  • Page 1: Instructions For Use

    SVENSKA NEDERLANDS ESPAÑOL ITALIANO FRANÇAIS DEUTSCH ENGLISH PORTUGUÊS INSTRUCTIONS FOR USE Perimeter OCTOPUS ® 6. Edition / 2016 – 09 DOC. no. 1500 1500.1400209.04000 © HAAG‑STREIT AG, 3098 Koeniz, Switzerland ‑ HS Doc. no. 1500.7220367.04060 – 6. Edition / 2016 – 09 01-IFU_Octopus600-7220367_04060_eng.indd 1 27.09.2016 08:45:17...
  • Page 2 Purpose of use 6. Edition / 2016 – 09 The Octopus 600 perimeter is designed for the examination, analysis and documen- tation of the field of sight, especially the light difference sensitivity and other func- tions of the human eye.

  • Page 3: Table Of Contents

    Table 3: Immunity (not life-support equipment) .............16 Safe system configuration in accordance Table 4: Recommended safe distances (not life-support equipment) ....177 with EN 60601-1 ..............10 System versions, OCTOPUS 600 with printer ............10 Commissioning ..............11 Switching on the appliance ...................11 Switching off the appliance ...................11 ©...

  • Page 4: Safety

    • The use of accessories other than than those listed may result in Use: Temperature from +10°C +35°C higher emissions or lower interference immunity of the Octopus 600. Air pressure from 800 hPa 1060 hPa • The software must be installed by trained personnel.

  • Page 5: Operation And Environment

    Warranty and product liability other cases, the user must monitor the eye personally during the • Haag-Streit products must be used only for the purposes and in the manner des- examination. cribed in the documents distributed with the product. • All users must be appropriately trained and familiarised with the •...

  • Page 6: Symbols

    USA Introduction Device description • The Octopus 600 is a screen perimeter for examining the central field of sight (30°). The device can be employed autonomously, i.e., the examination and con- trol components are integrated in the device. •...

  • Page 7: User Interface (14)

    • The optional chin rest can be used to stabilize the patient. The height can be freely A high-contrast display allows operation of the Octopus 600 at a large angle of adjusted using the rotating knobs on the side. view.

  • Page 8: Connections

    Connections 2.12 LED background lighting 16. 4 x USB 2.0 port In the Octopus 600, LEDs are used as light sources for the periphery and stimu- 17. Mains switch lus. The light intensity of the background lighting is measured with two independent 18.

  • Page 9: Connecting The Electric Power Supply Cable

    3.3 Connecting the electric power supply cable • The power unit for the Octopus 600 is designed for the voltages specified on the type plate. © HAAG‑STREIT AG, 3098 Koeniz, Switzerland ‑ HS Doc. no. 1500.7220367.04060 – 6. Edition / 2016 – 09 01-IFU_Octopus600-7220367_04060_eng.indd 9...

  • Page 10: Safe System Configuration In Accordance With En 60601-1

    Version II: 28. Printer connection via Ethernet port. This Ethernet port is electrically isolated in Printer connected via Ethernet port (28) the Octopus 600 and has a dielectric strength of 4 kV according to EN 60601-1. 21. Octopus 600 22. Printer 23.

  • Page 11: Commissioning

    The software's help section contains instructions and help for performing an exam- ination and descriptions of the error messages. The help can be opened via the F1 Before connecting the Octopus 600 to a suitable power socket, it must be ensured key or in the [?] - [Help] menu.

  • Page 12: Dimensions

    Applied parts such as the eye patch, patient response button and forehead and On the screen of the Octopus 600 it is possible to examine up to the following ec- chin rest (optional) as well as other parts such as the corrective lenses and the pa- centricity: tient-side cover are made of easy-to-clean plastics.

  • Page 13: Legal Regulations

    125% = Factor for products which can be repaired. Daily use = service use, from • field tests Average data: 21,900 patients/year, 10 minutes/patient. The Octopus 600 is a Class IIa device in accordance with Appendix IX of Direc- tive 93/42/EEC. By affixing the CE mark we confirm that our device complies 21900 with the applicable standards and directives.

  • Page 14: Concerning Electromagnetic Compatibility

    • Portable and mobile HF communication systems may interfere with General electrical medical devices. The Octopus 600 fulfils the requirements on electromagnetic compatibility according • Connecting third-party systems to the same extension cable can to EN 60601-1-2. The instrument is constructed in such a way that the generation compromise safety.

  • Page 15: Table 2: Immunity

    SVENSKA NEDERLANDS ESPAÑOL ITALIANO FRANÇAIS DEUTSCH ENGLISH PORTUGUÊS Table 2: Immunity Guidance and manufacturer's declaration – electromagnetic immunity This product is intended for use in the electromagnetic environment specifi ed below. The customer or the user of this product should assure that it is used in such an envi- ronment.

  • Page 16: Table 3: Immunity (Not Life-Support Equipment)

    ENGLISH DEUTSCH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA PORTUGUÊS Table 3: Immunity (not life-support equipment) Guidance and manufacturer's declaration – electromagnetic immunity This product is intended for use in the electromagnetic environment specifi ed below. The customer or the user of this product should assure that it is used in such an envi- ronment.

  • Page 17: Table 4: Recommended Safe Distances (Not Life-Support Equipment)

    SVENSKA NEDERLANDS ESPAÑOL ITALIANO FRANÇAIS DEUTSCH ENGLISH PORTUGUÊS Table 4: Recommended safe distances (not life-support equipment) Recommended safe distances between portable and mobile HF communication devices and this device. This product is designed to be operated in an electromagnetic environment in which radiated HF interference is controlled. The customer or user of this product can help to prevent electromagnetic interference by maintaining minimum distances between portable and mobile HF communication systems (transmitters) and this product, as rec- ommended below in accordance with the maximum output of the communication system.
  • Page 18 ENGLISH DEUTSCH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA PORTUGUÊS © HAAG‑STREIT AG, 3098 Koeniz, Switzerland ‑ HS Doc. no. 1500.7220367.04060 – 6. Edition / 2016 – 09 01-IFU_Octopus600-7220367_04060_eng.indd 18 27.09.2016 08:45:30...
  • Page 19 SVENSKA NEDERLANDS ESPAÑOL ITALIANO FRANÇAIS DEUTSCH ENGLISH PORTUGUÊS © HAAG‑STREIT AG, 3098 Koeniz, Switzerland ‑ HS Doc. no. 1500.7220367.04060 – 6. Edition / 2016 – 09 01-IFU_Octopus600-7220367_04060_eng.indd 19 27.09.2016 08:45:30...
  • Page 20 ENGLISH DEUTSCH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS SVENSKA PORTUGUÊS Should you have any further questions, please contact your HAAG-STREIT representative at: http://www.haag-streit.com/contact/contact-your-distributor.html HAAG-STREIT AG Gartenstadtstrasse 10 1250 3098 Koeniz, Switzerland Phone +41 31 978 01 11 +41 31 978 02 82 eMail info@haag-streit.com...
