Baxi POWER HT+ 1.50 User Manual
Gas fired floor-standing condensing boiler
Hide thumbs
Also See for POWER HT+ 1.50:
- Installation and service manual (117 pages) ,
- User manual (44 pages) ,
- Installation and service manual (124 pages)
Related Manuals for Baxi POWER HT+ 1.50
Summary of Contents for Baxi POWER HT+ 1.50
- Page 1 AustraliaNew Zealand User Guide Gas fired floor-standing condensing boiler POWER HT+ 1.50 POWER HT+ 1.70 POWER HT+ 1.90 POWER HT+ 1.110...
- Page 2 Dear customer, Thank you for purchasing this appliance. Please read this manual carefully before using the product and keep it in a safe place for future reference. In order to ensure continued safe and efficient operation we recommend that the product is regularly maintained. Our Service and After Sales organization can assist with this.
-
Page 3: Table Of Contents
Contents Contents 1 Safety ................5 1.1 General safety instructions . - Page 4 Contents General ..................32 Troubleshooting .
-
Page 5: Safety
1 Safety 1 Safety 1.1 General safety instructions Danger If you smell gas: 1. Do not use a naked flame, do not smoke, do not operate electrical contacts or switches (doorbell, light, motor, lift, etc.). 2. Shut off the gas supply. 3. - Page 6 1 Safety Caution The appliance should be on Summer or Antifreeze mode rather than switched off to guarantee the follow ing functions: Anti-blocking of pumps Frost Protection Caution If the home is unoccupied for a long period and there is a risk of frost, drain the boiler and the heating sys tem.
-
Page 7: Liabilities
1 Safety Note Regularly check the presence of water and pressure in the heating installation. Caution Maintenance work must be carried out by a qualified professional. Caution Only a qualified professional is authorised to clean the inside of the boiler. Caution Only genuine spare parts may be used. -
Page 8: Manufacturer's Liability
1 Safety Read and follow the instructions given in the manuals pro vided with the appliance. Install the appliance in compliance with prevailing legisla tion and standards. Carry out initial commissioning and any checks necessary. Explain the installation to the user. If maintenance is necessary, warn the user of the obliga... -
Page 9: About This Manual
2 About this manual About this manual General This manual is intended for the end user of a POWER HT + boiler. Symbols used 2.2.1 Symbols used in the manual This manual uses various danger levels to draw attention to special in structions. -
Page 10: Technical Specifications
3 Technical specifications Technical specifications Homologations 3.1.1 Certifications We hereby certify that the series of appliances specified below complies with the standard model described in the CE declaration of conformity. CE number CE-0085CP0089 NOx classification Class 5 Type of flue gas connection –... -
Page 11: Sensor Characteristics
3 Technical specifications POWER HT+ POWER HT+ POWER HT+ POWER HT+ Unit 1.50 1.70 1.90 1.110 Maximum water temperature °C Maximum operating temperature °C Tab.3 Data on the gases and combustion gases For gas flow rates at 15°C and Boiler speed Unit POWER HT POWER HT... -
Page 12: Description Of The Product
4 Description of the product Description of the product General description POWER HT + floor-standing condensing gas boilers have the following characteristics: Low pollutant emissions High efficiency heating Electronic control panel Flue gas discharge by a forced flue, chimney or bi-flow type connection. Perfectly suitable for cascade systems with several boilers. -
Page 13: System In Cascade
4 Description of the product Fig.2 Boiler equipped with the low-loss Fig.3 Functional diagram of a boiler with a low-loss header header kit MW-3000144-01 MW-1000021-02 1 Low-loss header (accessory) 6 Heating circuit flow 2 Air vent 7 Heating circuit return 3 Safety valve 8 Boiler 4 Modulating circulation pump... -
Page 14: Settings And Safety Devices
4 Description of the product Fig.4 Boilers in cascade Note Please contact us for further information. 4.2.4 Settings and safety devices Note The settings and safety devices are only operational if the boiler is powered up. Tab.7 Description of the safety devices Device Description Safety thermostats... -
