4.1 General Settings:
The General Settings
miscellaneous settings that are configured. The
following configuration settings can be seen under the
General Settings:
• Fan Speed
• Flow Boundary
• AirFlow Delay
• Trend Period
• Address
• Alarm Tone
• Fault Tone
• Acclimate
4.2 Network:
• MAC
• IP Address
• Subnet Mask
• Gateway
• DNS Primary
• DNS Secondary
• DHCP Status
• Device Name
4.3 Email
The Email menu screen provides the options for a
detailed look of the email settings in the device.
scroll ( ) keys to select an option and then select (
to confirm the selection
• Device Account
• Addresses
4.4 ModBus:
• Mode
• IP Address
• Port
• Address
4.5 Alarm Settings:
• Alarm Threshold
• Night Mode
• DST Setting
• Alarm Delays
•
Relay Settings
4.6 Information:
The Information screen provides the text information
that is configured on the device from PipeIQ. The fields
include Facility Name and Location, Device Location
and Contact Person.
Use the scroll (
up or down the information
5. Event History:
The Event History can be viewed through the LCD
screen. The Event History screen displays the event
number currently being displayed, the total number
events available, and the event detail for the currently
displayed event.
Use the scroll (
down the events
6. Message Log:
The Message Log history can be viewed through the
LCD screen. The Message Log screen displays the
message number currently being displayed, the total
number of messages available, and the message.
the scroll ( ) keys to advance up or down the messages.
© Pertronic Industries Ltd
FAAST 7100X
INSTALLATION AND MAINTENANCE INSTRUCTIONS
screen provides the
Use the
) key
) keys to advance
o
) keys to advance up or
Use
8
7. LCD Setting:
The LCD settings menu allows the user to adjust the
language, backlight and contrast settings for the LCD.
This feature can be locked out and require the user to
enter a 4 digit access code to enter the LCD menu. This
four digit access code is configurable through PipeIQ.
When a user selects the LCD Settings menu from the
main menu screen with the lock feature enabled, the
enter password screen will be displayed. Once in the
settings menu use the
then select ( ) key to confirm the selection
7.1 Language:
The Language screen allows the user to change the language
on the LCD. 16 languages are available
7.2 BackLight:
The Backlight screen is used to adjust the brightness of
the backlight.
Use the scroll (
decrease the brightness, then select (
setting
7.3 Contrast:
The Contrast screen is used to adjust the contrast of the
text.
Use the scroll (
contrast
7.4 Display TimeOut:
The Time Out information set for the unit is displayed
8. Diagnostics:
Information on system diagnostics is displayed
• FW Version
• Sensor Processor
• Comms Processor
f
FAAST XS (7100X) Installation Guide Iss 1.0, 201606
scroll ( ) keys to select an option,
) keys to increase or
) key to register the
) keys to increase or decrease the
