Coral IPx Office Installation Manual
4. If FlexiCom 200 CSLX cabinets are installed, determine the position of
peripheral interface cards that will be inserted into card slots 1 through 3 in the
expansion cages. Observe any order previously directed by a system designer
or any established convention of the distributor. Card placement diagrams
shown on Figure 2-22
system designer to establish card placement prior to installation. Refer to the
Coral FlexiCom 200 Expansion Unit (CSLX) Installation Procedure and
Hardware Reference Manual, Chapter 2 and the Coral Service and Peripheral
Cards Installation Manual.
FlexiCom 200 CSLX cabinets are supported by Coral software version 15.5
and higher.
5. Remove the peripheral interface cards from their shipping containers and
partially insert them into the card slots as determined above. Allow the cards
to protrude from the card cage by approximately 1 inch (2.5 cm).
6. Skip to Interconnecting IPx Office Main and the Expansion Units, page
through Figure 2-24 may be used as a worksheet by the
Hardware Installation Procedure
2-39.
2-29
