  • Page 1 HU 315 ASK...

  • Page 2: Table Of Contents

    able of conTenTs General safety rules for all machines Additional safety rules Specification Outline Description Instruction of installation Unpacking and Inspection Lifting, Moving and Anchoring Connecting Electric Power Connecting Compressed Air Hose Filling coolant Procedure to instll the stopper Function of control devises Instruction of operation Preparation for Operation Steps of Operation...

  • Page 3: General Safety Rules For All Machines

    HU 315 asK 1. G eneral safeTy rUles for all macHines N.B.: Read the instructions carefully in order to avoid any problems. As with all machinery there are certain hazards involved with operation and use of this machine. Using the machine with respect and caution will considerably lessen the possibility op personal injury.

  • Page 4: Additional Safety Rules

    2. a ddiTional safeTy rUles Always keep in mind that: • the machine must be switched off and disconnected from the power supply during maintenance and repairs, • clamped workpieces may only be measured when the machine is switched off. Never lean over the machine, mind loose clothing, ties, jewellery etc.
  • Page 5 (2) Right side view (3) Left Side View (3) Left side view CHANGES AND T YPING ERRORS RESER VED...

  • Page 6: Instruction Of Installation

    5. i nsTrUcTion of insTallaTion Note: Please read the instruction carefully before installation. If having any question please contact your dealer for prompt service 5.1 U npacKinG and nspecTion (1) Check if there is any damage on the wooden case or the plastic bag that used to pack the machine. Should any damage be found on the machine, please claim for the damage against the delivery or insurance company.

  • Page 7: Instruction Of Operation

    vertical action of cutting head. Press the button once to get one cutting cycle. (4) Emergency Stop Button Stop all the actions of Item (3) immediately when the button is pressed. Turn the button clockwise to reset. (5) Uppermost Limit Adjustment Nut and Lowermost Limit Adjustment Nut By adjusting the uppermost limit adjustment nut and lowermost limit adjustment nut to actuate the position limit switches and to control the stroke of saw blade.
  • Page 8 For Size of Bar≥ 38 mm, the Formula for Number of Tooth T is as following T= 4×(Diameter of Saw Blade×3.14)÷(Size of Bar) 1. For stainless steel, the number of tooth is one grade more than mild steel. 2. For aluminum and copper, the number of tooth is one grade less than mild steel. 3.

  • Page 9: Steps Of Operation

    NOTE: Please refer to following figure for better understanding. 6.1.4 Adjustment of the Saw Blade Rotating Speed Turn the saw blade speed-selecting switch to one of “LOW”, “HI” or “OFF” position. 6.1.5 Adjustment of the Saw Blade Feeding Speed Turn the cutting head moving (saw blade feeding) speed adjustment knob clockwise or counter-clockwise.

  • Page 10: Daily Inspection And Maintenance

    6.3 d aily nspecTion and ainTenance 6.3.1 Gear Box of Cutting Head (1) Change gear oil SAE 140 every six months. (2) Check temperature of the gearbox during continuous operation. 6.3.2 Chip Collecting Tray Remove chip from collecting tray. 6. AIR-HYDRAULIC SYSTEM DIAGRAM 7.

  • Page 11: Electric Scheme

    9. e lecTric scHeme CHANGES AND T YPING ERRORS RESER VED...
  • Page 12 CHANGES AND T YPING ERRORS RESER VED...
  • Page 13 All rights reserved. No part of this booklet may be reproduced in any form, by print, photoprint, microfilm or any other means without written permission from the publisher. © Huberts bv, Kennedylaan 14, Veghel, the Netherlands. Internet: www.huvema.nl CHANGES AND T YPING ERRORS RESER VED...
