Page 1: Chilled Water
FOUR-WAY CASSETTE CHILLED WATER IC4H-06KF-3, IC4H-08KF-3, IC4H-12KF-3, IC4H-16KF-3. INSTALLATION MANUAL MAN-I-C4AH-0516 intensity.mx... -
Page 2: Table Of Contents
CONTENTS PAGE Install according to this installation instructions strictly. If installation is defective, it will cause water leakage, electrical shock and fire. PRECAUTIONS..................1 INSTALLATION INFORMATION............... 2 When installing the unit in a small room, take measures against to keep refrigerant concentration from exceeding ATTACHED FITTINGS................3 allowable safety limits in the event of refrigerant leakage. -
Page 3: Installation Information
2. INSTALLATION INFORMATION CAUTION Ground the air conditioner. To install properly, please read this "installation manual" at Do not connect the ground wire to gas or water pipes, first. lightning rod or a telephone ground wire.Incomplete grounding may result in electric shocks. The air conditioner must be installed by qualified persons. -
Page 4: Attached Fittings
3. FITTINGS 3.1 Attached fittings Please check whether the following fittings are of full scope. If there are some spare fittings , please restore them carefully Four-way Cassette NAME SHAPE Four-way Cassette (compact) 3. Installation paper board INSTALLATION FITTINGS 4. Bolt M6 5. -
Page 5: Inspecting And Handling The Unit
4. INSPECTING AND HANDLING THE UNIT 5.3 Install the main body The existing ceiling (to be horizontal) At delivery, the package should be checked and any damage should be reported immediately to the carrier claims agent. Cut a quadrangular hole of 880x880mm or 600x600mm in When handling the unit, take into account the following: the ceiling according to the shape of the installation paper board. - Page 6 installation manual...
- Page 7 FIGURES 2 Installation sketch for slim four-way cassette 60 60 Outlet Inlet Outlet Ground Height of the front panel: Body Central hole H(mm) Type Four-way cassette Fixing hole Slim four-way cassette installation paper board Hook hole Screw M5×16 (Accessory) Installation paper board FIGURES 3 Cover board C Cover board B...
-
Page 8: Connect The Drain Pipe
5.4 Install The Panel 6. CONNECT THE DRAIN PIPE CAUTION 6.1 Install the drain pipe of indoor unit Never put the panel face down on floor or against the 1) The drainpipe can use PVC pipe (external diameter about 37 wall, or on bulgy objects. -
Page 9: Wiring
7. WIRING Gradient: higher than 1/100 CAUTION The air conditioner should use separate power supply with rated voltage. The external power supply to the air conditioner should have ground wiring, which is linked to the ground wiring of the indoor and outdoor unit. The wiring work should be done by qualified persons according to circuit drawing. -
Page 10: Test Operation
Table 7-1 510~2550 AIR FLOW(m PHASE 1-phase POWER FREQUENCY AND VOLT 220-240V~ 60Hz CIRCUIT BREAKER/FUSE(A) 15/15 BELOW 20M Twisted pairwire 2.5mm INDOOR UNIT POWER WIRING(mm BELOW 50M Twisted pairwire 6mm GROUND WIRING(mm The power cord type designation is H05RN-F or above. Wiring figure 8.
