DIGITAL RECORDER
INSTALLER'S MANUAL
MODEL
DX-TL5000E
THIS INSTRUCTION MANUAL IS IMPORTANT TO YOU. PLEASE READ IT BEFORE USING YOUR DIGITAL RECORDER.
This manual is for the products manufactured on January 2006 or after.
1

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi DX-TL5000E

Summary of Contents for Mitsubishi DX-TL5000E

  • Page 1 DIGITAL RECORDER INSTALLER’S MANUAL MODEL DX-TL5000E THIS INSTRUCTION MANUAL IS IMPORTANT TO YOU. PLEASE READ IT BEFORE USING YOUR DIGITAL RECORDER. This manual is for the products manufactured on January 2006 or after.

  • Page 2: Features

    Dual Multiplexer Outputs The DX-TL5000E400/DX-TL5000E(Z) has two video outputs (Output A / B), and both of the outputs can show single-screen, 4, 9, 10, 13 and 16 split-screen, Switched Cameras, Alarmed Camera in live mode and Recorded pictures. On Screen Menu are shown only on monitor Output A. It is also possible to view playback pictures of different cameras at the same time with these two video outputs.
  • Page 3 Microsoft is either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. All other company and product names appearing herein are the property of their respective owners. ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• Beginning...

  • Page 4: Caution And Care

    Caution and care HEAVY OBJECTS SHOULD NEVER BE PLACED ON THE UNIT (E.G., MONITOR) NEVER TOUCH OR INSERT ANY OBJECT INSIDE THE UNIT Touching the inside of the cabinet or inserting foreign objects of any kind through the disc loading slot or ventilation holes not only creates a safety hazard but can also cause extensive damage.
  • Page 5 Note: This symbol mark is for EU countries only. This symbol mark is according to the directive 2002/96/EC Article 10 Information for users and Annex IV. Your MITSUBISHI ELECTRIC product is designed and manufactured with high quality materials and components which can be recycled and reused.
  • Page 6 Caution and care (continued) INSTALLATION LOCATION AND HANDLING • Place this unit horizontally and in a stable place. If this unit is not placed correctly and used in an unstable place, the unit may be damaged such as removal of the DVD/CD disc. •...

  • Page 7: Note

    Note Thank you for purchasing Mitsubishi digital recorder DX-TL5000E400/DX-TL5000E(Z) (hereinafter referred to as “Product”). Before using this Product, please be sure to read the Software License Agreement on page 7 of the user’s manual with regard to the software contained in this Product (hereinafter referred to as “Licensed Software”). By using this Product, you are agreeing to be bound by the terms and conditions of the following Software License Agreement.

  • Page 8: Table Of Contents

    Contents Features ..............2, 3 PTZ Control ............. 50 PTZ control using the menu ..........50 Caution and care ........... 4-6 PTZ control using the front panel buttons ......50 Note ................7 Setup Menu Contents ..............8, 9 Recording ............51-55 Flowchart ............
  • Page 9 Communications by Web Browser ....101-109 System Menu Communications by Web Browser ........101 COM/LAN ............74-76 The personal computer product requirements ..101 Connections .............. 101 RS-232C Setting ............... 74 Login ............... 101, 102 RS-485 Cascade Setting ..........74 Main Menu ...............

  • Page 10: Flowchart

    Flowchart Flowchart for connection and settings This is a flowchart of connection and settings for making an alarm recording with timer recording and then search, playback, and copy the recorded data. Connections Connections • Connections for camera, monitor, and sensor. •...
  • Page 11 Setting the motion detection Copy the data • Selecting the camera number. • Setting the copy device. • Setting the detection areas. See “ Add/Remove HDD Device” or “ Add/ • Setting the sensitivity. Remove DVD/CD Drive” on pages 80-82. •...

  • Page 12: Major Operations And Their Functions

    Major operations and their functions Front view BUSY PUSH 3 4 5 6 7 8 9 10 11 1. POWER indicator 10. COPY 1 indicator Illuminates when the unit is ON (MAIN switch on the Illuminates while performing copy 1 operation. rear is ON and the POWER button in the front has Flashes when starting or ending the copy 1 operation.

  • Page 13: Loading/Ejecting A Dvd Or Cd

    IRIS button Loading/Ejecting a DVD or CD Adjusts the iris of a camera. Press this button and then Before using a disc, read the cautionary notes described turn JOG to the left (close) or right (open) to adjust the in the manual included with the disc. iris.

  • Page 14: Front View (Inside Of The Door)

    Major operations and their functions (continued) Front view (inside of the door) 25 26 27 28 24 29 30 31 32 22. POWER button 31. BOOK MARK button Turns on the unit (MAIN switch on the rear of this unit When pressing this button during frame still playback must be ON).

  • Page 15: Rear View

    Rear view AUDIO IN VIDEO VIDEO OPTION SLOT CAMERA OUTPUT A OUTPUT B CLAMPER AUDIO CASCADE AUDIO OUT VIDEO CASCADE SERIAL BUS SERIAL BUS LAN-A LAN-B CLAMPER RESET STORAGE AC IN ALARM OUT ALARM IN P T Z RS485 RS485 MAIN RS-232C 100-240V...
  • Page 16 Major operations and their functions (continued) Rear view (continued) AUDIO IN VIDEO VIDEO OPTION SLOT CAMERA OUTPUT A OUTPUT B CLAMPER AUDIO CASCADE AUDIO OUT VIDEO CASCADE SERIAL BUS SERIAL BUS LAN-A LAN-B CLAMPER RESET STORAGE AC IN ALARM OUT ALARM IN P T Z RS485...

