Wing Span:69in/1754mm
Wing area:58.2sq.dm
Length:61in/1550mm
Engine:2c 90-120; 4c 120; SPE 26CC gas engine
CAUTION : this plane is not a toy and should be kept away
children under 16 years of age! Before use , please carefully read
this manual.
●First-time builders should seek advice from people having building
experience in order to assemble the model correctly and to produce its
performance to full extent .
●Assemble this kit only in places out of children's reach!
●Take enough safety percautions prior to operating this model.
You are responsible for this model's assembly and safe operation!
●Always keep this instruction manual ready at hand for quick
reference,even after completing the assembly.
Flying Weight:3800-3900g
Radio:4channels 5servos
P1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Extra-260 28CC and is the answer not in the manual?

Questions and answers

Summary of Contents for Turnigy Extra-260 28CC

  • Page 1 Wing Span:69in/1754mm Flying Weight:3800-3900g Wing area:58.2sq.dm Radio:4channels 5servos Length:61in/1550mm Engine:2c 90-120; 4c 120; SPE 26CC gas engine CAUTION : this plane is not a toy and should be kept away children under 16 years of age! Before use , please carefully read this manual.
  • Page 2 MAIN WING Gather the wings, aluminium joiner and other parts together. Insert the hinge into the Glue wing slot and secure it with glue. Cut away covering film for the servo.
  • Page 3 Put the servo into the hole and pull out the servo extension from main wing. Find out the holes in each sides of fuselage, then cut the film.
  • Page 4: Main Landing Gear

    Connect the main wings and the fuselage with joiner. Also pull the extension into the fuselage. Plastic Fixup the wings with plastic bolt bolts on both sides. MAIN LANDING GEAR Gather the wheels,axles and collars as shown.
  • Page 5: Tail Wheel Installation

    Carbon Fiber Landing gear Wheel Pants Permanently tighten the axle to the gear strut by wrenches. Install wheel pants with two mounting bolts. TAIL WHEEL INSTALLATION Find and cut the hole for stabilizer and also the servo holes.
  • Page 6 Cut away the film along the edges, and glow the stabilizer to the fuselage. Cut the rudder film along the edges, and glue the rudder to the fuselage. Securely glue up and soaked up the hinge with instant glue.
  • Page 7 Bend the tail landing gear to fit for the rudder and insert it into the rudder. Glue the rudder to the fuselage. Glow the tail landing gear to the rudder securely.
  • Page 8 Install the tail wheel, and fasten the presser of the tail wheel to the stabilizer by screws. ELEVATOR AND RUDDER Insert elevator to the tailplane with U shape wire. Connect the control horn to the linkage of the servo.
  • Page 9 Tighten the second loop through the brass swage tube. Crimp the brass tube with a crimping tool or pliers. Push rods Rudder servo arm...
  • Page 10 Install rudder pushrod. Another method for the rudder servo installation Install the ball linkege connector.Calculate the length proportion between the servo arm and the horn.Rotate the ball linkage connector to an appropriate position. Place the hatch. Use two screws to secure it firmly.
  • Page 11 ENGINE Gather the MLD engine and spare parts as shown. The finished picture as shown. Pay attention to:you have DLE and MLD for choice. Install the DLE 30CC as shown.
  • Page 13 Place the hatch. Use two screws to secure it firmly. COWLING Mounting the cowling by wood screws. FUEL TANK...
  • Page 14 60-80mm 60-80mm 65-90mm 65-90mm 40-61mm 40-61mm...
  • Page 15 THE FINISHED PHOTO Flight Model MFG CO...
