Page 1
More beautiful, more user-friendly, more speedy JV33 Series Product guide for distributors Ink jet printer responded to the professional needs Ver.1.01 Aug. 2007 Mimaki Engineering Co., Ltd. D10027-02H...
Page 2
Contents Concept JV33 Series feature P4-22 Ink cartridges alignment System configuration Raster Link Pro III new functions P25 JV33 option supply pricing D10027-02H...
Page 3
Concept Advanced level of high speed and high quality than JV3 Series Affordable price Succession of JV3 functions. Upgrading of operability D10027-02H...
Page 4
Feature Print speed 30% faster than JV3 SP II Series Newly developed SS21 ink High quality print by Variable Dot Low running cost Realization of Automatic print operation Upgrading of operability Two ink types tailored to use application and environment White ink (Solvent base) becomes available.
Page 5
Print speed upgrading by 30 % of JV3 SP Series (1) Comparison of Print speed between JV33 and JV3 (4C mode) JV33 JV33- - - - 160 4C JV33 JV33 160 4C 160 4C 160 4C 17.5㎡/H 540x720VD 4pass Bi 540x720VD 4pass Bi 540x720VD 4pass Bi 540x720VD 4pass Bi- - - - direction...
Page 6
Print speed upgrading by 30 % of JV3 SP Series (2) Comparison of Print speed between JV33 and JV3 (6C mode) JV33 JV33- - - - 160 6C 160 6C JV33 JV33 160 6C 160 6C 9.0㎡/H 540x720VD 4pass Bi 540x720VD 4pass Bi- - - - direction direction 540x720VD 4pass Bi...
Page 7
Print speed upgrading by 30 % than JV3 SP Series (3) High speed head equipped ・Compared with JV3 SPII series print head, the upgrading of ink discharge frequency about 30 % faster enabled high speed print. ・Redesign of ink color arrangement enabled high speed and high quality print.
Page 8
Print speed upgrading by 30 % of JV3 SP Series Enhancement of drying by 3 way intelligent heater Post-heater enhances the quick-dry of ink to help winding media by high speed print. Pre-heater and print-heater reduce ink bleeding and enable high quality print.
Page 9
Newly developed SS21 ink (1) SS21 ink It is less bleeding and possible to print with high color density and also by high quality even by high speed mode. It is composed of the same component which allows to use the same media that is printed by SS2 ink.
Page 10
Newly developed SS21 ink (2) ・Wide color gamut SS21 SS21 SS21 SS21 Japan Color 2000 Japan Color 2000 Japan Color 2000 Japan Color 2000 The density of Cyan color of SS21 ink was upgraded and it got better Y Y Y Y color balance than SS2.
Page 11
High quality print by Variable Dot Variable dot( ( ( ( VD) With maximum pringing mode of 1440 dpi and thanks to printing in different 3 dot sizes of large, medium and small dots, JV33 allows us to print with high quality various images from highlight to shadow even in 4 color mode.
Page 12
Automatic print operation (1) JV33 equipped UISS function, successfully-used by JV5 series as well. Automatic change of double ink cartridges provides consistent print and avoids running-out of ink. When one of the two ink cartridges is terminated, thanks to valve function, the ink supply will be switched to the another cartridge automatically.
Page 13
Automatic print operation (2) Automatic take-up device Automatic take-up device based tension system enables a stable consecutive print without any broad space preparation. Easy in handling of media attachment, it is only to set a core of media to the device and fix the media and the core by an adhesive tape. D10027-02H...
Page 14
Automatic print operation (3) Media plate Thanks to a media plate, it prevents media from uplifting and jamming. It realized a stable print without failure. Media plate D10027-02H...
Upgrading of operability (1) Roll holder It is easy to set a media to the device, thanks to our roll folder, compatible with 2 inch and 3 inch core. Roll stopper helps to set a media easily without any skew. Roll holder Roll (compatible...
Page 16
Upgrading of operability (2) Easy operation of ink change - Front positioning of ink cartridges set enabled an easy operation of ink change. - As the running-out of ink is indicated by lamp, ink change is operated easily. And it is also possible to change a cartridge while printing.
Page 17
Upgrading of operability (3) Easy maintenance Thanks to a new cleaning system, the maintenance time is shorten and the amount of waste ink is also reduced. The cleaning liquid for maintenance locating at the dorsal side is supplied automatically to the capping station.
Page 18
Two ink types tailored to use application and environment Solvent ink ・ ・ ・ ・ SS21 ink( ( ( ( Newly developed) ) ) ) Excellent on drying property and less bleeding. Even for high speed print, it is appropriated to print on backlit, tarpaulin, flexible face etc, like the media which requires high ink density.
Page 19
White ink application (1) ( ( ( ( Planned to apply in Sep.07) SS21 White ink ・ ・ ・ ・ White ink over lay print It is appropriated to lots of applications like window display etc. # 6colors + white ink mode Combination order Combination order 6color print...
Page 20
White ink application (2) White ink overlay print ・Splitting the print head into the front and the rear and by printing by overlay of white area and color area, no mackle of color and white is occurred. This enables a long sized print. # 6colors + white ink mode :...
Page 21
Aqueous type ink is also possible. (1) ( ( ( ( Planned to apply in Oct.07) It is a versatile ink with two types of aqueous ink. Aqueous pigment ink and Sublimation ink The operation of JV33 Series is quite similar with our solvent ink models.
Page 22
Aqueous type ink is also possible. (2) Aqueous type ink 1. Aqueous pigment ink For indoor poster, wall paper、POP、Backlit etc. 2. Transfer sublimation ink It is for a print on fabric in polyester thru transferring. For flag, banner, tapestry etc. D10027-02H...
Ink cartridge alignment It is selectable between 4 color mode of high speed - high productivity and 6 color mode suitable to high quality. Moreover it is also possible to select 6 color and white ink mode for your wider range of job. Ink cartridge alignment 4C ink mode M C Y K K Y C M...
Page 24
Raster Link Pro III new functions is bundled. 16bit rendering ( ( ( ( Newly developed) ) ) ) 16 bit rendering of Raster Link ProⅢ realized to replicate an image with beautiful gradation free from color tone jump. Conventional 8 bit rendering Newly developed 16 bit rendering D10027-02H...
