Summary of Contents for BK Precision 1696
- Page 10 RECALL RECALL...
- Page 35 714-921-9095 714-921-6422...
-
Page 36: Command Sets
Command Sets BK models 1696/1697/1698 August 2004 BLUE – Input Command RED – Return Data from Power Supply PS = Power Supply Command Code Description SESS <address> <CR> Disable front panel keypad and make PS to [OK] [CR] Remote M ode ENDS <address>... - Page 37 GETM <address> <CR> Get All Preset M emory Values from PS M emory 1 Voltage [???] Current [???] [CR] M emory 2 Voltage [???] Current [???] [CR] M emory 9 Voltage [???] Current [???] [CR] [OK] [CR] GETM <address> location {1-9} <CR> Get M emory from Specific Preset of PS Voltage [???] Current [???] [CR]...
- Page 38 CURR <address> current {001-XXX} <CR> Set Current Level [OK] [CR] SOVP <address> voltage {010-XXX} <CR> Set Upper Voltage Limit of PS [OK] [CR] SOUT <address> 0 <CR> Disable Output of PS [OK] [CR] SOUT <address> 1 <CR> Enable Output of PS [OK] [CR] PROM <address>...
- Page 39 NOTES: { }- command data, [ ] - return data, [OK] = "OK", [CR] = 0dh ???? = 30h, 30h, 30h, 30h - 39h, 39h, 39h, 39h (4 bytes data) ??? = 30h, 30h, 30h - 39h, 39h, 39h (3 bytes data) ?? = 30h, 30h –...
