System Networking
0

Removing the WiFi Card

...................................................................................................
1. Remove the WiFi antennas.
2. Unplug the power cord that supplies the Coral IPx Office system.
Electrical Hazard. Contact with live wires could cause shock, burn, and death. Turn OFF
the ON/OFF switch and disconnect the power cord before opening the cover.
3. Remove the unit cover. See
The WiFi cable connectors are very delicate and can be easily damaged if excessive
force is applied. Handle with care.
4. Carefully disconnect the WiFi cables from the WiFi card.
5. Open the WiFi card flap.
6. Push the two WiFi card release levers outward; the WiFi card is ejected
Figure
upwards. See
7. Remove the WiFi card.
Opening the Unit Cover, page
11-8.
6-9.
Coral IPx Office Installation Manual