  • Page 17: Connections

    Connections Connecting to CCTV camera, monitor, and sensor Monitor To VIDEO IN or S(Y/C) IN connector To OUTPUT A VIDEO or OUTPUT A S(Y/C) connector Clamp the power cord using the supplied cable clamping band in order to prevent the One of either codes accidental removal of the cable.

  • Page 18: Alarm Recording Connection

    Connections (continued) Alarm recording connection The diagram below shows an example connection for setting alarm signal to sensor number 1. ALARM OUT ALARM IN RS-232C ALARM SWITCH EMERGENCY/ALARM IN/REC/CLOCK ADJ Input terminal • Input Circuit Active: When terminals are short-circuited or “Low” Level is applied. 0.047µF 10kΩ...

  • Page 19: Cascade Connection

    Cascade connection VIDEO MONITOR (LOCAL) VIDEO MONITOR (MASTER) To OUTPUT B To VIDEO CASCADE OUT Up to 16 cameras To AUDIO To CAMERA IN CASCADE IN DX-KB5UE KEYBOARD AUDIO IN VIDEO VIDEO OPTION SLOT CAMERA CAMERA OUTPUT A OUTPUT B Set the cascade address to "Master ID:01"...

  • Page 20: Attaching Or Removing The Hdd

    • Do not attach or remove the HDD unnecessarily. Attaching or removing the HDD of DX-TL5000E400/DX-TL5000E(Z) is intended to replace the faulty HDD or add the HDD when starting operation for the first time. It is not presumed to be used as a removable HDD.

  • Page 21: When Removing A Hdd

    4. Remove the metal part. When removing a HDD step • Remove 4 screws on the metal part. 1. Push the left end of each screw covers on both sides step of the cover to open. Do not leave the screw cover open for general use. 5.

  • Page 22: When Attaching A Hdd

    Connections (continued) 4. Insert the hard disk tray completely. When attaching a HDD step 1. Attach the new HDD onto the HDD tray with four step screws. • Make sure to attach the HDD in the correct direction. • Make sure to attach the screws to the correct position.
  • Page 23 8. Fix the front covers with two screws. step 9. Close the left end of each screw covers on both sides step of the cover. Follow the same procedures when removing or attaching the HDD B or HDD C. •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• Connections...

  • Page 24: Clamping The Cables

    Connections (continued) Clamping the cables 3. Pull the edge of the cable clamping band until it 1. Put the supplied cable clamping band into the step step stops. clamper hole on the rear panel. • There are 2 clamper holes on the unit, for power cable and USB cable.

  • Page 25: Optional Items

    Optional items Attaching the optional board DX-ZD5UE(Z) 1. Remove the 13 screws on both sides (4 X 2) and step HDD extension unit (serial bus connection type) rear side (5). The various external HDDs can be connected to this unit in order to expand the memory or to use as the copy device.

  • Page 26: How To Set The Menus

    How to set the menus Setting the menus The operations of this unit can be set via a menu displayed on OUTPUT A monitor. You can select and set the menu by using the buttons on the front panel or using a USB mouse connected to the unit. When using the front panel buttons, the numbers 1- 16 (camera number buttons) and letters A to E (SPLIT screen buttons) represent the GUI button of the menu screen.

  • Page 27: Displaying A Menu Screen

    Displaying a menu screen 1. Press the SET UP button or click the left button on step the mouse to display a menu. • The <User Menu> appears. • To open other menu, press the D button or left- click on “Next .”...

  • Page 28: Inputting Numbers

    How to set the menus (continued) Inputting numbers Number input area Using the front buttons of the unit: 1. Press the camera number buttons (0 to 9) to input step and use that number. Time Date Setting 241 000 000 •...

  • Page 29: Symbols In The Menus

    Symbols in the menus Up button Menu address Motion Search (Main - Normal) 116 000 000 Help button Camera Select Down button Search Start Position Left button Oldest Right button 0 1 - 0 1 Setup date search starts from. Motion Detection Settings Next >...

  • Page 30: Setup Wizard

    Setup Wizard Setup Wizard 1. After connecting the cameras and the monitors, turn step on the MAIN switch on the rear panel and wait until The setup wizard is displayed when the unit is turned on for the ACCESS indicator is turned off, then press the the first time.
  • Page 31 . (When selecting “Partition”) step Set the desired partition capacity. Normal Recording Area: The area for normal recording. Alarm Recording Area: The area for alarm recording. Long Pre-Alarm Area: The area for long pre-alarm recording. • Set the partition capacity for each area in 5 % unit.

  • Page 32: Menu Chart

    Menu chart Menu chart You can set the basic settings for this unit in the menu settings. Some of the menu settings cannot be changed during playback, recording, or stand-by mode for pre-alarm recording. User Menu User Menu (100 000 000) Menu Menu Address Functions...
  • Page 33 User Menu (100 000 000) Menu Menu Address Functions Pages Audio 1 Multiplexer Setting Switches the audio output among 1 to 4 during playback or displaying the picture from the camera. E Exit Exits the Audio menu. – Protect Data 1 Protect Recorded Data 151 000 000 Protects the recorded pictures.

