Quick Installation Guide
00825-0100-4811, Rev GA
October 2011
Guided Wave Radar Level and Interface
Transmitter
www.rosemount.com
Step 1: Mount the Transmitter Head/Probe
Step 2: Set Jumpers and Switches
Step 3: Connect the Wiring
Step 4: Configure
Environmental Conditions
Product Certifications
Start
Check Process Connections
Confirm Configuration
End
Rosemount 3300 Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3300 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Rosemount 3300 Series

Summary of Contents for Rosemount 3300 Series

  • Page 1 Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 Guided Wave Radar Level and Interface Transmitter Start Step 1: Mount the Transmitter Head/Probe Step 2: Set Jumpers and Switches Step 3: Connect the Wiring Step 4: Configure Environmental Conditions...

  • Page 2: Important Notice

    Enquiries@AP.EmersonProcess.com IMPORTANT NOTICE  This installation guide provides basic guidelines for the Rosemount 3300 Series. Refer to Rosemount 3300 Series Reference Manual (Document No. 00809-0100-4811) for more instructions. The manual and this Quick Installation Guide (QIG) are also available electronically on www.rosemount.com....
  • Page 3 • Avoid contact with the leads and terminals. High voltage that may be present on leads can cause electrical shock. • Make sure the main power to the Rosemount 3300 Series transmitter is off and the lines to any other external power source are disconnected or not powered while wiring the transmitter.
  • Page 4 Alloy 400 (UNS N04400) Duplex process connection The Material of Construction Code in the above table can be found in the following position in the Rosemount 3300 Series model code: 330xxxxxN... Category 2G or 2D Category 2G or 2D Category 1G or 1D...
  • Page 5 Clamp 5. Rotate the transmitter housing so the cable Gasket entries/display face the desired direction. Tank 6. Tighten the nut. Refer to Rosemount 3300 Series Reference Manual (Document No. 00809-0100-4811) for details regarding the mounting of transmitter head/probe.
  • Page 6 3. Fasten the bracket to the pipe using the four supplied nuts. Probe 4. Mount the transmitter with probe to the bracket and secure with the three supplied screws. See the Rosemount 3300 Series Reference Manual Vertical mounting (Document No. 00809-0100-4811) for more installation details. Transmitter...
  • Page 7 Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 CONTINUED Remote Housing 1. Remove the transmitter head from the probe by unscrewing the M50 nut. M50 nut 2. Mount the probe in the tank by following the previous instructions in this section.

  • Page 8: Set Jumpers And Switches

    Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 2: S UMPERS AND WITCHES If alarm and security jumpers are not set, the transmitter operates with the default alarm condition HIGH and Security OFF.   Write Protection must be set after configuration (Step 4).

  • Page 9: Step 3: Connect The Wiring

    Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 3: C ONNECT THE IRING For HART, the input voltage is 11-42 V (11-30 V in IS applications, 16-42 V in Explosion-proof / Flameproof applications). For Modbus, the input voltage is 8-30 V.
  • Page 10 Power Supply HART: U =42.4 V HART Modem Field Communicator NOTE Rosemount 3300 Series Transmitters with Flameproof/Explosion-proof HART Output have a built-in barrier; no external barrier needed. Intrinsically Safe HART Output Rosemount 3300 Approved Series Transmitter IS Barrier Power ...
  • Page 11 NOTE Rosemount 3300 Series Transmitters with Flameproof/Explosion-proof Modbus Output have a built-in barrier; no external barrier needed. The Field Communicator requires a minimum load resistance of 250  within the loop in order to function properly, see below.

  • Page 12: Load Limitations

    Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 Load Limitations Non-Hazardous Installations,  Explosion-proof/Flameproof (Ex d and Td) and Type n Approvals: Non-Sparking / Energy Installations Limited Power Supply Operating region Operating region Intrinsically Safe Installations NOTE...
  • Page 13  Configuration of the Rosemount 3300 Series transmitter can be done either with a Field Communicator, Asset Management Solutions (AMS), or Radar Configuration Tools (RCT). If using the Radar Configuration Tools, a HART modem is required, and the procedure is described below, together with the corresponding Field Communicator Fast Key sequence.

