A. Specifications:....................................... 1
Introduction:...............................................2
Description:............................................... 2
Installation:................................................ 2
Wiring........................................................ 3
User Interface:............................................ 5
Modes of Operation:.................................... 9
Logs.........................................................11
External Monitor / Reset............................. 11
Connections............................................ 11
Pipe Network........................................... 11
Web Server............................................. 11
Smoke Tests........................................... 11
Maintenance................................................. 11
B. Connection Using PipeIQ......................... 12
PipeIQ Quick Start Instructions...................... 12
Configuration............................................ 12
Design...................................................... 17
Document Colour Code Key:
SS Blue: Document Headers
Black:
general instructions/information applying to 7200BPI Device
Blue:
important settings to be configured on each 7200BPI

SPECIFICATIONS:

Electrical Characteristics:
External Supply Voltage
Remote Reset Time
Power Reset
Average Operating Current
Alarm Current
Additional Current Requirements
Average Loop Driver Operating Current: 700µA
Loop Driver Voltage Range:
Relay Contact Ratings
Environmental Ratings:
Operating Temperature
Sampled Air Temperature
Humidity
Hazardous Environments
IP Rating
Coverage Area
Ambient Air Movement
Mechanical Characteristics:
Exterior Dimensions
Cable Access
Wire Gauge
Shipping Weight
Nett Weight
Pipe Network Size:
Maximum single pipe length
External pipe diameter
Internal pipe diameter
© Pertronic Industries Ltd
FAAST 7100X
INSTALLATION AND MAINTENANCE INSTRUCTIONS

TABLE OF CONTENTS

(refer to Page 28)
18 - 30V
DC
External monitor must be pulled low for a minimum of 100msec.
10 secs (FAAST 7200BPI); 1 sec (FAAST 7100X)
Fan Hi: 200mA; Fan Med: 151mA; Fan Lo: 120mA @ 24V
Fan Hi: 230mA; Fan Med: 172mA; Fan Lo: 142mA @ 24V
LCD ON: 10mA; EtherNet Enabled: 20mA; Serial ModBus Enabled: 20mA
15 - 32V
DC
3.0A @ 30V
, 0.5A @ 125V
DC
0°C to 38°C
-20°C to 60°C
10 to 95% (non-condensing)
Suitable for use in Class I, Division 2, Groups A, B, C & D,
or Non-Hazardous locations only
IP30
2
600m
0 - 1,219.2m/min.
280 x 230 x 160
3 x 25.4mm cable entry holes on top, back and left of unit.
2.0mm (12 AWG) max to 0.5mm (24 AWG) min.
4kg, includes packing material
3kg
2
Up to 600m
54.8m
25mm
15 - 21mm
1
Conventional F16e/F4/F100LR-3................. 20
Views...................................................... 21
Required Items......................................... 22
Commissioning and HandOver.................... 22
Commission Testing.............................. 22
Inspection of Installation........................ 22
Power Up/Configuration...................... 22
Commissioning Tests............................23
Signalling.......................................... 24
System Check................................... 24
System Handover............................... 24
G. Flow Rate Conversion Table..................... 25
Glossary.................................................. 26
AC
(32°F to 100°F)
Factory Tested to 55°C (131°F)
(-4°F to 140°F)
2
(6,450ft
)
(0 - 4,000 ft/min.)
H x W x Dmm
FAAST XS (7100X) Installation Guide Iss 1.0, 201606
DC
DC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FAAST 7100X and is the answer not in the manual?

Questions and answers

Related Manuals for System Sensor FAAST 7100X

Summary of Contents for System Sensor FAAST 7100X

  • Page 1: Table Of Contents

    Remote Reset Time External monitor must be pulled low for a minimum of 100msec. Power Reset 10 secs (FAAST 7200BPI); 1 sec (FAAST 7100X) Average Operating Current Fan Hi: 200mA; Fan Med: 151mA; Fan Lo: 120mA @ 24V Alarm Current Fan Hi: 230mA;...

