Huvema HU 250 CS Manual

Cutting off saws
Hide thumbs Also See for HU 250 CS:
Table of Contents

Advertisement

Quick Links

C U T T I N G
-
O F F
-
S A W S
HU 250 CS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HU 250 CS and is the answer not in the manual?

Questions and answers

Related Manuals for Huvema HU 250 CS

Summary of Contents for Huvema HU 250 CS

  • Page 1 C U T T I N G O F F S A W S HU 250 CS...

  • Page 2: Table Of Contents

    able of conTenTs General safety rules for all machines Technical data 2.1. The HU 250CS speed comprises as follows: 2.2. Survey and sketch of dimensions Description of machine Installation 4.1. Installation and mounting 4.2. Coolant 4.3. Electricity Operation 5.1. Selection of the sawblade 5.2.

  • Page 3: General Safety Rules For All Machines

    Hu 250 cs uTTing off saw eneral safeTy rules for all macHines N.B.: Read the instructions carefully in order to avoid any problems. As with all machinery there are certain hazards involved with operation and use of this machine. Using the machine with respect and caution will considerably lessen the possibility op personal injury.

  • Page 4: Technical Data

    ddiTional safeTy rules Always keep in mind that: • the machine must be switched off and disconnected from the power supply during maintenance and repairs, • clamped workpieces may only be measured when the machine is switched off. Never lean over the machine, mind loose clothing, ties, jewellery etc. and wear a cap. exceeded all claims relating to the faults concerned will expire.

  • Page 5: Installation

    4 Installation 4.1 Installation and mounting nsTallaTion 4.1. i nsTallaTion and mounTing Unpack the machine. Unpack the machine. • Determine where the sawing machine will be placed. In doing so take into account the • Determine where the sawing machine will be placed. In doing so take into account the feed and discharge of feed and discharge of materials, optional built -on accessories, maintenance and repairs.

  • Page 6: Operation

    peraTion 5.1. s elecTion of THe sawblade After years of research we recommend you to use only Timewinner saw blades. These HSS saw blades are of top quality and are made of the base material DMO 5. These saw blades have undergone a special heat treatment which guarantees high wear resistance.

  • Page 7: Sawing Capacity

    5.6 Sawing speed The following cutting speeds are po ssible: HU 250 CS > speed in position 1: 40 m/min. CHANGES AND T YPING ERRORS RESER VED in position 2: 80m/min...

  • Page 8: Sawing Speed

    20 m/min > For steel alloy e.g. stainless steel 40 m/min > For normal steel 80 m/min > For non-ferrous materials 5.6. s 5.7 Clamping the material awing speed The following cutting speeds are possible: • speed in position 1: 40 m/min. It is of the utmost importance that the material is safely clamped in the double material •...

  • Page 9: Maintenance

    ainTenance 6.1. g eneral Clean the machine after it has been used and provide rust protection by applying a protective oil. Regularly remove the chips which gather underneath the vice jaws. In doing so use a thin, flat brush and NEVER an air jet. The gears, the worm and the worm gear are subject to wear.

  • Page 10: Survey Of Available Saw Blades

    urvey of available saw blades Saw blades HSS DMO5, steam passivated Material Dim. (mm) Pitch Steel 250x2x32 3/240 teeth 250x2x32 4/200 teeth 250x2x32 5/160 teeth 250x2x32 6/128 teeth 250x2x32 8/100 teeth 250x2x32 10/72 teeth 250x2x32 12/60 teeth Stainless steel 250x2x32 3/240 teeth 250x2x32 4/200 teeth...

  • Page 11: Coolant System

    oolanT sysTem Coolant drawing Pos.no. Description Q,ty Pos.no. Description Q,ty Pos.nr. Description Q,ty Pos.nr. Description Q,ty Pedestal Sticker bewo general Pedestal Sticker Bewo general Pump set 230/400V 50 Cover Pump set * 230/400v 50 Hz cover Support pump Support pump Screw m6x12 Screw m6x25 Screw M6x12...

  • Page 12: Parts Drawing For Hu250Cs

    10. p Hu250cs Parts drawing for HU250CS arTs drawing for CHANGES AND T YPING ERRORS RESER VED...

  • Page 13: Parts List For Hu 250Cs

    10.1. p Hu 250cs arTs lisT for No.. Description Model Q’TY No.. Description Model Q’TY Socket screw M8X20 Socket screw M10X30 Pulling arm Socket screw M10X16 Socket screw M6X16 Vice table Spring ring Threaded shaft Safety guard Guiding shaft Socket screw M6X25 Vice plate Washer...
  • Page 14 Electro box Quantity per machine ELECTRO BOX Quantity per machine Pos.no. Description Art.no. Pos.nr. Description Art.nr. HU 250CS Switch box 60.0579 Switch box 60.0579 Cover 50.0955 Cover 50.0955 Sealing tape 21.9950 Sealing tape 21.9950 Screw M4x10 44.1000 Screw M4x10 44.1000 Screw M5x12 44.1583 Screw M5x12...
  • Page 15 CHANGES AND T YPING ERRORS RESER VED...
  • Page 16 All rights reserved. No part of this booklet may be reproduced in any form, by print, photoprint, microfilm or any other means without written permission from the publisher. © Huberts bv, Kennedylaan 14, Veghel, the Netherlands. Internet: www.huvema.nl CHANGES AND T YPING ERRORS RESER VED...
  • Page 17 (in accordance with supplement II A of the Machinery Directive) Industrie & Handelsonderneming Huberts bv, Kennedylaan 14, 5466 AA Veghel, the Netherlands, in the capacity of importer, is to be held responsible for declaring that the Huvema machine: Cutting off saw HU 250 CS...
  • Page 18 CHANGES AND T YPING ERRORS RESER VED...
  • Page 19 CHANGES AND T YPING ERRORS RESER VED...
  • Page 20 CHANGES AND T YPING ERRORS RESER VED...
  • Page 21 CHANGES AND T YPING ERRORS RESER VED...
  • Page 22 CHANGES AND T YPING ERRORS RESER VED...
  • Page 23 CHANGES AND T YPING ERRORS RESER VED...