  • Page 34: Setup Menu

    Menu chart (continued) Setup Menu Setup Menu (200 000 000) Menu Menu Address Functions Pages Recording 1 Set Recording Pattern A (Normal/Timer) Specifies the recording setting for recording pattern A. 51-53,116,117 211 000 000 1 Camera Check 211 100 000 Selects the camera number to be recorded.
  • Page 35 Setup Menu (200 000 000) Menu Menu Address Functions Pages Recording 3 Set Recording Pattern C (Timer) 213 000 000 Specifies the recording setting for recording pattern C. 51-53,120,121 1 Camera Check 213 100 000 Selects the camera number to be recorded. 51-53 2 Auto + D Set >...
  • Page 36 Menu chart (continued) Setup Menu (continued) Setup Menu (200 000 000) Menu Menu Address Functions Pages 5 Emergency Recording Setup 215 000 000 Specifies recording time for long pre-alarm recording. Also specifies 54,55,124 recording time, maximum recording rate, and camera for emergency recording.
  • Page 37 Setup Menu (200 000 000) Menu Menu Address Functions Pages 5 Multiplexer Setting 245 000 000 Specifies the multiplex display settings for Output A and Output B. 66,67,127 1 Settings > 245 100 000 Specifies the output A display settings and switching time of the output A 66,127 sequence settings.
  • Page 38 Menu chart (continued) Setup Menu (continued) Setup Menu (200 000 000) Menu Menu Address Functions Pages 5 Settings > 245 250 000 Specifies the output B split 16 display settings. 67,128 6 Settings > 245 260 000 Specifies the output B single sequence setting. 67,128 7 Settings >...

  • Page 39: System Menu

    System Menu System Menu (300 000 000) Menu Menu Address Functions Pages COM/LAN 1 RS-232C Setting 311 000 000 Specifies RS-232C port settings. 74,131 2 RS-485 Cascade Setting 312 000 000 Specifies RS-485 cascade settings. 74,131 3 LAN B (Communication) Setting 313 000 000 Specifies the communication setting between this unit and the personal 75,131 computer.
  • Page 40 Menu chart (continued) System Menu (continued) System Menu (300 000 000) Menu Menu Address Functions Pages Service Info 1 System Log List 331 000 000 Shows the number, date, and time of the system log. 2 Elapsed Operating Time 332 000 000 Shows the total operating time.
  • Page 41 System Menu (300 000 000) Menu Menu Address Functions Pages – Next Proceeds to User Menu. Restore 1 Restore Data to Main HDD from Drive1/2 341 000 000 Restores the data from the copy device. 1 Start/End + 2 Set > 341 2SE 000 Specifies the start and end points to be restored.

  • Page 42: User Menu

    Search User Menu Selecting the search function Find data storage location The various search functions of this unit can be used to go to This item is used to display the list of the devices used for the beginning of the desired picture. This unit is equipped with recording in the specified time period and to specify the de- 5 search functions.

  • Page 43: Search By Motion

    Search by Motion By specifying the motion detection conditions for playback, you can search the picture with the motion which meets the specified condition. For this function, the camera number and start time need to be specified to search. The search result is displayed in frame still playback of the single screen display.

  • Page 44: Copy

    Copy User Menu This item is used to copy the data to a copy device. When copying the data to DVD while “Overwrite” is set to “On,” the unit clears the existing data on the disc Copy Data to Copy 1 Drive/Set Copy 1 before overwriting with new data.

  • Page 45: Copying The Data Of This Unit To A Video Cassette

    specifying only the start point. The point is specified by the When copying the data while “Copy Data” is set to date and time or the bookmark. The copy continues until the “Alarm,” the unit performs copy operation, however, the end point of the recording data reaches or the media to be data is not copied if there is no alarm recording data copied becomes full unless the copy is stopped manually (when...

  • Page 46: Playback Software

    Copy (continued) User Menu 4. [Analogue video cassette recorder] Start recording. Operational panel step 5. [This unit] Press the PLAY button to start playback. step Rewind Click to jump to the head of the recording data. 6. To stop copying, press the STOP button on this unit step first.

  • Page 47: Copy

    Decode Level [Synchronized playback] Select [Synchro.] in the [Playback] field. You can play back When clicking, the options of [Fine], [Middle], and [Rough] simultaneously the audio and image of the data downloaded appear. When setting the decode level to rough, the picture becomes rough and the playback update speed becomes in blocks via network or the data copied together with audio faster.

  • Page 48: Information/Audio

    Information/Audio User Menu Information Audio This item is used to check the recording range of the main, This item is used to switch the audio channel from 1 to 4 dur- copy 1, or copy 2 device. ing playback or displaying the picture supplied from the camera. This function is available only when the optional audio interface board DX-SC5 is attached to this unit.

  • Page 49: Protect Data

    Protect Data User Menu Protect Data When the locked area is overlapped, the lock function is as follows. Up to 500 specified areas can be locked preventing acciden- tal deletion of important data. Only the data in the main device can be locked.

  • Page 50: Ptz Control

    PTZ Control User Menu This function is used to control the cameras connected via PTZ control using the front panel buttons RS-232C or RS-422/485 terminal. 1. Press the camera number button of the PTZ camera step PTZ control using the menu number to be controlled and display the picture in the single screen display.

