2010
SPECIFICATIONS
WING SPAN: 1800 mm(70.86 in)
2
2
WING AREA: 33.5 dm (519 in )
LENGTH: 928 mm(36.5 in)
WEIGHT: 1100g(38.8 oz)
RADIO: 4 Ch
Warning
An RC aircraft is not a toy! If misused, it can cause serious bodily
harm and damage to property. Fly only in open areas, following all
instructions included with your radio.
Before beginning the assembly, remove each part from its bag for
inspection. Closely inspect the fuselage, wing panels, rudder and
stabilizer for damage. If you find any damaged or missing parts,
contact the place of purchase.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Super Flying Model Fournier RF-4D
Summary of Contents for Super Flying Model Fournier RF-4D
- Page 1 SPECIFICATIONS WING SPAN: 1800 mm(70.86 in) WING AREA: 33.5 dm (519 in ) LENGTH: 928 mm(36.5 in) WEIGHT: 1100g(38.8 oz) RADIO: 4 Ch Warning An RC aircraft is not a toy! If misused, it can cause serious bodily harm and damage to property. Fly only in open areas, following all instructions included with your radio.
- Page 2 the pre-drilled holes on the rib. Cut off the cotton line when the extension is out of the hole. Place the M2 plastic nut, pushrod connector and M3 hex screw on the working table. Drill 2mm hole on the servo arm. Slide the pushrod Connect the extensions with Y-harness.
- Page 3 securing the plate. Remove the plate and gear. Use 2mm drill to open the holes. Use 2 pieces of 2x13mm screws to Use hobby knife to remove the Insert the dowel. Make sure the dowel secure the control horn in place. covering on the pre-serving slot for the on both sides are the same length and landing gear.
- Page 4 Using hobby knife, carefully cut the Secure the stabilizer back temporary. Assemble the tail gear with wheel and Secure the vertical on the horizontal covering inside the marking lines. plastic collar. Secure the collar with use epoxy. The vertical must be Please do not press hard enough to M3x6 screw.
- Page 5 Apply the supplied transparent tape on Drill 2mm holes on the bottom of Apply the hook and loop on the battery Slide the rod into one piece of the junction where the horizontal elevator for securing the control horn. tray. supplied silicone tube, thread the meets the fuselage.
- Page 6 Place two 17g servos on the working Try to fit the cowling on the nose. Use hobby knife to cut the plastic Pull the pushrod tube straight and table. Assemble the rod connectors When satisfy the position, use 4 engine moulding separately. apply some instant glue to secure the on the servo arms.
- Page 7 Try to fit the canopy on the fuselage. When satisfy the location, apply the supplied transparent tape to secure the canopy in place. Center of Gravity The recommended Center of Gravity location is 70mm back from the leading edge against the fuselage.
