250...
  • Page 39 Bean to cup hot n cold TT 18. Exploded view. Door inside / Grinder 71 Fuse Light-emitting diode compl. 1104544...
  • Page 40 Bean to cup hot n cold TT 18. Exploded View. Machine Filter cold water hose (blue) sales by metre L= total 1,5m...
  • Page 41 Bean to cup hot n cold TT 18. Exploded View. Cooling unit...
  • Page 42 18. Exploded View. Brew mechanism...
  • Page 43 18. Exploded View. Brew mechanism...
  • Page 44 Bean to cup hot n cold TT FOR SERVICE Please contact your retail dealer Your retail dealer ................................................COFFEE QUEEN AB, Box 960, 671 29 ARVIKA, besöksadress; Korpralsv 1B, Tel vxl; +46 (0)570-47700, Fax; +46 (0)570-47719 E-mail: info@coffeequeen.se www.coffeequeen.se Art. nr/Art. no. 1704555...