  • Page 51: Setup Menu

    Recording Setup Menu Settings concerning normal recording and Set Recording Pattern A (Normal/Timer) to alarm recording D (Timer) This unit allows you to set the setting items for normal recording This item is used to make the recording settings for normal and alarm recording individually.
  • Page 52 Recording (continued) Setup Menu [Normal recording settings] 3. Select motion detection recording. step Alarm: Starts alarm recording when the motion is 1. Follow the steps 1 and 2 on page 97 to set the step detected. recording camera, frame or field recording, recording Normal: Starts normal recording when the motion rate, and picture grade for normal recording.

  • Page 53: Alarm Input

    When the pre-alarm recording time setting exceeds the When setting the trigger to “MD-A,” “MD-B,” “External / maximum pre-alarm recordable time, the pre-alarm MD-A,” “External / MD-B,” “External & MD-A,” or recording time display turns red. Set the time within “External &...

  • Page 54: Emergency Recording Setup

    Recording (continued) Setup Menu Emergency Recording Setup When you set the long pre-alarm recording time without setting the LPA area, long pre-alarm recording is carried This item is used to set the emergency recording settings. out using the internal memory for pre-alarm recording, When the EMERGENCY terminal is grounded by the alarm so long pre-alarm recording is performed for the short sensor while both of the MAIN switch on the rear panel and...

  • Page 55: Audio Recording Setup

    iii) To perform with alarm recording: Audio Recording Setup Set the “Alarm Mode” to “Alarm Plus.” This item is used to set the audio recording. This unit Long pre-alarm recording is performed at the picture simultaneously records audio along with the picture for camera grade of “Super”...

  • Page 56: Timer

    Timer Setup Menu Timer When you make the backup in timer recording, set the start and end time so that the backup time is 10 minutes This menu is used to program the timer of 2 most frequently or more. used operation patterns.

  • Page 57: Overlapped Timer Settings

    8. Press the TIMER button on the front panel of the Under this condition, the unit will give priority to Line 2 for the step unit. duration of the overlapping period, from 15:00 to 16:00. The unit will operate as shown in the chart below. •...

  • Page 58: Motion Det

    Motion Det Setup Menu Set Motion Detection Pattern A/Set Motion [When setting by the mouse:] • To set the area one by one, left-click the desired Detection Pattern B area. The area switches between active and This menu is used to set the conditions of the motion detec- inactive each time you click the mouse.
  • Page 59 6. Test the motion detection function on the condition step you have set. • The colour of the area detecting motion changes. 7. To copy another motion detection settings, use step “Same as settings.” • Select “Copy Motion A” to copy the setting for the same camera number of Motion A.

  • Page 60: System

    System Setup Menu Rear Terminal Setting Time/Date Setting This item is used to set the present date, time, and auto daylight Mode Out Settings saving. Auto daylight saving function is used to automatically This item is used to output the status of this unit from the MODE gain the clock of the unit an hour for the specified time period.

  • Page 61: Call Out Settings

    Key Sound “Main-Alarm” appears when “Alarm Recording Area” (System Menu Memory Data Management Setting This item is used to make a sound when using the operational for Main Memory Change Partition Setting) is set to buttons, JOG dial, and SHUTTLE ring. other than “0 %.”...

  • Page 62: Password Setting

    System (continued) Setup Menu Password Setting 4) Unlock the PASSWORD LOCK of level 2. • The PASSWORD LOCK of level 3 turns on. This menu is used to set the password for the lock function. This unit is equipped with 2 lock functions: When the PASSWORD LOCK of level 3 turns on, the following operations are locked.

  • Page 63: Activating The Password Lock

    [for the disk management password] Activating the PASSWORD LOCK . In the <Main Storage Memory> (System Menu Data step 1. Press the LOCK button while the MAIN switch is set step Clear), select “Clear” of desired area and then select to ON.

  • Page 64: Multiplexer Function Related Button Operations/Operation Table

    System (continued) Setup Menu Multiplexer function related button DIGITAL ZOOM button operations operations/operation table By pressing the DIGITAL ZOOM button during single screen display, the displayed picture can be viewed at 100%, 200% The multiplexer function of this unit allows the picture sup- or 400% magnification.

  • Page 65: The Function Of The Split, Sequence, Digital Zoom, And Camera Number Buttons

    The function of the SPLIT, SEQUENCE, DIGITAL ZOOM, and camera number buttons The screen of the camera number without video signal input appears blue. Furthermore, the screen of the camera number set to “Off” in the <Covert Camera Setting> appears blue. ( See page 68.) Page Display type...

  • Page 66: Multiplexer Setting

    System (continued) Setup Menu Multiplexer Setting [Split screen] 1. When using front panel buttons, press the C or D step This menu is used to set the multiplexer setting of <Output A button to select the display position to be set. Settings>...

  • Page 67: Output B Settings

    [Split screen] Output B Settings 1. When using front panel buttons, press the C or D step This item is used to set the camera number to be displayed in button to select the display position to be set. the split screen display on the monitor connected to OUTPUT When using the mouse, left-click the number of the B.

  • Page 68: Alarm Display Setting

    System (continued) Setup Menu Alarm Display Setting Setup Menu This item is used to switch the display to the picture input with alarm signal in the single screen display or split screen display System which has been pre-set. When another alarm signal is input during alarm recording, the picture with the latest alarm signal appears in the single screen display or split screen display.

