INVENTOR EPC-09 User Manual page 12

INSTALLATION INSTRUCTIONS (optional)
26.5 ~ 48.0
Window sill
or
26.5 ~ 48.0
or
Foam seal
Foam seal A
(adhesive type)
Fig.8
Window kit
Window kit
Window sill
Fig.9
Window kit
Window sill
Window kit
Window sill
Fig.10
Fig.11
Installation in a double-hung sash window
1. Cut the foam seal (adhesive type) to the proper length
and attach it to the window sill. Fig.8
2. Attach the window slider kit to the window sill.
3. Adjust the length of the window slider kit according to
the width of window, shorten the adjustable window kit
if the width of window is less than 26.5 inches. Open
the window sash and place the window slider kit on the
window sill. See Fig.9.
4. Cut the foam seal (adhesive type) to the proper length
and attach it on the top of the window. Shown as in
Fig.10.
5. Close the window sash securely against the window.
6. Cut the foam seal to the appropriate length and seal
the open gap between the top window sash and outer
window sash. See Fig. 11.
12