  • Page 2: Introduction

    FAAST 710 INSTALLA ATION AND MAINTENA ANCE INST TRUCTION Installation ) Introductio his equipmen nt must be in nstalled in a accordance w with all cope of this Manual: cal and natio onal codes an nd regulation he purpose of this docu ument is to p provide guida ance...

  • Page 3: Wiring

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS Exhaust Pipe Mount the Detector to the Bracket The device should always be exhausted into the space Once the mounting plate is attached, the unit is ready to that it is monitoring. There are some circumstances when be mounted onto the plate.
  • Page 4 INSTALLATION AND MAINTENANCE INSTRUCTIONS FAAST 7100X to FACP Wiring Diagram FAAST 7100X Cabling Requirements The FAAST 7100X provides a series of Euro style pluggable terminals, located behind the door on the upper left side of the unit. Refer to Table 1b for the proper electrical connections to...

  • Page 5: User Interface

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS Alarm Level Display: e) User Interface: The alarm level display consists of three red LEDs The user interface, shown in Figure 5, provides the whose illumination corresponds to the current alarm following information: • Detector status: Normal, Alarm, General Fault, level, shown in Figure 7.
  • Page 6 FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS LCD User Interface: Fault Display: The FAAST XS has an LCD screen to provide detailed The FAAST XS user interface displays faults in two ways: using information of the device’s status and configuration. The LCD amber LEDs on the right side of the user interface and on the typically will be in an idle state where the screen is off.
  • Page 7 FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS 3.2 Disable: Main Menu Screen: Use the scroll ( ) keys to Increment or Decrement the The Disable function sets the device into Disable mode. number the cursor is on. To register the number, use the When selected the device requests confirmation.
  • Page 8 FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS 4.1 General Settings: 7. LCD Setting: General Settings screen provides The LCD settings menu allows the user to adjust the miscellaneous settings that are configured. The language, backlight and contrast settings for the LCD.

  • Page 9: Modes Of Operation

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS Audible Indicator Configuration: Modes of Operation: The FAAST XS has an integrated audible indicator Initialisation: which provides the option to include a supplementary When the FAAST XS system is initially powered up it is...
  • Page 10 FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS Day, Night, Weekend Mode: Reset AirFlow Baselines: Day, Night, Weekend mode is the default setting which The AirFlow baselines may be reset through the LCD may be used if Acclimate mode is not desired. This screen.

  • Page 11: Logs

    All FAAST systems must be tested after installation and External Monitor / Reset: periodically thereafter. The FAAST 7100X has an External Monitor that can Test methods must satisfy the (AHJ) authority having detect an open or short when the supplied 47KΩ end of jurisdiction.

  • Page 12: Connection Using Pipeiq

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS SECTION B : CONNECTION TO FAAST XS USING PIPEIQ Connection to the FAAST XS detector is available using either the in-built USB ‘B’ or RJ45 EtherNet sockets located in the wiring cabinet. These interfaces allow access to a range of additional options, via the PipeIQ application software, when connected to a PC.
  • Page 13 FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS equipment required - Ethernet Connection: a) RJ45 EtherNet connector: the FAAST XS series detectors have an RJ45 socket sockets located in the wiring cabinet b) USB – EtherNet Adaptor : this sequence is based upon configuration of a Digitus DB-3023 USB 3.0 EtherNet Adapter (i) Install the Digitus Driver software –...

  • Page 14: Configuration

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS SECTION C : CONFIGURING FAAST XS (7000 SERIES) IN PIPEIQ A. Configuration: he following screen shots identify the parameters which are configurable on the 7000 Series FAAST XS devices. Review all parameters to ensure they are appropriate, taking particular care to ensure the...
  • Page 15 FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS c) Network: Passwords: FAAST XS devices have two types of password: - Web Access required to Password: access remote monitoring available via a web browser the default Password is 1234 Administrator Password - required to...
  • Page 16 FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS e) User Interface: Function Lockout: sets the Passcode to make the buttons available at the user interface - default Passcode is 1111 (ii) Lockout Configuration Menus: - Device controls Configuration: ability to select 4 Configuration options...