  • Page 69: On Screen Display Setting

    Display mode example On Screen Display Setting Camera title (during single screen display) On Screen Information Warning Recorder title This item is used to set the display mode and the location for RECORDER1 CAMERA1 ALERT the clock, triplex, and camera display on the monitor. PLAY REM 20% REC [A]...

  • Page 70: Recorder Title

    System (continued) Setup Menu On Screen Information Recorder Title • Adjust the see-through level of the information This item is used to set the recorder title. When using the such as the clock or title. The degree of cascade function, setting the name of the slave recorder to transparency becomes lower as the higher the recorder title makes distinction of the recorder easy.

  • Page 71: Reset To Factory Setting

    Reset to Factory Setting This item is used to reset the menu settings. Setup Menu System Reset to Factory Setting 1. Select “Execute” to initialize menu settings. step The setting of present time, password, user ID and password of communication, and HDD settings (partition setting) are not reset.

  • Page 72: Menu Data

    This is done by loading the menu settings which is This item is used to save the menu settings of this unit to the copied from another DX-TL5000E400/DX-TL5000E(Z) via the external media such as USB memory, the DVD disc, or CD external device.

  • Page 73: Xga Monitor Settings

    Option Setup Menu Mode 5: Displays the pictures of output A and B XGA Monitor Settings diagonally. This item is used to specify the display mode and sharpness of the picture output via the optional graphic card DX-GC5. This menu is displayed only when the optional graphic card DX-GC5 is attached to this unit.

  • Page 74: System Menu

    COM/LAN System Menu This menu is used to set the communication settings between RS-485 Cascade Setting this unit and the external device connected. This item is used to make the settings for the cascade func- tion using the recorders connected via the RS-485 terminal. RS-232C Setting This item is used to remotely control this unit via a PC con- System Menu...

  • Page 75: Lan B (Communication) Setting

    [E-mail Notification Detailed Information] LAN B (Communication) Setting 4. Check the contents to be transmitted to the PC. step This item is used to make the communication settings between Remain: Transmits signal when the remaining this unit and the PC connected to LAN B terminal. capacity reaches the value set for Call out setting.

  • Page 76: Lan A (Nas) Setting

    COM/LAN (continued) System Menu LAN A (NAS) Setting Descriptions concerning NAS HDD settings This item is used to make the communication settings between To use NAS HDD with this unit, make the settings below. this unit and the copy devices. 1.

  • Page 77: Ptz Setting

    PTZ Setting System Menu This menu is used to make the settings for the cameras to be controlled. PTZ Camera Configuration This item is used to make the detailed settings for the cameras to be controlled. System Menu PTZ Setting PTZ Camera Configuration 1.

  • Page 78: Service Info

    Service Info System Menu System Log List Disk Information This item is used to check the number, date, and time of the This item is used to check the recording range of the main, system log. copy 1 or copy 2 device. System Menu System Menu Service Info...

  • Page 79: Restore

    Restore System Menu Restore Data to Main HDD from Drive 1/2/ Restore cannot be performed during recording, Export Drive 1/2 Configuration playback, or copying. However, restore is available during following playback: This item is used to restore the data from the copy device to •...

  • Page 80: Memory

    Memory System Menu Add/Remove HDD Device 6. Add or remove the SCSI HDD for setting the main step or copy device. This item is used to set the HDDs for main or copy device. Main: Registers for the main device. The numbers indicate the recording order.

  • Page 81: Notes For Using The External Device

    Notes for using the external device The various external HDDs can be connected to this unit in order to expand the memory or to use as the copy device, however, when you record or playback at high rate, the picture may be missed during recording or playback depending on the external device connected due to the delay of the data transfer rate or respond of the external device.

  • Page 82: Add/Remove Dvd/Cd Drive

    Memory (continued) System Menu Add/Remove DVD/CD Drive “Repeat of LPA Recording Area” can be set when “Long Pre-Alarm Area” (System Menu Memory Data This item is used to set the DVD/CD drive device for the DVD/ Management Setting for Main Memory Change CD group of the copy 1 or 2 device.

  • Page 83: Recording Data Readout Setting

    [Auto-Expire on Specified Date] Recording Data Readout Setting This item is used to disenable the data which is recorded be- You cannot set this item during recording or playback. fore the specified time period to be played back in order to prevent keeping the data beyond the specified period.

  • Page 84: Data Clear

    Data Clear System Menu Main Storage Memory Copy 1/Copy 2 This item is used to delete the data of the normal area, alarm This item is used to delete the data of each group in the copy area, or LPA area in the main device. 1 or copy 2 device.

  • Page 85: Other Convenient Functions

    TL5000E(Z). Set the ID number of this recorder to “Master ID:01,” and that of other DX-TL5000E400/DX-TL5000E(Z) to “Slave ID:02,” etc. When completing the ID number settings, “CASCADE MODE” displays on the LCD on the front panel. To operate this unit to view the picture from other DX-TL5000E400/DX-TL5000E(Z), follow the procedures below.

  • Page 86: Various Playback Functions

    Other convenient functions (continued) Various playback functions Frame-by-frame playback 1. Turn the JOG dial during still frame playback. Playing still frames step • Clockwise: Activates frame-by-frame playback in This unit is equipped with the various playback functions using the forward direction. the JOG dial or SHUTTLE ring.

