Table 6-4 Number of
Universal I/O Slots per
System Configuration
System Configuration
Main
Main + IPx Office EX
Main + IPx Office EX + IPx Office EX
Main + IPx 500X
Main + IPx 500X + IPx 500X
Main + IPx 800X
Main + IPx 500X + IPx 800X
Main + IPx 800X + IPx 800X
Main + F.C. 200 CSLX
Main + F.C. 200 CSLX + F.C. 200 CSLX
Figure 6-23 System with
One Unit (IPx Office)
Coral IPx Office Installation Manual
Main 1 st Expansion
Unit Cage
5 —
4 4
4 4
4 10
4 10
4 11
4 10 (IPx 500X)
4 11
4 2
4 2
5 Office card
I/O slots
Common
control
2 nd Expansion Total System
Cage Universal I/O Slots
—
—
4
—
10
—
11 (IPx 800X
11
—
2
System Description
5
8
12
14
24
15
25
26
6
8
6-27