  • Page 17: Design

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS B. Design: The following screen shots illustrate how to set the Hole Sensitivity from the Calculation window in Design Setting Hole Sensitivity: design the required pipe layout to meet the system layout requirements select the Calculation icon select Set Hole Sensitivity (ii) set the Target Sensitivity for each of the activation levels: Alert;...

  • Page 18: Pertronic Industries Ltd

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS (iii) identify cells which do not meet the system constraints – highlighted in (iv) select Settings \ Constraints, then CUSTOM - first review the Sensitivity settings used by VEWFD, EWFD or SFD to identify appropriate settings...

  • Page 19: Refer To

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS (vi) the amended Sensitivity settings will be reflected in the Sensor settings in Configuration – refer to Threshold Levels (%/m) under Alarm Threshold and Delay in Configuration \ Sensor - in the screenshot below, the Day Threshold Levels reflect the fact the Day Sensitivity has been...

  • Page 20: Configuring Pertronic Fire Alarm Panels

    - as many Activation Levels (1–3) as required may be used, since each uses a separate Input Module. Sensitivity: the FAAST 7100X detector Threshold Levels are configured at the detector : Configuration \ Sensor - three Activations Levels are available: ALERT, FIRE 1 and FIRE2 - each level provides individual Threshold Levels (sensitivity) for Day, Night and Weekend use B.

  • Page 21: Monitoring Faast Xs Using Pipeiq

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS SECTION E : MONITORING FAAST XS USING PIPEIQ This section identifies options for testing the FAAST XS and monitoring its environment: Views: The PipeIQ™ Actions tab enables: replicates the FAAST XS front panel Mimic View:...

  • Page 22: System Testing And Commissioning

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS SECTION F : SYSTEM TEST AND COMMISSIONING: ensure the following items are available: Required Items: a) FAAST System Pipe Layout Report:- allows the measured values to be referenced to the values calculated in PipeIQ.

  • Page 23: Commissioning Tests

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS F2d. Commissioning Tests Before performing these tests ensure the area being protected is in its fully operational state – both in terms of airflows and cleanliness. For example, any air handling units (AHUs) should be running, all floor and ceiling tiles should be installed and any equipment producing a heat load should be in its normal operational mode.

  • Page 24: Signalling

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS Signalling All signalling between the ASD system and Fire Alarm Panel/CIE should be verified in accordance with the design. In particular the signalling and response to each Alarm level and Fault conditions should be checked and verified.

  • Page 25: Flow Rate Conversion Table

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS SECTION G: FLOW RATE CONVERSION TABLE This Flow Rate Conversion Table is valid for Pipes of 21mm Internal Diameter (ID) only. for Pipes other than 21mm ID, use the formulae at the end of the Table Inside Diameter (ID) ...

  • Page 26: Glossary

    The Company shall not be obligated to repair or replace units period of three years from date of manufacture. System Sensor makes no which are found to be defective because of damage, unreasonable use, other express warranty for this smoke detector.

  • Page 27: Faast System Validation Form

    FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS Section H : FAAST 7100X System Validation Form: Date Name Contact Information Installer: Commissioning Agent: Client Representative: Witness: Required Documents Commissioning Form for Each System (this document): Yes / No FAAST System Pipe Layout Report...
  • Page 28 FAAST 7100X INSTALLATION AND MAINTENANCE INSTRUCTIONS Section H : FAAST 7100X System Validation Form (continued): Network: Web Access Password: Administrator Password: Device Mail Server Configuration: Sender Account: SMTP Server Name: SMTP Port: Device Connection: DHCP Generated IP Address: Host Name:...