  • Page 87: Changing Playback Intervals

    Changing playback intervals Triplex playback Although, playback and reverse playback use the same inter- This function is used to insert the playback picture of the desired val as that for recording, it is possible to change the playback camera number while displaying the picture supplied from the interval.

  • Page 88: Registering The Picture

    Other convenient functions (continued) Registering the picture This function is used to register a bookmark or copy the picture being displayed using the BOOK MARK button. Registering a bookmark 1. Press the PAUSE button during playback in the step single screen display. •...

  • Page 89: Functions Of The Unit In Case Of Power Failure

    Functions of the unit in case of power failure Power failure compensation circuit The unit is equipped with an internalized power failure compensation circuit. When the unit has been charged for 48 hours (full), the date, time, timer record settings, and menu settings are kept up to 1 month without power.

  • Page 90: Operation Examples

    Operation examples Operation example 1 Specifying the recording period and performing continuous repeat recording. For loading of a picture supplied from the camera, see “Relation of recording operation to the number of cameras and recording rate settings” on page 137. Operation •...

  • Page 91: Operation Example 2

    Operation example 2 Setting the areas for normal and alarm recordings individually. Operation • Performs alarm recording at the specified recording rate. • Performs normal recording at the specified recording rate. • Records the data of normal and alarm recordings to the different areas in order to store the alarm recording data for long term.

  • Page 92: Operation Example 3

    Operation examples (continued) Operation example 3 Switching the number of the cameras operated and recording rate depending on the time period and day of the week. Operation • Uses <Set Recording Pattern A (Normal/Timer)> from 08:00 to 18:00 on Monday to Friday. 08:00 18:00 08:00 (next day)
  • Page 93 Menu Settings Pages 58,59 [Motion detection settings] step Set the motion detection settings for Motion Setup Menu Motion Det step Set Motion Detection Pattern B A+12 Motion Mask Settings Test Mode [Timer settings] 56,57 step Set the timer program number to “Program 1.” Set the detailed timer recording settings as step Setup Menu...

  • Page 94: Operation Example 3

    Operation examples (continued) Operation example 4 Switching the number of the cameras operated and recording rate depending on the time period and day of the week. Also switching the motion detection condition depending on the time period (daytime and night) or day of the week. Operation •...
  • Page 95 Menu Settings Pages [Motion detection settings] Set the motion detection settings for Motion 58,59 step A and Motion B. Setup Menu Motion Det step Set Motion Detection Pattern A A+12 Motion Mask Settings Test Mode Set Motion Detection Pattern B A+12 Motion Mask Settings Test Mode...

  • Page 96: Basic Operations

    Basic operations Basic multiplexer functions The sequential display is cancelled when you press the SEQUENCE button again or display a different type This function is used to activate multiplexer functions using of split screen or single screen. the buttons on the front panel. Pressing the OUTPUT A/B button on the front panel switches the multiplexer video output.

  • Page 97: Basic Manual Recording

    Basic manual recording Setting the recording rate and picture grade for normal recording This function is to setup the recording parameters of record- ing setting pattern A to start recording manually. Ensure all the 1. Execute camera check. step cameras are connected and time and date has been set •...

  • Page 98: Basic Playback

    Basic operations (continued) Basic playback Pressing the OUTPUT A/B button on the front panel switches the multiplexer video output. When OUTPUT This function is used to playback recorded data. This unit allows A is selected, the button light indicator is off. When recorded data to be played back using various methods.

  • Page 99: Basic Search

    Basic search This function is used to search the start point of needed picture. This unit is equipped with 5 search functions (Search by Time and Date, Search by Alarm List, Find data storage location, Search by Book Mark, and Search by Motion). In this section, the common search methods, search by time and date and search by alarm list, are described.

  • Page 100: Search By Alarm List

    Basic operations (continued) Search by Alarm List To clear the alarm list, erase the HDD data of which the alarm recording is recorded (System Menu Data This unit stores the start time of alarm recording and emer- Clear). Beware that executing it erases all the data of gency recording in the alarm list when such recording begins.

  • Page 101: Communications By Web Browser

    Communications by Web Browser Communications by Web Browser Login The Web browser on the personal computer can capture the Start up the Microsoft Internet Explorer and log in. pictures that have been recorded and live pictures from the 1. Start up the Microsoft Internet Explorer and enter the camera that is connected to this recorder.

  • Page 102: Main Menu

    Communications by Web Browser (continued) . (If you make an error in entering the user ID or password Main Menu • • • ) This is the screen for selecting, from “Main menu,” “Live • The “[Caution]” screen appears. Monitoring” with which live pictures will be retrieved and dis- .

  • Page 103: Live Monitoring

    Live Monitoring Retrieves live pictures and displays the pictures on the PC screen. 1. Select “Live Monitoring” and left-click. • The “[Live]” screen appears. When picture acquisition is tried for the first time with the Web browser of a personal computer, a message as shown below may be displayed.

  • Page 104: Playback

    Communications by Web Browser (continued) Playback The date, time, and the camera number for the picture acquired are displayed in “Image Information.” Clicking Retrieves, plays back and searches for pictures that have been “Save Image” stores the picture that is still-frame recorded by the recorder.

