GE 800
Packet.dll.
Note: WinPcap does not work with all ethernet adapters. A list of compatible adapters can be
found at http://www.winpcap.org/misc/faq.htm#Q-16. Particulary WLAN adapters may cause incom-
patibilities.
Installation IPStationConfig
As code for the installation the standard CCT product key is used.

The Program Interface

In the combo-box in the status bar at the bottom of the window, the desired network card can be
selected.
A failure in the network connection (e.g. wrong network card selected) is indicated with a blinking
blue box in the status bar.

Configuration Table

In the table the configuration of the IP-subscribers is shown.
If changes are made at an IP-subscriber (except in the columns "CallNo" and "Description") the respec-
tive columns and the column "Color" are highlighted in red color.
Grouping / filtering / sorting of entries
The entries in the table can be sorted to provide a better overview. Simply drag-and-drop the desired
column header to the blue area which is labelled "Drag a column header here...":
Remove grouping: Click in the blue area with the right mouse button and select "Clear Grouping" .
With the fields above the columns it is additionally possible to sort depending on text. Only entries
are indicated that begin with the text/number that has been entered.
Click on the column header to alphabetically sort the entries. Repeated clicking reverses the sorting
direction.
The column order in the table can be changed as desired. Simply drag-and-drop the column header
to the desired position in the table.
1.1/1209
7. Configuration of IP-Terminals
37
