Summary of Contents for Huvema HU 150 PB
- Page 1 B A N D S A W I N G M A C H I N E HU 150 PB...
- Page 2 NUT M8 8 pcs Handle Screw -M8*20 mm 4pcs Rubber pad 4pcs...
-
Page 3: Safety Rules
SAFETY RULES 1. KEEP GUARDS IN PLACE and in working order. 2. REMOVE ADJUSTING KEYS AND WRENCHES. Form habit of checking to see that keys and adjusting wrenches are removed from tool before turning it on. 3. KEEP WORK AREA CLEAN. Cluttered areas and benches invite accidents. 4. -
Page 4: Grounding Instructions
parts, mounting, and any other conditions that may affect its operation. A guard or other part that is damaged should be properly repaired or replaced. 20.DIRECTION OF FEED. Feed work into a blade or cutter against the direction of rotation of the blade or cutter only. -
Page 5: Running In The Blade
Running in the blade To safe guard the life and quality of a New blade, the first two or three cuts must be made Exerting slight pressure on the piece so that the Cutting time is almost twice the one normally Needed (see cutting table) Correct positioning of the piece in the clamp : Pieces to be cut must always be held firmly in The clamp, directly between the two jaws and... -
Page 6: Specifications
PROFILE Operating button Operating handle Blade Guide Blade tension handwheel On/off switch Bow Saw Motor Reduction Gear Vice hand Revolving Arm Base Item Specifications Item Specifications Voltage 230 V Blade size 13 x 0.9 x 1735mm Motor 1500W Bow-Saw Aluminum Cutting Circular bar: 150mm, rectangular Base... - Page 7 41(1) 41(2) 41 40 M1 M2 8(1) 18(1)
- Page 9 NO Q'ty Description NO Q'ty Description NO Q'ty Description Body frame Block blade tension Vise cover Spring axis Return flywheel Screw Spring Saw blade Vise plate 32004 bearing MOTOR flywheel Screw Axis Screw Body cover Rod stock stop Washer Bolt Fixed blade gvide plate Cover Screw...
-
Page 10: Electric Scheme
ELECTRIC SCHEME Description 1 Description 2 Type Main switch IP54:250Vac TR26-21C-13D/L SM-8 Switch on handle 20.5A 125 / 250 Vac CE ZIPPY Overload protection 3.7A / 250 Vac Motor 1500W / 230V, IP54 Mains cable Ac 600V, 10A, 3G/0,75 mm... - Page 11 All rights reserved. No part of this booklet may be reproduced in any form, by print, photoprint, microfilm or any other means without written permission from the publisher. © Huvema BV, Kennedylaan 14, 5466 AA, Veghel, Nederland. Internet: www.huvema.nl CHANGES AND T YPING ERRORS RESER VED...
