EXPLODED DRAWING—Model No. PFEVEX19010
Key No. Qty.
Description
1
1
Frame
2
1
Front Stabiliser
3
1
Rear Stabiliser
4
2
Rear Endcap
5
1
Seat Post
6
1
Seat Bracket
7
2
Handlebar Endcap
8
2
Foam Grip
9
1
Seat Adjustment Knob
10
5
M8 Nylon Locknut
11
1
M6 x 38mm Screw
12
1
Seat
13
1
Upright
14
1
Upright Bushing
15
1
Handgrip Pulse Sensor/Handlebar
16
1
Console
17
1
Left Side Shield
18
1
Right Side Shield
19
1
Side Shield Cover
20
1
Seat Upright Bushing
21
2
M8 Push Nut
22
1
Reed Switch Clamp
23
2
M4 x 5mm Screw
24
1
Left Pedal
25
1
Left Pedal Strap
26
1
Right Pedal
27
1
Right Pedal Strap
28
2
Adjustment Knob
29
2
M6 x 72mm Button Screw
30
2
Wheel
31
1
Left Front Endcap
32
1
Right Front Endcap
33
1
M6 x 25.4mm Button Screw
34
1
Adjustment Motor
35
1
Lower Wire Harness
36
1
Upper Wire Harness
37
1
Flywheel
38
1
Magnet
39
1
Flywheel Axle
40
2
Flywheel Bearing
Note: "#" indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of this manual for information about ordering replacement parts.
R0202A
Key No. Qty.
Description
41
1
"C" Magnet
42
1
Left Crank Arm
43
1
Reed Switch/Wire
44
2
Crank Bearing
45
2
M5 Nut
46
1
Adjustment Cable
47
1
Return Spring
48
1
Idler Arm
49
1
Idler Wheel w/Bearing
50
3
M10 Black Split Washer
51
3
M10 x 27mm Button Screw
52
7
M4 x 25mm Screw
53
1
Idler Arm Spring
54
1
Pulley
55
1
M10 x 25mm Flat Bolt
56
2
Flange Screw
57
1
Right Crank Arm
58
2
M4 x 7mm Screw
59
1
M8 x 47mm Button Bolt
60
2
M6 Nut
61
2
M8 Nylon Jam Nut
62
1
Flywheel Washer
63
5
M10 Black Nylon Locknut
64
2
Idler Washer
65
4
M10 x 112mm Carriage Bolt
66
11
M4 x 16mm Screw
67
2
Leveling Foot
68
1
Flywheel Spacer
69
1
M8 Flange Nut
70
4
M8 Split Washer
71
2
M4 x 12mm Round Head Screw
72
1
Belt
73
4
Motor Washer
74
1
Crank Axle Snap Ring
#
1
User's Manual
#
1
Allen Wrench
#
1
Audio Cable
#
1
Adapter
#
1
Splitter
22
IMPORTANT PRECAUTIONS
WARNING:
To reduce the risk of serious injury, read the following important precau-
tions before using the exercise cycle.
1. Read all instructions in this manual before
using the exercise cycle.
2. It is the responsibility of the owner to ensure
that all users of the exercise cycle are ade-
quately informed of all precautions. Use the
exercise cycle only as described in this manual.
3. Use the exercise cycle indoors on a level sur-
face. Keep the exercise cycle away from
moisture and dust. Place a mat under the
exercise cycle to protect the floor.
4. Inspect and properly tighten all parts regular-
ly. Replace any worn parts immediately.
5. Keep children under the age of 12 and pets
away from the exercise cycle at all times.
6. Wear appropriate clothing when exercising;
do not wear loose clothing that could become
caught on the exercise cycle. Always wear
athletic shoes for foot protection.
WARNING:
Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
7. The exercise cycle should not be used by
persons weighing more than 114 kg (250 lbs.).
8. Always keep your back straight when using
the exercise cycle; do not arch your back.
9. If you feel pain or dizziness whilst exercising,
stop immediately and cool down.
10. The exercise cycle does not have a freewheel;
the pedals will continue to move until the fly-
wheel stops.
11. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
12. The exercise cycle is intended for home use
only. Do not use the exercise cycle in
a commercial, rental, or institutional setting.
3
