4. Cabling

4. Cabling

1. Connection Intercom Server

2. Connection Intercom Terminals
3. Connection Inputs /Outputs
4. Connection of multiple Intercom Servers
Connection Intercom Server
Installation Board G8A-GEN
Music /
alarm
input
Floating
contacts
S1W
S1
S2W
S2
e.g.:
Door opener
Power supply
Installation Board G8A-NET
UPLINK Ethernet (configuration)
DOWNLINK
Connection to network cards (G8-CNET-W, G8-CNET-E1)
OUT (GEV)
or GE 700 (G7-GEV)
IN (GEV)
10
G8A-GEN
MU1
1
MU2
IN1
2
3
IN2
4
5
S1
S2
S1W
S1
Programming socket
S2W
(parallel to G8-GEN)
S2
+30V
DC
Power supply GE 800
or
24V AC
AC
24V AC
Grounding
1....GND
(Shield)
6
2....TXD
7
3....RXD
4....NC
8
5....GND
9
6....NC
7....NC
8....NC
9....NC
Grounding point
for wrist strap
grounding
GE 800
1.1/1209