Page 15: Main Components
4 Description of the product Main components Fig.5 POWER HT+ 1.50 and POWER HT+ 1.70 MW-3000116-01 1 Control panel 16 Igniter 2 Flue gas measuring point 17 Spark plug 3 Flue gas connection 18 Ionisation probe 4 Power supply terminal block 19 Flame inspection window 5 Terminal block for the sensors and the remote con... -
Page 16: Control Panel Description
4 Description of the product 12 Safety thermostat against overheating 22 Emplacement for two AVS 75 boards maximum. A 13 Condensate siphon third AVS 75 board can be used by the boiler but 14 Drain valve must be fixed to the wall and powered externally. 15 Hydraulic pressure sensor 23 Emplacement for OCI 345 board 16 Igniter... -
Page 17: Operation
5 Operation Operation Use of the control panel 5.1.1 Modifying the user parameters Fig.9 1. Press the key to access the parameters. MENU Note Press the key to return to the main display. MENU The user parameters can now be accessed. Use the button to se... -
Page 18: Activating Protection Mode
5 Operation 5.4.1 Activating Protection mode 1. Press the key to access the shortcuts menu. Fig.11 2. Select the Central heating mode CH1 parameter by turning the button. 3. Confirm the selection by pressing the button. 4. Select the Off parameter by turning the button. -
Page 19: Settings
6 Settings Settings List of parameters 6.1.1 Shortcuts menu Tab.8 Functions accessible with the shortcut key Parameter Description Adjustment range Standby/operation Boiler standby / start-up Standby: Boiler put on standby. symbol is displayed. The boiler's operating modes are deactivated. The frost protection function is activated. On: Starting up the boiler 316:Hot water boost Forcing domestic hot water pro... -
Page 20: List Of User Parameters
6 Settings Information Description Value Minimum outside temperature value memorised °C Outside temp min Note The outside sensor must be connected. Maximum outside temperature value memorised °C Outside temp max Note The outside sensor must be connected. Hot water temp 1 Domestic hot water temperature °C Note... - Page 21 6 Settings Parameter number Parameter Description Heating circuit Heating circuit 2 Heating circuit 3 3rd Time ON Start of hourly period 3. 3rd Time OFF End of hourly period 3. Default values Reset the hourly program parameters to zero (Yes / No).
-
Page 22: Setting The Parameters
6 Settings Tab.15 Menu Temps / mode CH1 – Temps / mode CH2 – Temps / mode CH3 Parameter number Parameter Description Factory setting Heating Heating Heating cir circuit 1 circuit 2 cuit 3 1000 1300 The control unit is installed on the boiler: Off: heating is deactivated. -
Page 23: Language Selection
6 Settings Fig.14 3. Confirm the menu selection by pressing the button. The parameter Hours / minutes is displayed. Information Set time and date Operator section MENU MW-3000054-EN-02 Fig.15 4. Confirm the parameter selection by pressing the button. The parameter flashes, it can be modified. 5. -
Page 24: Setting A Temporary Heating Flow Temperature
6 Settings Fig.18 4. Confirm the menu selection by pressing the button. The language currently used flashes. 5. Modify the parameter by turning the button 6. Confirm the setting by pressing the button. Note Press the key to return to the main display. MENU Operator section Change language... -
Page 25: Forcing Domestic Hot Water Production
6 Settings Fig.21 4. Select the appropriate operating mode. Shortcuts menu, page 19 5. Press the button to confirm. Central heating mode CH1 Note Setting NOT confirmed Press the key to return to the main display. Timed MENU MENU MW-3000060-EN-02 6.2.5 Forcing domestic hot water production 1. -
Page 26: Modifying The Domestic Hot Water Production Mode
6 Settings Fig.24 4. Turn the button to modify the temperature set point. Shortcuts menu, page 19 5. Press the button to confirm. Room temperature CH1 Note Press the key to return to the main display. MENU MENU MW-3000063-EN-02 6.2.7 Modifying the domestic hot water production mode 1. -
