- Page 1 INSTRUCTION MANUAL Model 1665/ 1666/ 1667 BENCH SWITCHING DC POWER SUPPLIES 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS AND PRECAUTIONS ............. 3 INTRODUCTION ......................4 SPECIFICATIONS ......................5 CONTROLS AND INDICATORS ................6 OPERATION PROCEDURES ..................9 Limited Warranty ........................10 Service Information ......................11... -
Page 3: Safety Instructions And Precautions
1. SAFETY INSTRUCTIONS Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Do not install unit near any heat source or heating emitting devices. Prevent the power cord from being walked on or pinched. Unplug this unit during lighting storms or when unused for long periods of time. -
Page 4: Introduction
Current limiting control with automatic crossover of constant voltage (CV) and constant current (CC) indicators make this series ideal for research and development work in laboratories. Model 1665 only: V meter max. display Above 19.99 output voltage, V meter display... -
Page 5: Specifications
3. SPECIFICATIONS Specifications 1665 1667 1667 Output Voltage: I-19VDC 1-40VDC 1-60VDC Output Voltage Control: Fine & Coarse Fine & Coarse Fine & Coarse Output Current: 0-10A 0-5A 0-3.3A Ripple & Noise (P-P): 20mV 20mV 20mV Load Regulation: 0.5% + 200mV 0.5%+200mV... -
Page 6: Controls And Indicators
4. CONTROLS AND INDICATORS FRONT PANEL... - Page 7 4. CONTROLS AND INDICATORS REAR PANEL...
-
Page 8: Front Panel
Front Panel Power Switch -- Turns the power supply ON/OFF. DC Voltmeter (LED Display)* -- Indicated the present output voltage with auto range. DC Ammeter (LED display) -- Indicates the present output current with auto range. Constant Current Mode (C.C.) -- Indicator Indicates the power supply is operating in constant current mode. Constant Voltage Mode (C.V.) -- Indicator Indicates the power supply is operating in voltage mode. -
Page 9: Operation Procedures
5. OPERATING PROCDURES Output Voltage Control - It is a dual control consisting of a coarse and fine potentiometer. The final DC voltage output is the sum of both adjustments. Current Limiter Control - It is a dual control (coarse/fine) that changes the DC current over the rated current range. Ground Connections - For operating with negative or positive output terminal, grounded or without grounding. -
Page 10: Limited Warranty
Limited One-Year Warranty B&K Precision Corp. warrants to the original purchaser that its products and the component parts thereof, will be free from defects in workmanship and materials for a period of one year from date of purchase. B&K Precision Corp. will, without charge, repair or replace, at its option, defective product or component parts. Returned product must be accompanied by proof of the purchase date in the form of a sales receipt. -
Page 11: Service Information
Service Information Warranty Service: Please return the product in the original packaging with proof of purchase to the address below. Clearly state in writing the performance problem and return any leads, probes, connectors and accessories that you are using with the device. Non-Warranty Service: Return the product in the original packaging to the address below.