  • Page 105: Alarm List Search

    Alarm List Search Click “Alarm List” and the “Alarm List Search” screen appears in the sub-screen. 2. Select the desired “Configuration Menu” and left-click. User Registration This is the screen for changing the settings for registered user authorization, and for deleting a registration. It can also be 1.

  • Page 106: User Registration

    Communications by Web Browser (continued) . (To change the access method settings • • • ) Certain items cannot be selected depending on what the user authorization is. Select the item to be changed in the “Access Mode Setup.” “Configuration” authorization can be used by only one •...

  • Page 107: Recorder Title & Camera Titles

    3. To send the test e-mail, select “From Address Test (send Recorder Title & Camera Titles test mail)” and left-click. This is the screen for setting or changing the recorder and the camera titles. 4. (When attaching alarm recording picture to e-mail • • •) 1.

  • Page 108: Nas Setup

    Communications by Web Browser (continued) NAS Setup Clock Setup This is the screen for setting the clock of the recorder via PC. This is the screen for making the settings to connect to the NAS server, and for mounting or removing the NAS server. 1.

  • Page 109: Logout

    Logout Change Login User In this screen, assign “Logout” settings to end the job. This screen is for changing the logged in user. 1. Select “Logout” and left-click. 1. Select “Change Login User” and left-click. • The “[Logout]” screen appears. •...

  • Page 110: Recording Time Table

    Recording time table Continuous recording time table The following table shows the total number of recordable pictures of all the cameras which are set for recording. When recording on a 250 GB HDD: Without audio recording d : day, h : hour Number of pictures /sec.

  • Page 111: With Audio Recording

    When recording on a 400 GB HDD: Without audio recording d : day, h : hour Number of pictures /sec. 66.7 33.3 Picture grade Super 1d2h 1d15h 2d5h 2d18h 3d6h 4d10h 6d22h 8d12h Fine 1d7h 1d22h 2d14h 3d6h 3d20h 5d5h 8d3h 10d1h High...

  • Page 112: Troubleshooting

    Troubleshooting If problems with the unit persist even after you’ve followed the suggestions below, disconnect the power cord and contact the retailer from whom you purchased the unit. Description of problem Please consult the following Page The unit does not be •...
  • Page 113 Description of problem Please consult the following Page 12,62,63 The unit does not perform • Is the LOCK indicator light on? playback. • Has the data been erased? 42,98 • Is the correct playback device selected? The copy device dose not –...

  • Page 114: Warnings And Call Out Output

    Warnings and CALL OUT output Warnings and their appropriate countermeasures #1 Options in the CALL OUT output column: • Selectable: Selects to output CALL OUT signal or not on the menu screen. • Fixed: Outputs CALL OUT signal from the CALL OUT terminal regardless of the menu setting. •...
  • Page 115 CALL OUT Cancelling Page Countermeasure Log number Warning Display output the warning No Camera Signal • Check whether the unit Fixed Stop recording. LOG54 and camera are properly Camera signal is lost or distorted. connected and turned on. – Please check the camera and cable •...