  • Page 14: Setup Basics

    October 2011 CONTINUED Configuration of a Rosemount 3300 Series transmitter can be done using the installation Wizard for detailed guidance. If you are already familiar with the configuration procedure, or if you want to change settings, you may use the setup function.
  • Page 15 Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 Setup - Output Set Range Values, Field Communicator Fast Key sequence [1,3,4,3] The Lower Range value = 4 mA value. The Upper Range value = 20 mA value. The 4-20 mA range must not include the upper or lower Transition Zone.
  • Page 16 Additional Configuration to Fine-Tune Performance To fine-tune the transmitter’s performance, it is recommended the Trim Near Zone function be executed after configuration is finished. For detailed information on how to trim the near zone, see the Rosemount 3300 Series Reference Manual (Document No. 00809-0100-4811).

  • Page 17: Environmental Conditions

    National deviations may apply, see “Product Certifications”. Process Temperature Restrictions When the Rosemount 3300 is installed in high temperature applications, it is important that the maximum ambient temperature is considered. Tank insulation should not exceed 4 in. (10 cm). The diagram below shows the maximum ambient temperature vs. process temperature: Ambient Temperature °F (°C)

  • Page 18: Product Certifications

    Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 Product Certifications EU Conformity The EC declaration of conformity can be found on page 28. The most recent revision can be found at www.rosemount.com. SAFETY NOTE: A safety isolator, such as a zener barrier is always needed for intrinsic safety....
  • Page 19 E1 Flameproof: SPECIAL CONDITIONS FOR SAFE USE (X): On application of the Rosemount 3300 Series Guided Wave Radar Level and Interface Transmitters equipped with plastic materials in an explosive gas atmosphere, precaution shall be taken to avoid danger of ignition due to electrostatic charges on the enclosure....
  • Page 20 Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 Maximum Temperature (For Explosion-Proof/Flameproof version) As defined in EN 60079-0 Clause 5.2. Maximum Temperature Maximum Temperature (Process Seal) (Terminal Housing bottom) +275 °F (+135 °C) or +185 °F (+85 °C)
  • Page 21 Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 I1 Intrinsic Safety: SPECIAL CONDITIONS FOR SAFE USE (X): The apparatus is not capable of withstanding the 500 V test as defined in clause 6.3.12 of EN 60079-11:2007. This must be considered in any installation....
  • Page 22 Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 N1 Type n Approvals: Non-Sparking / Energy Limited Power Supply SPECIAL CONDITIONS FOR SAFE USE (X): The external supply must be provided with transient and over voltage protection. ...
  • Page 23 E2 Explosion-proof: SPECIAL CONDITIONS FOR SAFE USE (X): On application of the Rosemount 3300 Series Guided Wave Radar Level and Interface Transmitters equipped with plastic materials in an explosive gas atmosphere, precaution shall be taken to avoid danger of ignition due to electrostatic charges on the enclosure....
  • Page 24 Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 National Supervision and Inspection Center for Explosion Protection and  Safety of Instrumentation (NEPSI) Approvals SPECIAL CONDITIONS FOR SAFE USE (X): See certificate for details. E3 Flameproof: GYJ071096 Ex d ia IIC T6 (-20 °C < T <...

  • Page 25: Canadian Standards Association (Csa) Approval

    Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 Factory Mutual (FM) Approval Project ID: 3013394 E5 Explosion-proof for use in Class I, Div. 1, Groups B, C, and D; Dust-ignition-proof for use in Class II/III, Div. 1, Groups E, F, and G;...

  • Page 26: Iecex Approval

    = 30 V, I = 130 mA, P = 1 W, C = 0 nF, L = 0 mH Approval valid for HART option. For information on hazardous locations installations, refer to Rosemount 3300 Series Reference Manual (Document No. 00809-0100-4811).

  • Page 27: Overfill Protection

    Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 Overfill Protection U1 WHG Overfill Approval: TÜV-tested and approved by DIBt for overfill protection according to the German WHG regulations. Cert no: Z-65.16-416 Available for HART option.

  • Page 28: Ec Declaration Of Conformity

    Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 EC Declaration of Conformity Figure 1. EC Declaration of Conformity - page 1...
  • Page 29 Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 Figure 2. EC Declaration of Conformity - page 2...
  • Page 30 Quick Installation Guide 00825-0100-4811, Rev GA Rosemount 3300 Series October 2011 Figure 3. EC Declaration of Conformity - page 3...
