INSTALLATION AND MAINTENANCE INSTRUCTIONS
FAAST 7100X and 7100XA
Fire Alarm Aspiration Sensing Technology
SPECIFICATIONS
Electrical Characteristics
External Supply Voltage
Remote Reset Time
Power Reset
Relay Contact Ratings
Environmental Ratings
Operating Temperature
Sampled Air Temperature
Humidity
The purpose of this document is to provide practical information for mount-
ing and connecting to FAAST XS. For full product information, which includes
installation guidelines, instructions for safe use, and warranty and safety
information, refer to the FAAST XS Comprehensive User Guide available at
systemsensor.com/7100Xuserguide or by scanning the QR code.
ITEMS INCLUDED WITH UNIT
• FAAST XS (7100X or 7100XA) device
• Mounting bracket and hardware
• Installation and Maintenance Instructions
• USB interface cable
• PipeIQ® software, comprehensive manual, and other helpful documents
are available at systemsensor.com/faast
CONNECTING TO FAAST XS
FAAST XS requires a valid configuration from PipeIQ in order to initialize. The
device must be connected to a PC running PipeIQ with either the USB port, or
the Ethernet port located inside the wiring cabinet.
CONNECTING TO FAAST XS VIA USB
NOTE: In order to connect your computer to the FAAST XS using a USB con-
nection, a USB driver must first be installed. The driver installation occurs
during the installation of PipeIQ version 2.2 or later. Once the driver is in-
stalled, connect to the device using the following steps.
1. Launch PipeIQ. (Download from www.systemsensor.com/faast.)
2. Create a new project and select FAAST XS device, or open an existing project
3. Expand the tree view in the left side navigation pane to reveal the device
4. Right click on the device and select 'Connect Device'
5. Select USB, The USB combo box should already be populated with FAAST
XS (COM Port Number).
6. Select 'Admin' and enter the password – the default password is 'password'
– then hit 'Connect'
CONNECTING TO FAAST XS VIA ETHERNET
Default Device IP Configuration
IP Address: 192.168.1.10
Subnet Mask: 255.255.255.0
Default Gateway: 192.168.1.1
Primary DNS: 0.0.0.0
Secondary DNS: 0.0.0.0
CONFIGURE YOUR PC
Your PC will need to be sitting on the same local area network as the FAAST
XS device in order to establish communication. Change your PC's IP address to
192.168.1.15 by:
1. Accessing your network setting in your PC's control panel
2. Open 'Local Area Connection' settings and select 'Properties'
3. Select 'Internet Protocol Version 4 (TCP/IPv4) and then select 'Properties'
SS-600-012
18 – 30 VDC
External monitor must be pulled low for a minimum of 100 msec
1 sec
3.0A @ 30VDC, 0.5A @125VAC
32°F (0°C) to 100°F (38°C) – Factory tested to 131°F (55°C)
-4°F (-20°C) to 140°F (60°C)
10 to 95% non-condensing
®
4. Select 'Use the following IP address and enter 192.168.1.15. If the sub-
net mask does not automatically populate, enter 255.255.255.0 into
the subnet mask field.
5. Hit OK and close out of the network menus.
Important Note: Before changing your PC's IP address, be sure to take note of
whether your IP is currently dynamically set, or is a static IP address. If your PC
is assigned a static IP address, make note of all IP address and settings so that
you can change back to the proper settings after the FAAST has been configured.
CONNECT USING PIPEIQ
1. Launch PipeIQ. (Download from systemsensor.com/faast)
2. Create and save a new project, or open an existing project
3. Expand the tree view in the left side navigation pane to reveal the device
4. Right click on the device and select 'Connect Device'
5. Select Host/IP and type in the device's IP address
192.168.1.10
6. Select 'Admin' and enter the password – the default password is
'pass word' – then hit 'Connect'
7. Upon connection, a green dot will appear on the device icon in the
navigation tree
INSTALLATION
This equipment must be installed in accordance with all local and national
codes and regulations.
PIPE INSTALLATION
The pipe layout is designed using the PipeIQ software package. Refer to the
Comprehensive Instruction Manual to design the pipe network. All pipe must
be installed in accordance with local and national codes and regulations. The
pipe network should be complete before proceeding with the physical and
electrical system installation.
PHYSICAL UNIT INSTALLATION
Make sure that there are no pipes or electrical wires within the wall before
drilling any mounting holes
SECURING THE MOUNTING BRACKET
The typical mounting location for the FAAST XS unit is on the wall. The unit is
mounted to the wall using the enclosed mounting bracket. Figure 1 shows the
wall mounting bracket. For easier access to the FAAST XS unit, it is preferred
to position the mounting bracket in an easily accessible location.
1. Place the mounting bracket on the wall in the desired location and use
it as a template to locate the necessary mounting holes.
2. Mark the hole locations and remove the bracket. It is recommended to
secure the bracket using both mounting holes.
3. Using a drill and the proper size bit for your mounting hardware, drill
the necessary holes.
4. Use appropriate fasteners to accommodate the mounting surface and
FAAST XS device weight.
5. Secure the bracket to the wall.
1
3825 Ohio Avenue, St. Charles, Illinois 60174
1.800.SENSOR2; Fax: 630.377.6495
www.systemsensor.com
WARNING
I56-6006-001