  • Page 116: Check Sheet

    Check sheet The following is the sheet for writing down each settings. Use it when you make settings. The screened values are the default settings. The items marked with * are the menus which is loaded or saved using <Menu Data>.
  • Page 117 3 Alarm Recording Menu (continued) Motion Detection Alarm Post-Alarm Duration Pre-Alarm Duration Mode Recording 4 Alarm Camera Setting Recording Camera Sensor number 1 Sensor number 2 Sensor number 3 Sensor number 4 Sensor number 5 Sensor number 6 Sensor number 7 Sensor number 8 Sensor number 9 Sensor number 10...
  • Page 118 Check sheet (continued) Set Recording Pattern B (Timer) * 2 Normal Recording Menu Frame / Recording Rate Picture Grade Field Camera number 1 Camera number 2 Camera number 3 Camera number 4 Camera number 5 Camera number 6 Camera number 7 Camera number 8 Camera number 9 Camera number 10...
  • Page 119 3 Alarm Recording Menu (continued) Motion Detection Alarm Post-Alarm Duration Pre-Alarm Duration Mode Recording 4 Alarm Camera Setting Recording Camera Sensor number 1 Sensor number 2 Sensor number 3 Sensor number 4 Sensor number 5 Sensor number 6 Sensor number 7 Sensor number 8 Sensor number 9 Sensor number 10...
  • Page 120 Check sheet (continued) Set Recording Pattern C (Timer) * 2 Normal Recording Menu Frame / Recording Rate Picture Grade Field Camera number 1 Camera number 2 Camera number 3 Camera number 4 Camera number 5 Camera number 6 Camera number 7 Camera number 8 Camera number 9 Camera number 10...
  • Page 121 3 Alarm Recording Menu (continued) Motion Detection Alarm Post-Alarm Duration Pre-Alarm Duration Mode Recording 4 Alarm Camera Setting Recording Camera Sensor number 1 Sensor number 2 Sensor number 3 Sensor number 4 Sensor number 5 Sensor number 6 Sensor number 7 Sensor number 8 Sensor number 9 Sensor number 10...
  • Page 122 Check sheet (continued) Set Recording Pattern D (Timer) * 2 Normal Recording Menu Frame / Recording Rate Picture Grade Field Camera number 1 Camera number 2 Camera number 3 Camera number 4 Camera number 5 Camera number 6 Camera number 7 Camera number 8 Camera number 9 Camera number 10...
  • Page 123 3 Alarm Recording Menu (continued) Motion Detection Alarm Post-Alarm Duration Pre-Alarm Duration Mode Recording 4 Alarm Camera Setting Recording Camera Sensor number 1 Sensor number 2 Sensor number 3 Sensor number 4 Sensor number 5 Sensor number 6 Sensor number 7 Sensor number 8 Sensor number 9 Sensor number 10...
  • Page 124 Check sheet (continued) Emergency Recording Setup * Frame / Pre-alarm Duration Post-alarm Duration Field Maximum Camera Setting Recording Rate for All Cameras Audio Recording Setup * Audio Record Channel 1 Channel 2 Channel 3 Channel 4 Audio Recording Mode Normal Alarm Timer Configure Timer Program 1 *...
  • Page 125 Configure Timer Program 2 * Motion Detection Day of The Week Time Program Mode Special Day Start Define Holidays * (Date / Month) Motion Det * 1 Set Motion Detection Pattern A 2 Set Motion Detection Pattern B Reference Interval Sensitivity Reference Interval Sensitivity...
  • Page 126 Check sheet (continued) System Menu Language Selection * P y CCK N ENGLISH DEUTSCH FRANÇAIS ITALIANO ESPAÑOL Rear Terminal Setting * 1 Mode Out Settings Mode Out 1 to 4 Low Memory Alarm Setting Trigger Polarity Device Low Memory Mode Out 1 Mode Out 2 Mode Out 3 Mode Out 4...
  • Page 127 Multiplexer Setting * 1 Output A Settings Split 4 screen Split 9 screen 1 Output A Settings (continued) Split 13 screen Split 10 screen Split 16 screen [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ]...
  • Page 128 Check sheet (continued) Multiplexer Setting * (continued) 2 Output B Settings Split 4 screen Split 9 screen 2 Output B Settings (continued) Split 13 screen Split 10 screen Split 16 screen [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ]...
  • Page 129 Alarm Display Setting Output Setting Output A Output B Sensor 1 Sensor 2 Sensor 3 Sensor 4 Sensor 5 Sensor 6 Sensor 7 Sensor 8 Sensor 9 Sensor 10 Sensor 11 Sensor 12 Sensor 13 Sensor 14 Sensor 15 Sensor 16 5 Covert Camera Setting * On Off CH 1...
  • Page 130 Check sheet (continued) On Screen Display Setting * 1 On Screen Information Clock Triplex Camera Location Mode Mode Mode Location Location 2 Camera Title 4 Recorder Title Camera number 1 Display Mode Camera number 2 Recorder Title Camera number 3 Camera number 4 Camera number 5 Camera number 6...

  • Page 131: System Menu

    Option XGA Monitor Settings * Display Mode Sharpness Setting Setting System Menu (300 000 000) COM/LAN RS-232C Setting * Port Settings Communication Data Stop Transmission Delimi Mode Parity Bit Mode -ter Length Length RS-485 Cascade Setting * Cascade Connection Recorder Address Mode LAN B (Communication) Setting * IP Address...
  • Page 132 Check sheet (continued) PTZ Setting PTZ Camera Configuration * Tilt Port Reverse Reverse Device Device ID Camera number 1 Camera number 2 Camera number 3 Camera number 4 Camera number 5 Camera number 6 Camera number 7 Camera number 8 Camera number 9 Camera number 10 Camera number 11...
  • Page 133 Memory Add/Remove HDD Device Main device 1 Internal HDD 2 External HDD (USB HDD) 3 External HDD (SCSI HDD) Copy 1 device SerialBus NAS group group SCSI group DVD/CD USB memory •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• Check sheet...
  • Page 134 Check sheet (continued) Add/Remove HDD Device (continued) Copy 2 device Internal NAS group group SerialBus group SCSI group DVD/CD Add/Remove DVD/CD Drive Select using for Copy1 or Copy2 Copy1 Copy2 ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••...
  • Page 135 Data Management Setting for Main Memory Main Device Settings Repeat of Normal Recording Area * Repeat On Repeat Off Repeat of Alarm Recording Area * Repeat On Repeat Off Repeat of LPA Recording Area * Repeat On Repeat Off 4 Change Partition Setting Normal Recording Area 4 Change Partition Setting (continued) Alarm Recording Area...

  • Page 136: Glossary

    Glossary Glossary Motion Detection Playback Search This is a function to automatically search a recorded picture Auto PAN by detecting motion in the selected detection area. Setting the When a camera is set to this mode, it automatically turns detection area for searching is required before activating this between two preset positions horizontally.

  • Page 137: Relation Of Recording Operation To The Number Of Cameras And Recording Rate Settings

    Relation of recording operation to the number of cameras and recording rate settings The recording pattern of this unit is as illustrated in the diagram below. Picture data input from all the connected cameras is recorded sequentially. (Approx. every 0.005 second during normal recording.) The example when setting a setup of each channel to “1 pps”...

  • Page 138: Specifications

    DVD-R/RW, CD-R/RW recording format Original format Accessories: AC power cord (for U.K/for the Continent) Screws 8 (DX-TL5000E400) 12 (DX-TL5000E(Z)) Cable clamping band Installer’s manual (this manual) User’s manual Weight and dimensions shown are approximate. Design and specifications are subject to change without notice.

Table of Contents
