Tylo Elite Installation Manual And Quick Start Manual page 12

EN
Overview
The overview screen is shown both when the heater is switched off (Figure 7) and when it is on
Fig. 7
Home
Get to the Home screen (fig. 9) by touching the screen in the Overview mode or by pressing the
Home button. The Activity buttons are used to start and stop the heater. A Standby button is also
shown. When one of the activity buttons is pressed, the colour changes to indicate the current status.
Fig. 9
Fig. 8
Activity/Status buttons
On
Standby:
Off
Functions/Settings buttons
12
Air humidity setting
Temperature setting
Current temperature
Current relative air humidity
(only shown if the temperature/
humidity sensor is connected
on the Combi and Tylarium
models)
Current time
Remaining sauna
time
Water level in the tank (applies
to the Combi model)
Shows that the panel is
connected to Wifi (only the
Elite Wifi model)
