SET BUTTON
The SET button is used to manually step through the 5 stored output values.
1. Select the SOURCE mode
2. Press the SET button and the value stored in memory location 01 will be sourced. "MEM.01"
appears in the display.
3. Each press of the SET button will step through the 5 memory locations.
4. The arrow buttons can be used to adjust the value in each memory location.
STEP/MEM BUTTON
The STEP/MEM button is used to automatically step through the 5 stored output values. The meter
can be set for a single cycle of the stored values or a continuous cycle.
1. Select the SOURCE mode
2. Press and HOLD the STEP/MEM button. "STEPSS" (single cycle) and "STEPSC"
(continuous cycle) will alternately appear in the display. Release the button when the
desired mode is displayed.
3. In single cycle mode the meter will source the current displayed in MEM01 for 5 seconds.
The meter will then advance to MEM02 for 5 seconds. This will continue through MEM05
and then step down through the memory locations. The cycle will end when MEM01 has
been reached.
4. In the continuous mode the cycle will continue until manually stopped.
5. Momentarily press the STEP/MEM button to stop the cycle. "END" will briefly appear in the
display.
STORING VALUES INTO MEMORY
The default values stored in the memory locations are:
To change the values in memory:
1. Select the SOURCE mode
2. Press the SET button to select the memory location to be changed.
3. Press the arrow buttons to adjust to the new value
4. Momentarily press the MEM button to store the value. The memory location icon will blink
while the value is being stored.
actoolsupply.com
Memory
mA
Location
4.00mA
M1
8.00mA
M2
12.00mA
M3
16.00mA
M4
20.00mA
M5
actoolsupply.com
%
0.0%
25%
50%
75%
100%
5 PRC10-EU-EN-V1.2 01.13