Page 27: Setting The Room Temperature Set Point (Reduced Mode)
6 Settings Fig.27 4. Turn the button to modify the temperature set point. Shortcuts menu, page 19 5. Press the button to confirm. Note Press the key to return to the main display. Hot water temp setpoint MENU MENU MW-3000067-EN-02 6.2.9 Setting the room temperature set point (Reduced mode) 1. -
Page 28: Programming A Holiday Period
6 Settings 6.2.10 Programming a Holiday period This series of functions is used to program the boiler's behaviour in holiday periods or during prolonged absences. The various parameters are used to program one of eight Holiday periods. When the function is activated, the symbol is displayed. - Page 29 6 Settings Fig.31 5. Confirm by pressing the button. Holiday heating CH1 Preselection Period 1 MENU MW-3000074-EN-02 Fig.32 6. Select the Start parameter by turning the button. 7. Confirm the menu selection by pressing the button. Holiday heating CH1 Period 1: Start Day / month - - / - - MENU...
-
Page 30: Selecting A Heating Circuit
6 Settings Fig.35 11. Select and confirm the end date of the holiday period with the button. 12. Confirm the menu selection by pressing the button. Holiday heating CH1 Period 1: End Day / month - - / - - MENU MW-3000078-EN-02 Fig.36... - Page 31 6 Settings Fig.38 2. Select the Information menu with the rotary button. 3. Confirm by pressing the rotary button ---------------------------------------------------- Information Set time and date MENU MW-3000098-EN-02 Fig.39 4. Use the rotary button to scroll through the various items of infor mation.
-
Page 32: Maintenance
7 Maintenance Maintenance General We recommend having the boiler inspected and serviced at regular inter vals. Boiler maintenance and cleaning must be carried out at least once a year by a qualified professional. Have an inspection carried out and the flues swept at least once a year or more, depending on the regulations in force in your country. -
Page 33: Troubleshooting
8 Troubleshooting Troubleshooting Error codes Fig.40 Error code A Error code B Secondary error code C Description of the error Note Press the key to return to the main display. MENU symbol continues to be displayed on the control panel. After one minute, if the error is not resolved, the error code is 1 18 displayed on the control panel a second time. -
Page 34: Automatic Error Code Clearing
8 Troubleshooting Display Description of the error 430:Dyn water pres too low Safety cut-off for absence of circulation (check made by a pressure sensor) Note Contact the installer: If an error code different from the ones described is displayed on the screen If an error code is displayed on a regular basis Note If the error code simultaneously displays the... -
Page 35: Environmental
9 Environmental Environmental Energy savings Tips on saving energy: Keep the room in which the boiler is installed well ventilated. Do not block ventilation outlets. Do not cover the radiators. Do not hang curtains in front of the radiators. Install reflective panels behind the radiators to prevent heat losses. Insulate the pipes in rooms that are not heated (cellars and lofts). -
Page 36: Disposal
10 Disposal 10 Disposal 10.1 Disposal/recycling Warning Removal and disposal of the boiler must be carried out by a quali fied installer in accordance with local and national regulations POWER HT + 7609475 - v02 - 04092014... -
Page 37: Warranty
11 Warranty 11 Warranty 11.1 General We would like to thank you for buying one of our appliances and for your trust in our product. In order to ensure continued safe and efficient operation we recommend that the product is regularly inspected and maintained. Your installer and our service department can assist with this. - Page 38 11 Warranty POWER HT + 7609475 - v02 - 04092014...
- Page 39 © Copyright All technical and technological information contained in these technical instructions, as well as any drawings and technical de scriptions supplied, remain our property and shall not be multiplied without our prior consent in writing. Subject to alterations.
