FANATEC CSL Elite Pedals Manual page 18

Adjust the brake stiffness by arranging the different elastomer springs on the back side
brake rod according to your setup and favour.
The brake rod takes five pieces of elastomer springs plus the required soft yellow
spring.
Please refer to table of this Manual for correct setup!
Hardness
Shore
65
Shore
85
Shore
95
IMPORTANT:
than 40% of their length so do not put more load on them than listed in
table! If mixing brake springs with different hardness on the brake rod the
maximum load is defined by the spring with lowest shore value!
Replace the brake limiter pad at the backside of the clutch pedal unit (former
CSL Elite Pedals brake) by clutch limiter pad from CSL Elite Pedals Loadcell
Kit package content.
18
Description Max. load
Medium
hardness
Hard
Very hard
The elastomer springs must not be compressed more
Scenario / setup recommendation
18 kg Pedals on grippy floor or mounted to wheel
stand
40 kg Pedals mounted to wheel stand or to rig /
cockpit
90 kg Pedals mounted to rig / cockpit
