IA1200 Front Panel

11 12 13 14 15
1 2
1.Power: Press this button to power the unit on and off.
2.USB Input: Insert your USB flash drive into this slot. The unit will
the USB flash drive. The maximum storage size of the
sure USB/SD input mode is selected to play the signal from the USB flash drive.
3.SD Card Input: Insert your SD card into this slot.The unit will read .mp3 files from the SD Card.The
maximum storage size of the SD card can not exceed 32GB. Make sure USB/SD input mode is
selected to play the signal from the SD card.
4.MP3 Input: Connect your MP3 player here. Make sure the MP3 input mode is selected to play the signal
from the MP3.
5.MIC1: Microphone Input ¼".
6.MIC2: Microphone Input ¼".
7.Microphone Volume:Use this knob to adjust the volume of the microphones.
8.Microphone ECHO:Use this knob to adjust the microphone's echo.
9.Headphone Output: Connect your headphone here. Make sure the volume level of the unit is turned down
before making the connection.
10.Volume: Use this knob to adjust the master volume output.
11.Play / Pause: When the input selector is in the position of SD/USB, press this button to pause the
signal from the USB flash drive or SD card. Press this button again to play. The play/pause function
will only work for the USB flash drive or SD card. In MP3, AUX or DVD input, press this button to mute
the unit.
12.Previous Track Button: Press this button to go back to the beginning of the current track or to the previous
track on either the USB flash drive or SD card.
13.Next Track Button: Press this button to go to the beginning of the next track on either the USB flash
drive or SD card.
14.Record: When the input is MP3/AUX/ DVD and there is an USB flash drive or SD card (with blank space
on it) inserted into their respective slot, press this button and hold for several seconds to activate the
recording function. After holding the button down for several seconds the unit will create a new file in the
connected USB flash drive or SD card and get ready to record. The word "REC" will appear on the
display screen. At this point there is no actual recording yet. Press this button again and the unit will
start recording. The elapsed time of the recording onto the USB flash drive or SD card will display on
the screen. To pause the recording press this button once again. When paused, the pause symbol on the
screen will be illuminated. Once paused, press this button once again to continue the recording on the
3 4
16 17 18
5 6
automatically
USB flash drive can not exceed 32GB. Make
IA1200
7 8 9 10
read .mp3 files from
